| Ref | Part Number | Description |
|---|
| 1 |
3274-80 |
SCREW-HH Price: $1.76 |
| 1 |
531151701 |
SERVICE KIT TUBE TUBE.HANDLE.B This part replaces 532428610. Price: $14.99 |
| 2 |
3256-80 |
WASHER-PLAIN Price: $0.25 |
| 3 |
83-0650-01 |
ARM-STEERING ASM This part replaces 83-0650. Price: $418.93 |
| 4 |
579785402 |
BAGGER SWAGE TUBE HANDLE ASSY This part replaces 532439612. Price: $44.99 |
| 4 |
83-0780-03 |
SUPPORT-VALVE, STEERING This part replaces 83-0780. Price: $56.04 |
| 5 |
583365901 |
FRAME.ASM.TOP.BAGGER.SRD This part replaces 532417632. Price: $89.99 |
| 6 |
532126875 |
RIVET,DRILLED Price: $2.99 |
| 6 |
83-0750 |
CAPSCREW-HH, LH THREAD Price: $30.37 |
| 7 |
323-4 |
SCREW-HH Price: $1.02 |
| 7 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 8 |
32144-21 |
SCREW Price: $0.20 |
| 8 |
583503801 |
SRD.BAGGER.TOP.SUB.ASM This part replaces 532435165. Price: $119.99 |
| 9 |
583365801 |
INSERT.HANDLE.BAGGER.SRD This part replaces 532417629. Price: $22.99 |
| 9 |
68-5140 |
CAP-WHEEL, STEERING Price: $15.13 |
| 10 |
107-2561 |
NUT-HEX This part replaces 47-6990. Price: $14.65 |
| 10 |
585384501 |
FRAME FRONT TUBE TEX CRD BLACK This part replaces 532436770. Price: $37.99 |
| 11 |
583511601 |
BRACE.SIDE.TUBE.TEX/CRD.BLACK This part replaces 532436771. Price: $11.99 |
| 11 |
68-5130 |
WHEEL-STEERING Price: $124.07 |
| 12 |
3246-3 |
SCREW-HSH Price: $12.70 |
| 12 |
583391701 |
NUT.SQUARE.1/4 This part replaces 532421793. Price: $3.99 |
| 13 |
583391201 |
SCREW.1/4X1.150.HXWSH This part replaces 532421780. Price: $2.99 |
| 13 |
65-6390 |
WASHER-THRUST, PLAIN Price: $5.02 |
| 14 |
583392001 |
BOLT.SHOULDER.HX.WSH.1/4X1.150 This part replaces 532421800. Price: $6.99 |
| 14 |
83-0740 |
DISC-FRICTION Price: $12.57 |
| 15 |
83-0730 |
SPACER-LOCKUP Price: $11.78 |
| 16 |
83-0760 |
SPACER-PLATE, LOCKUP Price: $8.77 |
| 17 |
233-48 |
KNOB Price: $10.92 |
| 18 |
83-0700-03 |
HANDLE-LOCKUP This part replaces 83-0700. Price: $103.37 |
| 19 |
325-4 |
SCREW-HH Price: $0.95 |
| 19 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 20 |
47-2890 |
BUSHING Price: $3.19 |
| 20 |
585368801 |
SCREW.HEXCAP.1/4-20X1.375(2 2) Price: $2.99 |
| 21 |
3274-39 |
SCREW-HSBH Price: $4.34 |
| 22 |
3290-277 |
NUT-SPEED Price: $0.61 |
| 23 |
83-1420 |
COLUMN-STEERING Price: $284.84 |
| 23 |
872040410 |
BOLT Price: $3.99 |
| 24 |
92-8690 |
STEERING CONTROL VALVE ASM Price: $1,180.24 |
| 25 |
83-0810 |
COVER-STEERING Price: $110.46 |
| 26 |
83-1350 |
HOSE-HYD Price: $71.15 |
| 27 |
583387201 |
GROMMET.RUBBER.SRD This part replaces 532421262. Price: $3.99 |
| 27 |
83-1360 |
HOSE-HYD Price: $68.95 |
| 28 |
532165787 |
GRIP.HANDLE.BLACK Price: $5.99 |
| 28 |
83-1370 |
HOSE ASSY - HYD Price: $65.82 |
| 29 |
237-21 |
O-RING Price: $0.70 |
| 30 |
340-1 |
FITTING-STRAIGHT Price: $10.19 |
| 30 |
583519701 |
PLUG.97CM.TEX.CRD.MULCH This part replaces 532437452. Price: $19.99 |
| 31 |
237-42 |
O-RING Price: $2.78 |
| 31 |
583507401 |
PIN.HINGE This part replaces 532435861. Price: $5.99 |
| 32 |
584455101 |
SPRING.DOUBLE.TORSION.SPRING This part replaces 532437454. Price: $11.99 |
| 33 |
3274-63 |
SCREW-HSBH Price: $1.09 |
| 33 |
583531101 |
SHAFT.TEX.CRD.MULCH.PLUG This part replaces 532438451. Price: $29.99 |
| 34 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 34 |
532437988 |
E-RING.5/16" Price: $7.99 |
| 35 |
583539101 |
GRIP.MULCH.PLUG.HAND. This part replaces 532439139. Price: $11.99 |
| 36 |
594093401 |
Bolts This part replaces 532439098. Price: $5.99 |
| 37 |
532069180 |
LOCKNUT Price: $2.99 |
| 38 |
819070818 |
WASHER Price: $5.99 |
| 39 |
583539501 |
BUNGEE.TEX.CRD This part replaces 532439242. Price: $12.99 |
| 40 |
532439418 |
Price: Call Us |
| 41 |
532439435 |
Price: Call Us |
| 42 |
583548101 |
CHRISTMAS.TREE.CLIP This part replaces 532440428. Price: $2.99 |
