WHEELS & TIRES
Parts (19)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 3296-60 | NUT-LOCK, NI Price: $5.08 |
| 2 | 120-5576 | WASHER-HARDENED Price: $3.91 |
| 2 | 544114301 | RIM Price: $89.99 |
| 3 | 104-3546 | PULLEY-DRIVEN, LOW Price: $163.56 |
| 3 | 535460001 | TIRE Price: $69.99 |
| 4 | 506574301 | VALVE Price: $4.99 |
| 5 | 106-7159 | O-RING Price: $0.99 |
| 5 | 523012602 | WHEEL This part replaces 544126301. Price: $159.99 |
| 6 | 119-4777 | SPINDLE ASM Price: $294.55 |
| 6 | 523034801 | RIM This part replaces 544114201. Price: $89.99 |
| 7 | 138-6416 | SPACER-SPINDLE, SHAFT This part replaces 69-6950. Price: $18.44 |
| 7 | 535460001 | TIRE Price: $69.99 |
| 8 | 506574301 | VALVE Price: $4.99 |
| 9 | 506504803 | WASHER Price: $3.99 |
| 10 | 506596201 | SPACER Price: $2.99 |
| 11 | 506504805 | WASHER Price: $3.99 |
| 12 | 506899001 | RETAINING RING Price: $2.99 |
| 13 | 544353501 | HUB CAP Price: $6.99 |
| 14 | 544353502 | HUB CAP Price: $7.99 |
