| Ref | Part Number | Description |
|---|
| 1 |
117-3070-01 |
PEDAL Price: $87.89 |
| 2 |
117-3073 |
PIVOT-PEDAL Price: $34.46 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 589818701. Price: $44.99 |
| 3 |
323-6 |
SCREW-HH Price: $0.66 |
| 4 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 5 |
115-0072-03 |
ROD-TRACTION Price: $68.85 |
| 6 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 7 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 8 |
323-29 |
SCREW-HH Price: $0.42 |
| 9 |
3220-3 |
NUT-HJ Price: $0.28 |
| 9 |
596501502 |
Keepers This part replaces 501832602. Price: $9.99 |
| 10 |
115-0148 |
ARM ASM Price: $94.35 |
| 11 |
76-8640 |
STUD-TRACTION Price: $23.60 |
| 12 |
532405472 |
RP_PULLEY ENGINE This part replaces 586728901. Price: $34.99 |
| 12 |
85-9120 |
SPACER-PIVOT, TILT Price: $4.01 |
| 13 |
251-259 |
BEARING-BALL This part replaces 251-307. Price: $13.67 |
| 14 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 15 |
3274-86 |
SCREW-HSH Price: $1.76 |
| 16 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 17 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 18 |
323-9 |
SCREW-HH Price: $1.29 |
| 19 |
117-3298 |
LEVER-MOW STOP Price: $12.70 |
| 20 |
116506 |
SPRING-EXTENSION Price: $18.19 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 21 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 22 |
94-3308 |
PAD-PEDAL, TRACTION Price: $8.96 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 70 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 Price: $17.99 |
| 71 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 Price: $19.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE Price: $2.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 110 |
532414118 |
VALVE.ASM.ANTI-SLOSH Price: $19.99 |
| 111 |
587044580 |
Hoses This part replaces 532414119. Price: $9.99 |
