| Ref | Part Number | Description |
|---|
| 1 |
115-5357-03 |
BRACKET-JOYSTICK Price: $35.61 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 2 |
106-4192 |
SPACER Price: $5.47 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
93-5547 |
BUSHING-NYLON Price: $6.15 |
| 4 |
119-3540 |
HUB-PIVOT, JOYSTICK Price: $40.61 |
| 5 |
105-8289 |
SPRING-TORSION Price: $15.05 |
| 6 |
106-4193 |
WASHER-FINGER, SPRING Price: $3.66 |
| 7 |
322-9 |
SCREW-HH Price: $3.09 |
| 8 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 8 |
587205101 |
TRAY.BATTERY BOX.FRONT Price: $14.99 |
| 9 |
3290-354 |
NUT-SPEED Price: $9.99 |
| 10 |
108-6496 |
SWITCH (W/BOOT) Price: $18.62 |
| 11 |
95-3003 |
SCREW-PPHTF Price: $2.99 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 24 |
585555601 |
CABLE.FRBATT.W/WIRE.8GA.8 Price: $7.99 |
| 25 |
585555501 |
CABLE.STARTER.8GA.17.5 Price: $7.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
596133601 |
Hardware Price: $2.99 |
| 28 |
532416588 |
CABLE.GROUND.21"BLK.8GA.90T Price: $11.99 |
| 29 |
532192749 |
SWITCH.SEAT.DP W/RAMPS Price: $17.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $8.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
580723502 |
HARNESS DASH DIFF LOCK HARNESS Price: $59.99 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. Price: $19.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 582107602. Price: $24.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 71 |
580513001 |
HARNESS.IGN.CHASSIS.TEX.DCKLOC Price: $37.99 |
| 75 |
580366401 |
SWITCH.ON/OFF.(DIFF.LOCK) Price: $32.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $4.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 100 |
596135301 |
Washers Price: $2.99 |
| 102 |
532404454 |
HARNESS PIGTAIL PCH TEX ROS Price: $14.99 |
| 105 |
532407568 |
REVERSE SWITCH Price: $12.99 |
