| Ref | Part Number | Description |
|---|
| 1 |
182516X007 |
Bar, Weight Price: Call Us |
| 1 |
92-0460 |
ARM ASM Price: $161.20 |
| 2 |
166785 |
Nut, Hex Price: Call Us |
| 2 |
92-0465 |
NUT-PUSH Price: $2.72 |
| 3 |
72110510 |
Bolt, Carriage Price: Call Us |
| 3 |
92-0417 |
SPRING-EXT Price: $15.08 |
| 4 |
1049-P |
Clevis Pin Price: Call Us |
| 4 |
181083 |
Pulley, Impeller Price: Call Us |
| 5 |
188910 |
Bearing Assembly, Flange Price: Call Us |
| 5 |
3272-53 |
PIN-COTTER Price: $0.35 |
| 6 |
155377 |
Nut, Hex Flange 5/16-18 Price: Call Us |
| 6 |
92-0457-03 |
MOUNTING BRACKET ASM This part replaces 92-0457. Price: $54.53 |
| 7 |
180355 |
Bolt, Flat Head, Carriage 5/16-18 x 5/8 Price: Call Us |
| 7 |
33115-090 |
SCREW-HH Price: $13.76 |
| 8 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 8 |
72270505 |
Bolt, Carriage 5/16-18 x 5/8 Price: Call Us |
| 9 |
178820 |
Nut, Cage 3/8-16 Price: Call Us |
| 9 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 10 |
178827X428 |
Housing, Auger Price: Call Us |
| 10 |
92-0466 |
TUBE-SPACER Price: $16.68 |
| 11 |
178691X479 |
Bar, Scraper Price: Call Us |
| 11 |
321-4 |
SCREW-HH Price: $0.99 |
| 12 |
178675X008 |
Bracket, Corner Discharge Price: Call Us |
| 12 |
3211-9 |
SCREW-HH Price: $1.09 |
| 13 |
175322 |
Base, Discharge Chute Price: Call Us |
| 13 |
92-0455 |
BEARING Price: $33.93 |
| 14 |
19111507 |
Washer, Flat Price: Call Us |
| 14 |
3220-3 |
NUT-HJ Price: $0.28 |
| 15 |
10040500 |
Washer, Lock 5/16 Price: Call Us |
| 15 |
3296-42 |
NUT-LOCK, NI This part replaces 32146-17. Price: $0.28 |
| 16 |
74950512 |
Screw, Hex Head 5/16-18 x 3/4 Price: Call Us |
| 16 |
94-7572 |
END-TIE ROD, RH This part replaces 41704. Price: $31.99 |
| 17 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 18 |
179582 |
Screw, Hex Head 5/16 x 1 Price: Call Us |
| 18 |
92-0454-03 |
PLATE-CONTROL This part replaces 92-0454. Price: $23.69 |
| 19 |
73800400 |
Nut, Hex Lock 1/4-20 Price: Call Us |
| 19 |
94-7005-03 |
DISCONTINUED This part replaces 94-7005. Price: Call Us |
| 20 |
73800500 |
Nut, Hex Lock 5/16-18 Price: Call Us |
| 21 |
155415 |
Washer, Flat Price: Call Us |
| 21 |
92-0453 |
GUIDE-BEARING Price: $24.88 |
| 22 |
178777X479 |
Skid Plate, RH Price: Call Us |
| 22 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 23 |
179246 |
Washer, Nylon, Friction Price: Call Us |
| 23 |
3217-26 |
NUT-HEX Price: $0.25 |
| 24 |
72270506 |
Bolt, Carriage 5/16-18 x 3/4 Price: Call Us |
| 25 |
185600 |
Bolt, Shoulder Price: Call Us |
| 26 |
174658 |
Bearing, Auger Price: Call Us |
| 27 |
174697 |
Washer, Thrust, 1" Price: Call Us |
| 28 |
187494 |
Bolt, Shear Price: Call Us |
| 29 |
174762X479 |
Skid Plate, LH Price: Call Us |
| 30 |
178765X479 |
Auger Assembly, RH Price: Call Us |
| 31 |
178764X479 |
Auger Assembly, LH Price: Call Us |
| 32 |
174699 |
O-Ring Price: Call Us |
| 33 |
174700 |
Bushing, Flange 3/4 Price: Call Us |
| 34 |
174681 |
Washer, Thrust 3/4 Price: Call Us |
| 35 |
174684 |
Bearing, Thrust 3/4 Price: Call Us |
| 36 |
174660 |
Shaft, Impeller Price: Call Us |
| 37 |
174683 |
Washer, Thrust 5/8 Price: Call Us |
| 38 |
174686 |
Bushing, Flange 5/8 Price: Call Us |
| 39 |
150078 |
Screw, Hex Head 5/16-18 x 3/4 Price: Call Us |
| 40 |
86447 |
Plug, Case Price: Call Us |
| 41 |
174688 |
Housing, Gearbox, RH Price: Call Us |
| 42 |
174698 |
Seal, Oil Price: Call Us |
| 43 |
174701 |
Bushing, Flange, 1" Price: Call Us |
| 44 |
178879 |
Key, Square 1/4 x 1/4 x 7/8 Price: Call Us |
| 45 |
174659 |
Gear, Worm Price: Call Us |
| 46 |
174657 |
Shaft, Auger Price: Call Us |
| 47 |
174687 |
Housing, Gearbox, LH Price: Call Us |
| 48 |
175321X479 |
Impeller Assembly Price: Call Us |
| 49 |
74780426 |
Screw, Hex Head 1/4-20 x 1-5/8 Price: Call Us |
| 50 |
175311 |
Gasket, Gearbox Price: Call Us |
| 51 |
7836M |
Pin, Roll 3/16 x 1-1/8 Price: Call Us |
| 52 |
181160X479 |
Bar, Drift Cutter Price: Call Us |
| 53 |
155415 |
Washer, Flat Price: Call Us |
| 54 |
53847 |
Washer, Flat 1/4 Price: Call Us |
| 361011 |
DISCONTINUED |
Price: Call Us 361011 |
