| Ref | Part Number | Description |
|---|
| 0 |
632529 |
CARBURETOR Price: Call Us |
| 1 |
581579001 |
DECAL.WARNING.2007.ENG/FR This part replaces 532411658. Price: $3.99 |
| 1 |
631615 |
SHAFT & LEV Price: $6.48 |
| 2 |
631767 |
SPRING Price: $1.25 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 5 |
581724502 |
DECAL.MOWER.CAUTION.TENSION.AR This part replaces 532178455. Price: $2.99 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 6 |
532429557 |
DECAL.ENG.BS.23HP.XRD.TWIN Price: $2.99 |
| 6 |
631036 |
SHUTTER Price: $1.20 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
531229002 |
DECAL.DECK.BELT.ROUTING.48/54 This part replaces 532198785. Price: $1.99 |
| 9 |
532145005 |
DECAL BTRY SYMBOLS Price: $3.99 |
| 10 |
31836 |
SHAFT & LEV Price: $5.21 |
| 11 |
632042 |
SPRING Price: $3.00 |
| 12 |
631184 |
WASHER Price: $1.25 |
| 13 |
631183 |
WASHER Price: $1.25 |
| 14 |
31837 |
SHUTTER Price: $1.18 |
| 14 |
532433142 |
DECAL.SIDE PANEL.YTH23V48 Price: $6.99 |
| 15 |
532423829 |
DECAL.WARNING.CUST.RESP.E85. Price: $14.99 |
| 15 |
630735 |
SPRING Price: $1.25 |
| 16 |
581627301 |
DECAL.BADGE.170MM.TEXTLOGO. This part replaces 532429196. Price: $11.99 |
| 16 |
632164 |
FUEL FITTING Price: $5.95 |
| 17 |
532430523 |
DECAL.RPL. Price: $2.99 |
| 17 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 20 |
631838 |
ADJ SCREW Price: $2.71 |
| 21 |
630766 |
SPRING Price: $1.25 |
| 22 |
630739 |
WASHER Price: $1.25 |
| 23 |
630740 |
O RING Price: $1.49 |
| 25 |
631867 |
FLOAT BOWL Price: $2.34 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
632816 |
FLOAT This part replaces 632802. Price: $5.90 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 40 |
31839 |
POWER SCREW Price: $10.89 |
| 41 |
630740 |
O RING Price: $1.49 |
| 42 |
630739 |
WASHER Price: $1.25 |
| 43 |
630738 |
SPRING Price: $1.25 |
| 44 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
| 532439681 |
PAD.FOOT.LH.HUSQ.ERGO.LT.GREY |
This part replaces 532410805. Price: $8.99 532439681 |
| 532439682 |
PAD.FTRST.RH.PCH.ERGO.LT.498 |
This part replaces 532410806. Price: $6.99 532439682 |
| 581724801 |
DECAL.BYPASS.FENDER.CRD/LT/YT |
This part replaces 532166960. Price: $3.99 581724801 |
