| Ref | Part Number | Description |
|---|
| 2 |
13524 |
BRACKET-HI Not Available Price: |
| 3 |
711-0684 |
CLEVIS PIN .25 x 1.00 Not Available Price: |
| 4 |
717-0344 |
PUMP Not Available Price: |
| 5 |
13532 |
HANDLE ASSEMBLY Not Available Price: |
| 6 |
920-0232 |
Knob This part replaces 720-0232. Price: $9.11 |
| 7 |
13531 |
HANDLE ASSEMBLY Not Available Price: |
| 8 |
710-0105 |
SCREW-TRUSS MACH 1/4-20 x 3.0 Not Available Price: |
| 9 |
13534 |
VALVE BASE PLATE Not Available Price: |
| 12 |
927-0200 |
VALVE Not Available This part replaces 727-0200. Price: |
| 15 |
714-0101 |
Hairpin Cotter 1/2" Dia. Price: $4.13 |
| 16 |
711-0308 |
CLEVIS PIN Not Available This part replaces 711-0140. Price: |
| 18 |
736-0156 |
Fl-Wash. .62" I.D. x 1.12" Price: $3.95 |
| 19 |
714-0147 |
Hairpin Cotter Price: $4.20 |
| 20 |
938-0148 |
Shoulder Screw, .50 x .66 This part replaces 738-0148. Price: $14.70 |
| 22 |
736-0217 |
L-Wash. 3/8" I.d.-H.D. Price: $3.86 |
| 23 |
736-0258 |
Fl-Wash. .38" I.D. x 1.00" Price: $3.93 |
| 24 |
13151 |
ARM-LIFT Not Available Price: |
| 25 |
750-0526 |
Spacer .385" I.D. Price: $3.96 |
| 26 |
13729 |
Cross Shaft Ass'y.-Front Price: Call Us |
| 27 |
13139 |
LIFT ARM LINK Not Available Price: |
| 28 |
13728 |
SHAFT ASSEMBLY Not Available Price: |
| 30 |
711-0146 |
COLLAR 1/2 x 1.00 x .320 Not Available Price: |
| 31 |
13545 |
BRACKET-IN Not Available Price: |
| 32 |
711-0242 |
Spacer .38" I.D. x 1.0" O.D. Price: $3.95 |
| 33 |
711-04722 |
Pin, Clevis, .375 x .969 HT This part replaces 711-0173. Price: $5.89 |
| 34 |
710-0459A |
Hex Cap Screw 3/8-24 x 1.5 This part replaces 710-0459. Price: $6.50 |
| 35 |
13570 |
DECK LINK Not Available Price: |
| 36 |
13572 |
REAR WHEEL HUB ASS'Y. Not Available Price: |
| 37 |
13574A-0637 |
PLATE-HUB Not Available This part replaces 13574. Price: |
| 39 |
936-0364 |
WASHER Not Available This part replaces 736-0364. Price: |
| 40 |
912-0288 |
HEX NUT INS L 3/4-10 Not Available This part replaces 712-0288. Price: |
| 41 |
710-0470 |
BOLT 1/2-20 x .875 GR2 Not Available Price: |
| 42 |
734-0935 |
WHEEL ASSEMBLY W/O TIRE COLOR Not Available Price: |
| 43 |
734-0934 |
WHEEL ASSEMBLY W/TIRE 27 x 9.50 XCOLOR Not Available Price: |
| 44 |
727-0159 |
CYLINDER-HYDRO Not Available Price: |
| 46 |
727-0219 |
HOSE-VALVE TO CYL Not Available Price: |
| 47 |
710-0216 |
Hex Bolt 3/8-16 x .75" Lg.-Grade 5 Price: $3.93 |
| 48 |
727-0222 |
REDUCER Not Available Price: |
| 49 |
725-0157 |
Cable Tie This part replaces 726-0178. Price: $3.46 |
| 50 |
712-3029 |
NUT This part replaces 712-0922. Price: $6.01 |
| 51 |
736-0179 |
Fl-Wash. .50" I.D. x 1.25 Price: $4.02 |
| 52 |
727-0217 |
HOSE-FILTER RETURN Not Available Price: |
| 53 |
749-0309 |
TUBE ASSEMBLY-PUMP Not Available Price: |
| 54 |
13026-0637 |
Hitch Brkt. This part replaces 13026. Price: $53.45 |
| 56 |
914-0114 |
Sq. Key 1/4" x 1/4" x 2.00" Not Available This part replaces 714-0114. Price: |
| 57 |
714-0104 |
Hairpin Cotter 1/4" Dia. Price: $3.90 |
| 59 |
710-0528 |
Hex Bolt 5/16-18 x 1.25" Price: $3.90 |
| 60 |
727-0167 |
HOSE-PUMP TO VALVE Not Available Price: |
| 61 |
727-0162 |
FILTER Not Available Price: |
| 62 |
727-0163 |
BASE-FILTER Not Available Price: |
| 63 |
727-0218 |
HOSE-VALVE TO FILTER Not Available Price: |
| 64 |
715-0129 |
Spring Pin Spiral 1/8" Dia. Price: $4.19 |
| 65 |
727-0187 |
ADAPTER-FLARE Not Available Price: |
| 67 |
750-0417 |
SPACER Not Available Price: |
| 68 |
727-0175 |
ADAPTER-90 DEGREE Not Available Price: |
| 69 |
714-0145 |
Hairpin Cotter Price: $4.42 |
| 70 |
13530 |
Transmission Brace Price: Call Us |
| 71 |
13135-0637 |
LIFT SHAFT-RR Not Available This part replaces 13135. Price: |
| 72 |
711-0654 |
Clevis Pin Price: $14.11 |
| 73 |
710-0514 |
Hex Scr. 3/8-16 x 1.00" Lg. Grade 5 Price: $3.78 |
| 75 |
13709 |
BAR ASSEMBLY-P Not Available Price: |
| 76 |
13535 |
INDICATOR Not Available Price: |
| 77 |
13501 |
LIFT SHAFT ASS Y. Not Available Price: |
| 78 |
710-0649 |
HEX SCREW WASH HD 3/8-24X7/8 Not Available Price: |
| 79 |
712-0239 |
Hex Cent. L-Nut 1/2-20 Thd. Price: $5.01 |
| 81 |
731-0707 |
BATERY COVER Not Available Price: |
| 82 |
912-0113 |
Wing Nut 1/4-20 Thd. This part replaces 712-0113. Price: $6.01 |
| 83 |
911-0222A |
HOLD DOWN BATTERY ROD Not Available This part replaces 711-0222. Price: |
| 84 |
951-0226A |
Gas Tank Cap This part replaces 751-0226. Price: $50.20 |
| 88 |
726-0205 |
Gas Line clamp 1/2" Price: $3.71 |
| 89 |
751-10349-54 |
Fuel Line 46" Lg. This part replaces 751-0535-46. Price: $47.01 |
| 94 |
950-0336 |
SLEEVE Not Available This part replaces 750-0336. Price: |
| 95 |
710-0514 |
Hex Bolt 3/8-16 x 1" Lg. This part replaces 710-0253. Price: $3.78 |
| 99 |
710-0515 |
Hex Scr. 1/2-20 x 3 1/2" Lg.-Grade 5 Price: $10.13 |
| 100 |
750-0443 |
SPACER Not Available Price: |
| 102 |
711-0497 |
CLEVIS PIN LINK Not Available Price: |
| 103 |
13196-0637 |
HITCH PLATE Not Available This part replaces 13196. Price: |
| 104 |
712-0923 |
Hex Cent. L-Nut 5/8-18 Thd. Price: $6.01 |
| 105 |
712-0206 |
HEX NUT This part replaces 7120206. Price: $3.90 |
| 106 |
911-0817 |
Eye Bolt Adj. Link 1/2-13 Thd. This part replaces 711-0817. Price: $12.64 |
