| Ref | Part Number | Description |
|---|
| 1 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 2 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
70-7530 |
SPRING-COMPRESSION Price: $15.72 |
| 4 |
66-2720-03 |
VALVE LEVER ASM This part replaces 66-2720. Price: $56.12 |
| 5 |
233-39 |
KNOB-CONTROL Price: $16.12 |
| 6 |
63-7960 |
VALVE-LIFT Price: $636.36 |
| 7 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 8 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $24.99 |
| 9 |
237-65 |
O-RING Price: $2.50 |
| 10 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 11 |
237-22 |
O-RING Price: $2.43 |
| 12 |
66-3130 |
FITTING-SPECIAL Price: $76.51 |
| 13 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 14 |
66-8150 |
HOSE-HYDRAULIC Price: $15.32 |
| 15 |
66-8500 |
HYD HOSE ASM Price: $89.96 |
| 16 |
321-11 |
SCREW-HH Price: $0.36 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 18 |
76-4830-03 |
VALVE ROD ASM This part replaces 76-4830. Price: $38.97 |
| 19 |
283-16 |
PIN-CLEVIS Price: $2.37 |
| 20 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 21 |
3220-2 |
NUT-JAM Price: $0.50 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $24.99 |
| 22 |
282-27 |
CLEVIS-ADJ Price: $24.71 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 24 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 25 |
532198893 |
CABLE.START.RED.17.5". Price: $11.99 |
| 25 |
66-8190 |
HYDRAULIC HOSE ASM Price: $85.54 |
| 26 |
340-86 |
FITTING-TEE Price: $35.23 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
304-99 |
STEM-HOSE Price: $34.00 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
237-22 |
O-RING Price: $2.43 |
| 28 |
532198885 |
CABLE.BLACK.18"REAR.BA Price: $17.99 |
| 29 |
3272-23 |
PIN-COTTER Price: $0.28 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
27-4240 |
PIN-CYLINDER Price: $21.90 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 31 |
63-6630 |
HYD CYLINDER ASM Price: $683.92 |
| 32 |
328-7 |
SCREW-HH This part replaces 328-20. Price: $4.00 |
| 33 |
532140401 |
KEY MLD GEN DELTA Price: $5.99 |
| 33 |
66-8640 |
HYDRAULIC HOSE ASM Price: $104.12 |
| 34 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 35 |
340-70 |
NUT-LOCK Price: $2.10 |
| 36 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 37 |
63-7410 |
BRACKET-BULKHEAD Price: $9.20 |
| 38 |
321-4 |
SCREW-HH Price: $0.99 |
| 39 |
3272-31 |
PIN-COTTER Price: $1.58 |
| 40 |
532400449 |
HARNESS.IGN.CHASS.TEX.REAR.BAT Price: $32.99 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 532401763. Price: $19.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174651. Price: $24.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 71 |
532401098 |
HARNESS IGN. DASH Price: $69.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY This part replaces 532400725. Price: $4.99 |
| 101 |
532198317 |
PIGTAIL.MATNLK.NEW.HAR Price: $6.99 |
