| Ref | Part Number | Description |
|---|
| 1 |
462180 |
PUMP ASSY, RH - SZC This part replaces 483106. Price: Call Us |
| 2 |
462179 |
PUMP ASSY, LH - SZC This part replaces 483105. Price: Call Us |
| 3 |
482994 |
Hose Assembly, Wheel Motor SZC Price: Call Us |
| 4 |
48572-04 |
Fitting, 1/2" JIC x 1/2" O-Ring Price: Call Us |
| 5 |
48603-06 |
O-Ring Price: Call Us |
| 6 |
482266-01 |
Elbow, 90 Degree O-Ring 9/16-18 x 3/8 Hose Price: Call Us |
| 7 |
48136-13 |
Clamp, Hose .69 Max Dia. Price: Call Us |
| 9 |
481761-01 |
Elbow, 90 Degree JIC to O-Ring Price: Call Us |
| 10 |
48350-02 |
Elbow, 90 Degree 1/2 x 1/2" JIC to O-Ring Price: Call Us |
| 11 |
48938-02 |
O-Ring Bushing, 5/8" Price: Call Us |
| 12 |
424061 |
Control Lever, Pump Price: Call Us |
| 13 |
483123 |
Retainer, Pump Lever Price: Call Us |
| 14 |
04021-12 |
Nut, Center Lock 5/16-24 Price: Call Us |
| 15 |
483094 |
Cap, Oil Reservoir Price: Call Us |
| 17 |
04001-09 |
Bolt, Hex Head 5/16-18 x 1" Price: Call Us |
| 18 |
04030-03 |
Lockwasher, 5/16" Spring Price: Call Us |
| 19 |
04040-15 |
Flatwasher, 5/16-.375 x .875 x .083 Price: Call Us |
| 20 |
48462-01 |
Filter, Spin On Price: Call Us |
| 21 |
461828 |
Fuel Tank, L.H. SZC Price: Call Us |
| 22 |
482571 |
Bushing This part replaces 48309. Price: Call Us |
| 23 |
481602 |
Elbow, 90 Degree Price: Call Us |
| 25 |
483617 |
Fuel Hose, 1/4" I.D. Non-Perm (791DFI Fuel Return) This part replaces 48058. Price: Call Us |
| 26 |
482212 |
Valve, Fuel Shutoff Price: Call Us |
| 27 |
04001-08 |
Bolt, Hex Head 5/16-18 x 3/4" Price: Call Us |
| 28 |
04030-03 |
Lockwasher, 5/16 Price: Call Us |
| 29 |
04040-15 |
Flatwasher, 5/16-.375 x .875 x .083 Price: Call Us |
| 30 |
461971 |
FUEL TANK ASSY, RH - SZC This part replaces 461829. Price: Call Us |
| 32 |
482774 |
Gasket, Gas Tank Cap Price: Call Us |
