| Ref | Part Number | Description |
|---|
| 1 |
137-6111 |
FULL FRONT ROLLER ASM (3IN DIA)(22IN) This part replaces 110-9612-03. Price: $447.03 |
| 1 |
817060408 |
Screw, Hex Thd. Cut 1/4-20 x 1/2 (AYP part number) Price: $3.99 |
| 2 |
110-4053 |
SHAFT-ROLLER Price: $94.63 |
| 2 |
532132752 |
Control, Throttle (AYP part number) Price: $17.99 |
| 3 |
93-3007 |
SEAL-OIL Price: $4.46 |
| 4 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 4 |
532192334 |
SCREW.SOCKET HD.5/16-1 This part replaces 871070512. Price: $2.99 |
| 5 |
109966 |
BEARING-BALL Price: $14.99 |
| 5 |
810040500 |
Washer, Lock Heavy Helical Spring 5/16 (AYP part number) Price: $2.99 |
| 6 |
532272293 |
Gasket Eng 1 313 Id Tin Plated (AYP part number) This part replaces 532125593. Price: $7.99 |
| 6 |
93-1251 |
SEAL-INNER Price: $9.50 |
| 7 |
539990118 |
SLW 3/8 STD This part replaces 811050600. Price: $1.99 |
| 7 |
93-1252 |
SEAL-OUTER Price: $18.76 |
| 8 |
32120-62 |
RING-RETAINING Price: $4.29 |
| 8 |
532121094 |
Bolt, Shoulder 5/16 (AYP part number) Price: $2.99 |
| 9 |
253-70 |
SEAL-OIL Price: $6.52 |
| 9 |
531003379 |
WASHER This part replaces 819101216. Price: $2.99 |
| 10 |
810040400 |
Washer, Lock Hvy Hlcl Spring 1/4 (AYP part number) Price: $3.99 |
| 12 |
532137437 |
Muffler (AYP part number) Price: $179.99 |
| 13 |
532101326 |
Deflector, Muffler (AYP part number) Price: $4.01 |
| 14 |
532161464 |
SCREW.HEX.WS.HD.8-18 X 7/8 This part replaces 817030808. Price: $3.99 |
| 15 |
532137180 |
Arrester, Spark (Optional equipment) (AYP part number) Price: $129.99 |
| 17 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 (AYP part number) This part replaces 817490624. Price: $3.99 |
| 18 |
873510600 |
Nut, Hex Keps 3/8 (AYP part number) Price: $3.99 |
| 19 |
532002751 |
Clip, Insulated (AYP part number) This part replaces 532124996. Price: $2.42 |
