| Ref | Part Number | Description |
|---|
| 1 |
530037793 |
Foam- Air Filter Price: $1.99 |
| 1 |
99-7984 |
KNOB-SOFT GRIP, PUSH-ON Price: $11.31 |
| 2 |
112-7695-03 |
HANDLE Price: $53.91 |
| 2 |
530016101 |
Nut Price: $1.99 |
| 3 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 3 |
530035526 |
Grommet-Carb Adjust Price: Call Us |
| 4 |
92-2651 |
WASHER Price: $1.83 |
| 5 |
112-0038 |
SPACER Price: $7.34 |
| 5 |
530049700 |
Carb. Adapter Price: $3.99 |
| 6 |
114-0621 |
ADAPTER ASM Price: $469.97 |
| 7 |
283-83 |
PIN-CLEVIS Price: $9.52 |
| 8 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 8 |
530012550 |
Cylinder This part replaces 530071412. Price: $17.99 |
| 9 |
323-10 |
SCREW-HH Price: $0.89 |
| 9 |
530016136 |
Clip-High Tension Lead Price: $1.99 |
| 10 |
112-7686 |
LATCH Price: $40.54 |
| 10 |
530016153 |
Screw Price: $1.99 |
| 11 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 12 |
530071835 |
Kit-Purge Bulb This part replaces 530047213. Price: $5.99 |
| 12 |
75-5270 |
SPACER-KNOB, SEAT This part replaces 99-2058. Price: $4.61 |
| 13 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 13 |
530015780 |
Screw Price: $1.99 |
| 14 |
144-7093 |
LINK ASM This part replaces 110-8105. Price: $105.96 |
| 14 |
530095646 |
Fuel Pick-up Ass’y. Price: $2.99 |
| 15 |
323-12 |
SCREW-HH Price: $1.14 |
| 15 |
530037652 |
Heat Insulator Price: $1.99 |
| 16 |
114-0652 |
PIN-LYNCH Price: $253.01 |
| 16 |
530052296 |
Assy. -Wire Harness Price: $4.99 |
| 17 |
323-7 |
SCREW-HH Price: $0.65 |
| 18 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 18 |
530047442 |
Strap-Ground Price: $1.99 |
| 19 |
530039198 |
Module- Ignition Price: $29.99 |
| 20 |
530015814 |
Screw Price: $1.99 |
| 22 |
530016132 |
Screw Price: $1.99 |
| 23 |
530036103 |
Screen-Spark Price: Call Us |
| 24 |
530037813 |
Diffuser-Muffler Price: $1.99 |
| 25 |
530069608 |
Gasket-Muffler Price: $5.99 |
| 26 |
530049870 |
Backplate-Muffler Price: $3.99 |
| 27 |
545113101 |
CRANKSHAFT ASSY This part replaces 530047062. Price: $54.99 |
| 28 |
530037935 |
Cap-Crankcase Price: $8.99 |
| 29 |
530056363 |
Assy.-Seal & Bearing Price: $11.99 |
| 31 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 32 |
545160401 |
Ring-Piston This part replaces 530038729. Price: $2.99 |
| 33 |
530069608 |
Gasket - Carb. Adapter Price: $5.99 |
| 34 |
530016187 |
Screw Price: $1.99 |
| 35 |
530016386 |
Screw Price: $5.99 |
| 36 |
530069608 |
Gasket - Carburetor Price: $5.99 |
| 38 |
530057480 |
Housing- Air Filter Price: $4.99 |
| 39 |
530031163 |
Wrench - Bar Price: $4.99 |
