| Ref | Part Number | Description |
|---|
| 1 |
532057079 |
THRUST WASHER Price: $1.99 |
| 2 |
532124416 |
INSERT,STR WHEEL Price: $7.89 |
| 3 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 4 |
532100712 |
WASHER Price: $2.42 |
| 5 |
532124415 |
STEERING WHEEL Price: $58.99 |
| 6 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532100711. Price: $7.99 |
| 7 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 8 |
532165857 |
SCREW.HX.WSH.HD This part replaces 871070410. Price: $3.99 |
| 9 |
532004921 |
COTTER PIN This part replaces 532124961. Price: $4.99 |
| 010 |
98-9468 |
NOZZLE HOLDER ASM Price: $341.86 |
| 10 |
532102670 |
SPRING GTV Price: $3.84 |
| 12 |
873610600 |
NUT Price: $2.99 |
| 13 |
532124577 |
COVER.FRONT.WHEEL Price: $10.99 |
| 14 |
532121274 |
KNOB.DUCKHEAD.1/2 Price: $8.99 |
| 15 |
532110845 |
ROD YTH Price: $8.99 |
| 16 |
532121631 |
SPRING TORSION Price: $2.42 |
| 17 |
532108196 |
BRKT CONTROL HYT NLA Price: $8.01 |
| 18 |
532156544 |
STEERING SHAFT This part replaces 532128762. Price: $64.99 |
| 020 |
99-8301 |
NUT Price: $8.64 |
| 20 |
532160395 |
STEERING SHAFT SUPPORT This part replaces 532124035. Price: $8.99 |
| 21 |
596582301 |
Washers This part replaces 532126684. Price: $2.99 |
| 22 |
531152201 |
SERVICE KIT BRACKET BRKT This part replaces 532124036. Price: $12.99 |
| 24 |
812000029 |
RING CLIP Price: $3.99 |
| 25 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 26 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532127501. Price: $29.99 |
| 27 |
532108972 |
WASHER HYT Price: $2.38 |
| 28 |
532136874 |
GEAR.SECTOR This part replaces 532124034. Price: $69.99 |
| 030 |
99-8302 |
WASHER-ADJUSTING Price: $7.16 |
| 30 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 31 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 32 |
532108200 |
WASHER FRIC HYT Price: $2.38 |
| 33 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 34 |
532108518 |
BOLT HYT Price: $3.52 |
| 35 |
819212016 |
WASHER D Price: $4.99 |
| 36 |
532108201 |
SPACER HYT NLA Price: $6.23 |
| 37 |
532121202 |
LINK CONTROL Price: $6.05 |
| 38 |
532108844 |
SPRING HYT Price: $6.16 |
| 39 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 040 |
99-8303 |
SPRING-NOZZLE Price: $11.49 |
| 40 |
596564405 |
Bolts This part replaces 874760648. Price: $2.99 |
| 41 |
532121209 |
ARM ASM PUMP Price: $16.19 |
| 42 |
532105663 |
SUPPORT-SADDLE LT NLA Price: $8.25 |
| 43 |
874761060 |
BOLT LT Price: $4.99 |
| 44 |
532105664 |
SUP-SADDLE FRT LT Price: $9.99 |
| 45 |
532130468 |
LINK.DRAG.SOL.BALL JT.20.064 Price: $64.99 |
| 46 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 47 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 48 |
532170162 |
ROD.ASM.TIE.BALL.JOINT.NOVAN This part replaces 532130467. Price: $79.99 |
| 49 |
873610500 |
This part replaces 873810500. Price: $2.15 |
| 050 |
99-8304 |
SPACER-DISTANCE Price: $29.26 |
| 50 |
532156483 |
SPINDLE ASM LH This part replaces 532130460. Price: $22.99 |
| 51 |
819272016 |
WASHER Price: $3.99 |
| 52 |
532155134 |
KIT-AXLE This part replaces 532110438. Price: $13.26 |
| 53 |
532122819 |
SCREW SPECIAL Price: $2.38 |
| 54 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 55 |
583612401 |
LOCKNUT M This part replaces 873601000. Price: $2.99 |
| 56 |
532108075 |
AXLE ASSY T Price: $62.55 |
| 57 |
532130459 |
SPINDLE Price: $29.86 |
| 58 |
532000278 |
FITTING LT. This part replaces 532124957. Price: $5.99 |
| 59 |
532065139 |
VALVE STEM LT Price: $5.99 |
| 060 |
99-8305 |
ROD-PUSH Price: $60.67 |
| 60 |
532059192 |
VALVE CAP Price: $4.99 |
| 61 |
532009040 |
BEARING.FLANGE This part replaces 532124959. Price: $6.99 |
| 62 |
532106732 |
RIM.ASM.6X4.5.FRONT.SILVER This part replaces 532125102. Price: $79.99 |
| 63 |
532122073 |
TIRE.15X6-6.TURF.SAVER.FRONT This part replaces 532106222. Price: $59.99 |
| 64 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 65 |
532108212 |
TRUNION HYT Price: $19.99 |
| 66 |
532121750 |
ROD ADJ CONTROL Price: $46.99 |
| 67 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 68 |
532059904 |
TUBE.5.3/4.5/6 Price: $19.99 |
| 070 |
99-8306 |
NUT-NOZZLE Price: $34.65 |
| 71 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 72 |
532123186 |
BRACKET Price: $2.38 |
| 73 |
532183226 |
FITTING.GREASE.TAPERED This part replaces 532124836. Price: $4.99 |
| 74 |
532121748 |
WASHER Price: $3.99 |
| 78 |
532109816 |
NYLINER T (7283A) Price: $4.99 |
| 080 |
99-8307 |
WASHER-PLAIN Price: $8.84 |
| 81 |
596134901 |
GSPH This part replaces 819131212. Price: $2.99 |
| 82 |
532121749 |
WASHER Price: $2.99 |
| 83 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 84 |
594976501 |
Washers This part replaces 819151516. Price: $2.99 |
| 85 |
532110739 |
WASHER T Price: $3.99 |
| 86 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 87 |
532121217 |
GUIDE CONTROL Price: $2.38 |
| 88 |
532121216 |
BRKT NLA Price: $2.38 |
| 89 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 090 |
99-8308 |
PIECE-NOZZLE Price: $90.57 |
| 90 |
817021008 |
SCREW Price: $3.99 |
| 91 |
819070816 |
Washer 7/32 x 1/2 x 16 Gauge Price: $5.99 |
| 92 |
874561014 |
SCREW Price: $2.99 |
| 93 |
532069180 |
LOCKNUT Price: $2.99 |
| 94 |
532121204 |
BELLCRANK NLA Price: $5.46 |
| 95 |
532121206 |
BRKT BELLCRANK NLA Price: $2.38 |
| 96 |
532100536 |
SHOULDER BOLT LT Price: $2.38 |
| 97 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 98 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 100 |
99-8309 |
ADJUSTING WASHER ASM Price: $56.19 |
| 110 |
99-8310 |
WASHER-ADJUST (0.10MM) Price: $2.74 |
| 110 |
99-8311 |
WASHER-ADJUST (0.20MM) Price: $3.56 |
| 110 |
99-8312 |
WASHER-ADJUST (0.30MM) Price: $2.74 |
| 110 |
99-8313 |
WASHER-ADJUST (0.40MM) Price: $2.74 |
| 110 |
99-8315 |
WASHER-ADJUST (0.52MM) Price: $1.91 |
| 110 |
99-8316 |
WASHER-ADJUST (0.54MM) Price: $1.91 |
| 110 |
99-8317 |
WASHER-ADJUST (0.56MM) Price: $1.91 |
| 110 |
99-8318 |
WASHER-ADJUST (0.58MM) Price: $1.91 |
| 110 |
99-8319 |
WASHER-ADJUST (0.80MM) Price: $1.91 |
