| Ref | Part Number | Description |
|---|
| 1 |
98-9321 |
RING-KEY Price: $1.80 |
| 2 |
98-9316 |
LATCH-HOOD Price: $61.25 |
| 3 |
299819 |
SEAL, OIL Price: Call Us |
| 3 |
98-9315 |
LATCH-LOCKING Price: $117.46 |
| 4 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 5 |
65-5100 |
HANDLE-DOOR Price: $9.05 |
| 6 |
46-8091 |
SCREW-HWH Price: $3.59 |
| 7 |
237-141 |
GROMMET-RUBBER Price: $2.39 |
| 7 |
272916 |
GASKET, CYLINDER HEAD Price: Call Us |
| 8 |
98-9746 |
HOOD ASM Price: $1,782.58 |
| 9 |
272481 |
GASKET, VALVE COVER Price: Call Us |
| 9 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 9A |
272238 |
GASKET, BAFFLE PLATE Price: Call Us |
| 10 |
321-4 |
SCREW-HH Price: $0.99 |
| 11 |
98-9314 |
GROMMET Price: $15.98 |
| 12 |
133-8095 |
DECAL-CE This part replaces 93-7252. Price: $3.73 |
| 12 |
272198 |
GASKET, CRANKCASE Price: Call Us |
| 13 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 14 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 15 |
75-0570 |
CABLE-HOOD Price: $16.66 |
| 16 |
98-4573-03 |
SCREEN-HOOD, REAR Price: $74.71 |
| 17 |
106-7062 |
DECAL Price: $52.78 |
| 18 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 19 |
321-39 |
SCREW-HH Price: $0.42 |
| 20 |
399781 |
SEAL, OIL Price: Call Us |
| 20 |
66-6140 |
DECAL Price: $25.48 |
| 21 |
92-5751 |
DECAL-HOOD, LH Price: $34.66 |
| 22 |
92-5752 |
DECAL-HOOD, RH Price: $34.66 |
| 23 |
63-6900-01 |
LH HOOD HINGE PLATE ASM Price: $23.15 |
| 24 |
63-6890-01 |
RH HOOD HINGE PLATE ASM Price: $12.36 |
| 25 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 26 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 28 |
93-0081 |
STRIP-SEAL Price: $73.83 |
| 52 |
272199 |
GASKET, INTAKE ELBOW Price: Call Us |
| 81 |
223664 |
LOCK, MUFFLER SCREW Price: Call Us |
| 104 |
231371 |
PIN, FLOAT HINGE Price: Call Us |
| 121 |
493762 |
CARB OVERHAUL KIT Price: Call Us |
| 134 |
398188 |
VALVE, INLET Price: Call Us |
| 163 |
272653 |
GASKET AIR CLEANER Price: Call Us |
| 187 |
492790 |
HOSE, FUEL Price: Call Us |
| 188A |
94644 |
SCREW, HEX HEAD Price: Call Us |
| 201 |
262579 |
LINK, GOVERNOR Price: Call Us |
| 209 |
263044 |
SPRING, GOVERNOR Price: Call Us |
| 300 |
496106 |
MUFFLER, EXHAUST Price: Call Us |
| 333 |
802574 |
ARMATURE, MAGNETO Price: Call Us |
| 334 |
94731 |
SCREW, SEMS Price: Call Us |
| 346 |
94602 |
SCREW, HEX HEAD Price: Call Us |
| 356 |
398808 |
WIRE, GROUND Price: Call Us |
| 358 |
497316 |
GASKET SET Price: Call Us |
| 524 |
280393 |
SEAL, FILLER TUBE Price: Call Us |
| 601 |
93807 |
CLAMP HOSE Price: Call Us |
| 613 |
94231 |
SCREW, HEX HEAD Price: Call Us |
| 617 |
270344 |
SEAL, FUEL INTAKE TUBE Price: Call Us |
| 620 |
497203 |
BRACKET, CARBURETOR Price: Call Us |
| 670A |
493823 |
SPACER, BRACKET Price: Call Us |
| 832 |
494224 |
GUARD MUFFLER Price: Call Us |
| 842 |
280966 |
SEAL, O-RING Price: Call Us |
| 851 |
493880 |
TERMINAL, IGNITION CABLE Price: Call Us |
| 883 |
272253 |
GASKET, MUFFLER Price: Call Us |
| 493762 |
CARB |
OVERHAUL KIT Price: Call Us 493762 |
| 497316 |
GASKET |
SET Price: Call Us 497316 |
