| Ref | Part Number | Description |
|---|
| 1 |
105-2917 |
INSTRUMENT PANEL ASM Price: $119.85 |
| 1 |
186093X428 |
Wheel, Steering Price: Call Us |
| 2 |
195968 |
Axle Asm., Front Price: Call Us |
| 2 |
98-9339 |
GAUGE-FUEL Price: $115.28 |
| 3 |
104-4065 |
HARNESS-WIRE, MAIN Price: $714.83 |
| 4 |
194743 |
Spindle Asm., LH Price: Call Us |
| 4 |
32128-30 |
NUT Price: $2.69 |
| 5 |
194744 |
Spindle Asm., RH Price: Call Us |
| 5 |
322-3 |
SCREW-HH Price: $0.79 |
| 6 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 6 |
6266H |
Bearing, Race Thrust Harden Price: Call Us |
| 7 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 7 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 8 |
12000029 |
Ring, Klip #T5304-75 Price: Call Us |
| 8 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 9 |
106-5190 |
BATTERY Price: $170.85 |
| 9 |
121232X |
Cap, Spindle Price: Call Us |
| 10 |
104-9497 |
CABLE-BATTERY, NEGATIVE Price: $75.01 |
| 11 |
95-8853 |
CABLE-BATTERY, POSITIVE Price: $95.21 |
| 12 |
24-6420-03 |
HOLDDOWN-BATTERY Price: $55.90 |
| 13 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 13 |
24-6390 |
STUD-HOLDDOWN, BATTERY Price: $19.83 |
| 14 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 14 |
3217-6 |
NUT-HEX Price: $1.19 |
| 15 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 15 |
73540600 |
Nut, Crown Lock 3/8-24 unf Price: Call Us |
| 16 |
194746 |
Shaft Steering Price: Call Us |
| 16 |
32103-2 |
NUT-WING Price: $0.68 |
| 18 |
120-2244 |
HOURMETER This part replaces 66-2950. Price: $48.06 |
| 19 |
112-6561 |
WARNING LIGHT ASM This part replaces 98-9306. Price: $121.84 |
| 19 |
194729 |
Plate Steering Price: Call Us |
| 20 |
199743X428 |
Boot, Steering Price: Call Us |
| 20 |
98-9308 |
GAUGE-TEMPERATURE Price: $112.90 |
| 21 |
100-8072 |
SWITCH Price: $94.07 |
| 21 |
186737 |
Adapter, Wheel Steering Price: Call Us |
| 22 |
104-2541 |
SWITCH ASM Price: $36.70 |
| 22 |
194845 |
Bushing, Strg. Blk Price: Call Us |
| 23 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 24 |
43-3990 |
CONTROL-THROTTLE Price: $49.39 |
| 25 |
3290-134 |
SCREW Price: $0.27 |
| 26 |
186095X428 |
Insert, Wheel Steering Price: Call Us |
| 26 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 27 |
105-0002-01 |
BRACKET-RELAY Price: $34.06 |
| 28 |
17000612 |
Screw 3/8-16 x 3/4 Price: Call Us |
| 28 |
70-1480 |
RELAY Price: $105.19 |
| 29 |
98-7611 |
CONTROLLER-GLOW This part replaces 107-9097. Price: $316.53 |
| 30 |
37-2690 |
CAPACITOR Price: $155.98 |
| 31 |
2412-74 |
R-CLAMP Price: $2.37 |
| 32 |
321-4 |
SCREW-HH Price: $0.99 |
| 33 |
32128-33 |
NUT-HF Price: $0.25 |
| 34 |
98-9321 |
RING-KEY Price: $1.80 |
| 35 |
194732 |
Gear, Sector Plate Price: Call Us |
| 45 |
19183812 |
Washer 9/16 ID x 2-3/8 OD 12 G Zin Price: Call Us |
| 50 |
73900600 |
Nut Lock 3/8-16 UNC Price: Call Us |
| 51 |
73940800 |
Nut Hex Jam Toplock 1/2-20 unf Price: Call Us |
| 53 |
188967 |
Washer Hardened .793 x 1.637 x .060 Price: Call Us |
| 54 |
74760636 |
Bolt Hex 3/8-16 UNC x 2-1/4 Price: Call Us |
| 55 |
197636 |
Spacer Brace Axle Price: Call Us |
| 57 |
197246 |
Bracket Upstop Price: Call Us |
| 58 |
194747 |
Bolt Shoulder Sector Pivot CFM Price: Call Us |
| 59 |
194748 |
Washer Thrust Sector Steering Price: Call Us |
| 60 |
73971000 |
Nut Flange Lock 5/8-11 Price: Call Us |
| 61 |
194740 |
Draglink LH Price: Call Us |
| 62 |
194741 |
Draglink, RH Price: Call Us |
| 63 |
17060512 |
Screw 5/16-18 x 3/4 Price: Call Us |
| 64 |
199849 |
Retainer Clip Spring Steering Price: Call Us |
| 65 |
194734 |
Brace Axle Front Price: Call Us |
| 66 |
71020748 |
Bolt Hex Fghd 7/16-14 x 3 Serr Price: Call Us |
| 67 |
194737 |
Bushing PM Front Axle Price: Call Us |
| 68 |
73900700 |
Nut Lock Flange 7/16-14 Gr. 5 Price: Call Us |
| 69 |
199162 |
Washer 1.5 x .505 x .118 Price: Call Us |
