| Ref | Part Number | Description |
|---|
| 1 |
3242-1 |
SCREW-SQH Price: $3.66 |
| 1 |
530015805 |
Screw-alignment Price: $1.99 |
| 2 |
22-8670 |
TIE ROD Price: $26.76 |
| 2 |
530015886 |
Screw Price: $1.99 |
| 3 |
22-8650 |
WASHER Price: $1.39 |
| 3 |
530057983 |
Hsg.-Throttle right Price: $7.99 |
| 4 |
22-8630 |
HEAD Price: $701.11 |
| 4 |
530016326 |
Screw-Cable Retention Price: $1.99 |
| 5 |
22-8610 |
ROD-PISTON, 10IN Price: $209.81 |
| 5 |
530057984 |
Hsg.-Left throttle Price: $6.99 |
| 6 |
3217-9 |
NUT-HH Price: $0.37 |
| 6 |
530058843 |
Assy-Wire Price: $5.99 |
| 7 |
22-8660 |
WIPER-SEAL, 10IN Price: $44.00 |
| 7 |
530069572 |
Kit-Switch Price: $4.99 |
| 8 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 8 |
530058583 |
Assy-Handle This part replaces 530057546. Price: $4.99 |
| 9 |
22-8680 |
DISCONTINUED Price: Call Us |
| 9 |
545017701 |
TRIGGER THROTTLE RED This part replaces 530058759. Price: $1.99 |
| 10 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 10 |
530091373 |
Nut This part replaces 530016152. Price: $1.99 |
| 11 |
42-2390 |
SWITCH This part replaces 27-5760. Price: $79.18 |
| 11 |
530015786 |
Bolt Price: $1.99 |
| 12 |
302-40 |
FITTING-GREASE, 90 DEG Price: $1.70 |
| 13 |
37-2080 |
DISCONTINUED Price: Call Us |
| 13 |
530016344 |
Screw Price: $1.99 |
| 14 |
218-461 |
NUT-HH Price: $2.50 |
| 14 |
530071788 |
Kit - Lower Shaft Assy. This part replaces 545024301. Price: $37.99 |
| 15 |
28-2100 |
DISCONTINUED Price: Call Us |
| 16 |
256-198 |
Bushing Price: Call Us |
| 16 |
530052286 |
Limiter-Line Price: $1.54 |
| 17 |
22-8640 |
O-RING Price: $16.87 |
| 17 |
530015814 |
Screw Price: $1.99 |
| 18 |
22-8550 |
O-RING Price: $11.98 |
| 18 |
530015820 |
Bolt Price: $1.99 |
| 19 |
37-2110 |
DISCONTINUED Price: Call Us |
| 19 |
530091373 |
Nut This part replaces 530016152. Price: $1.99 |
| 20 |
37-2160 |
DISCONTINUED Price: Call Us |
| 20 |
530057559 |
Dustcup Price: $2.99 |
| 21 |
115-4947-01 |
HYDRAULIC CYLINDER ASM (10.69 STROKE) This part replaces 22-8620. Price: $880.23 |
| 21 |
530071306 |
Kit-Hub Ass'y This part replaces 530095776. Price: $8.99 |
| 22 |
22-8600 |
O-RING Price: $10.49 |
| 22 |
530053241 |
Spring-Return Price: $1.99 |
| 23 |
22-8590 |
PISTON Price: $454.13 |
| 23 |
530401957 |
Retainer-Spool Price: $1.99 |
| 24 |
22-8560 |
LOCKNUT Price: $2.37 |
| 24 |
952711548 |
Accy-Spool w/Line This part replaces 952711624. Price: $6.95 |
| 25 |
22-8580 |
WASHER Price: $14.50 |
| 26 |
22-8570 |
O-RING Price: $10.69 |
| 27 |
22-8540 |
CAP-END Price: $634.77 |
| 28 |
37-2140 |
DISCONTINUED Price: Call Us |
