| Ref | Part Number | Description |
|---|
| 1 |
532146525 |
This part replaces 532123198. Price: $3.99 |
| 1 |
7-3900 |
PAD-BRAKE Price: $27.35 |
| 2 |
819091016 |
Washer 9/32 x 5/8 x 16 Ga. (AYP part number) Price: $2.99 |
| 2 |
93-8743 |
FOOTPAD-TURN This part replaces 27-7580. Price: $27.95 |
| 3 |
532150109 |
BATTERY HOLDDOWN This part replaces 532102476. Price: $4.99 |
| 3 |
93-8743 |
FOOTPAD-TURN This part replaces 27-7570. Price: $27.95 |
| 4 |
323-6 |
SCREW-HH Price: $0.66 |
| 4 |
872240460 |
Carriage Bolt (AYP part number) Price: $3.99 |
| 5 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 5 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532121265. Price: $139.99 |
| 6 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 6 |
532007603 |
TRAY.BATTERY This part replaces 532124886. Price: $3.99 |
| 7 |
3218-5 |
NUT-JAM Price: $0.27 |
| 7 |
532124262 |
Ignition Harness Price: $3.33 |
| 8 |
21-2850-01 |
MOUNT-PEDAL, RH This part replaces 21-2850. Price: $69.64 |
| 8 |
532110859 |
Light Socket Harness (AYP part number) Price: $17.84 |
| 9 |
32144-102 |
SCREW-HWH This part replaces 11-0590. Price: $3.19 |
| 9 |
532004152 |
Light Bulb (AYP part number) Price: $2.99 |
| 10 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 10 |
532007697 |
Tube, Tray, Battery (AYP part number) This part replaces 532100541. Price: $6.23 |
| 11 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 11 |
532007192 |
WIRE TIE This part replaces 532124756. Price: $3.99 |
| 12 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 12 |
532004021 |
PTO Switch (AYP part number) Price: $18.99 |
| 13 |
532108423 |
Battery Cable (Battery to Solenoid) (AYP part number) Price: $5.99 |
| 13 |
95-1821 |
SPRING-COMPRESSION This part replaces 3-3251. Price: $6.71 |
| 14 |
27-9530 |
DISCONTINUED Price: Call Us |
| 14 |
532365402 |
KIT.SWITCH.IGNITN This part replaces 532125104. Price: $17.99 |
| 15 |
33-4350 |
DISCONTINUED This part replaces 22-6380. Price: Call Us |
| 15 |
532124211 |
Nut, Ignition (AYP part number) This part replaces 532109788. Price: $3.99 |
| 16 |
24-2000 |
DISCONTINUED Price: Call Us |
| 16 |
532122147 |
Key (AYP part number) Price: $4.99 |
| 17 |
24-2090 |
STEERING WHEEL CAP Price: $30.55 |
| 17 |
532109081 |
Solenoid (AYP part number) Price: $22.99 |
| 18 |
233-17 |
KNOB Price: $10.58 |
| 18 |
532110712 |
Light Switch (AYP part number) Price: $4.99 |
| 19 |
27-7660 |
DISCONTINUED Price: Call Us |
| 19 |
873680400 |
Hex Nut 1/4-20 (AYP part number) Price: $2.99 |
| 20 |
27-7300 |
DISCONTINUED Price: Call Us |
| 20 |
532124967 |
Clip, Insulated (AYP part number) This part replaces 532004171. Price: $5.46 |
| 21 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 21 |
532004799 |
BATTERY CABLE This part replaces 532124780. Price: $6.99 |
| 22 |
28-5190 |
DISCONTINUED Price: Call Us |
| 22 |
532124783 |
Terminal Cover (For Solenoid) (AYP part number) Price: $4.99 |
| 23 |
28-5130 |
TRACTION PEDAL PAD Price: $33.21 |
| 23 |
532124773 |
Battery Cable (To Ground) (AYP part number) Price: $4.99 |
| 24 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 24 |
874641008 |
Pan Head Screw (AYP part number) Price: $2.99 |
| 25 |
28-5220 |
FRICTION WHEEL ASM Price: $108.15 |
| 25 |
532109596 |
Hose Clamp (AYP part number) Price: $2.99 |
| 26 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 26 |
810040400 |
Lock Washer 1/4 (AYP part number) Price: $3.99 |
| 27 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873350400. Price: $3.99 |
| 27 |
603773 |
LOCKNUT This part replaces 32146-2. Price: $2.09 |
| 28 |
32136-4 |
NUT-HEX,SLOTTED Price: $1.56 |
| 28 |
539990071 |
HCS 1/4-20. This part replaces 874780408. Price: $1.99 |
| 29 |
28-5160-01 |
DISCONTINUED This part replaces 28-5160. Price: Call Us |
| 29 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 30 |
28-5210 |
TRACT PEDAL SHAFT Price: $48.49 |
| 30 |
874760412 |
Hex Bolt 1/4-20 x 3/4 (AYP part number) Price: $3.99 |
| 31 |
28-5240 |
DISCONTINUED Price: Call Us |
| 31 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $3.99 |
| 32 |
23-2240-03 |
PUMP CONTROL TUBE ASM This part replaces 23-2240. Price: $209.72 |
| 32 |
810040400 |
LOCKWASHER This part replaces 811050400. Price: $3.99 |
| 33 |
23-2270 |
BUSHING-RUBBER Price: $17.07 |
| 34 |
3-7243 |
SPRING-EXTENSION Price: $11.23 |
| 34 |
532122822 |
Ammeter (AYP part number) Price: $11.99 |
| 35 |
283-30 |
PIN-CLEVIS Price: $0.35 |
| 36 |
99-5686 |
RH SOCKET ASM This part replaces 21-0140. Price: $99.81 |
| 37 |
3220-5 |
NUT-JAM Price: $0.65 |
| 38 |
108-1380 |
LH BRAKE CABLE ASM This part replaces 21-3380. Price: $162.33 |
| 39 |
26-9760 |
DISCONTINUED Price: Call Us |
| 39 |
532102501 |
Wire Loop (AYP part number) Price: $9.49 |
| 40 |
3231-21 |
SCREW-CARR Price: $0.76 |
| 40 |
532124995 |
Insulated Clip (AYP part number) Price: $2.38 |
| 41 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 41 |
539990118 |
SLW 3/8 STD This part replaces 811050600. Price: $1.99 |
| 42 |
3274-47 |
SCREW-HSFH Price: $0.53 |
| 42 |
532104445 |
Clutch Pedal Interlock Switch (AYP part number) Price: $9.99 |
| 43 |
27-7590-01 |
BRAKE MT WA This part replaces 27-7590. Price: $239.14 |
| 43 |
532004022 |
Hex Nut (AYP part number) Price: $2.99 |
| 44 |
3217-7 |
NUT-HEX Price: $0.28 |
| 44 |
873951000 |
Keps Nut #10-32 UNF (AYP part number) Price: $5.99 |
| 45 |
32149-2 |
NUT-KEPS Price: $2.39 |
| 45 |
584446901 |
KIT.IGN.BOOT/NUT This part replaces 532109787. Price: $4.99 |
| 46 |
27-9270-01 |
PIVOT SHAFT MOUNT ASM This part replaces 27-9270. Price: $81.41 |
| 46 |
532421062 |
SWITCH.SNAPMOUNT.NC This part replaces 532121305. Price: $7.99 |
| 47 |
3272-7 |
PIN-COTTER Price: $0.25 |
| 47 |
817021008 |
Tapping Hex Screw (AYP part number) Price: $1.99 |
| 48 |
27-7640-01 |
SHAFT-BRAKE LATCH ASM This part replaces 27-7640. Price: $62.42 |
| 48 |
532121264 |
Battery Caps Set (AYP part number) Price: $10.91 |
| 49 |
256-10 |
BUSHING-FLANGE Price: $3.68 |
| 49 |
810040400 |
LOCKWASHER This part replaces 810090400. Price: $3.99 |
| 50 |
27-7490 |
LH BRAKE PEDAL ASM Price: $347.33 |
| 51 |
27-7510 |
RH BRAKE PEDAL ASM Price: $321.91 |
| 52 |
302-5 |
FITTING-GREASE Price: $0.59 |
