| Ref | Part Number | Description |
|---|
| 3 |
04041-07 |
FLATWASHER, 3/8" SPECIAL(.391 X .938 X .105) Price: Call Us |
| 4 |
04029-03 |
WING NUT, 3/8-16 Price: Call Us |
| 5 |
48584 |
ANTI-SCALP WHEEL Price: Call Us |
| 6 |
04001-79 |
BOLT, HEX HEAD 5/8-11 X 4-1/2" Price: Call Us |
| 7 |
461086 |
Anti-Scalp Wheel Assembly This part replaces 42882. Price: Call Us |
| 8 |
04017-27 |
BOLT, HEX SERRATED FLANGE 3/8-16 X 1" Price: Call Us |
| 9 |
04040-10 |
FLATWASHER, 5/8"(.688 X 1.75 X .134) Price: Call Us |
| 10 |
04021-13 |
NUT, HEX ELASTIC STOP 5/8-11 Price: Call Us |
| 12 |
04001-09 |
BOLT, HEX HEAD 5/16-18 X 1" Price: Call Us |
| 13 |
04021-10 |
NUT, HEX ELASTIC STOP 5/16-18 Price: Call Us |
| 14 |
04017-16 |
BOLT, HEX SERRATED FLANGE 5/16-18 X 3/4" Price: Call Us |
| 16 |
45037 |
IDLER PIVOT BASE Price: Call Us |
| 17 |
04001-46 |
BOLT, HEX HEAD 3/8-16 X 2-1/4" Price: Call Us |
| 18 |
48100-05 |
BUSHING Price: Call Us |
| 19 |
481035 |
NUT, SPECIAL 1-1/16-18 Price: Call Us |
| 20 |
04019-03 |
NUT, HEX SERRATED FLANGE 5/16-18 Price: Call Us |
| 21 |
46081 |
IDLER ARM(INCLUDES BUSHINGS & GREASE Price: Call Us |
| 22 |
43077 |
SPACER Price: Call Us |
| 24 |
04021-09 |
NUT, HEX ELASTIC STOP 3/8-16 Price: Call Us |
| 25 |
48114-04 |
GREASE FITTING Price: Call Us |
| 26 |
04041-08 |
FLATWASHER, 3/4" Price: Call Us |
| 26 |
04041-08S |
FLATWASHER, 3/4" SPECIAL Price: Call Us |
| 27 |
04050-02 |
RING, RETAINING 3/4" EXTERNAL "E" Price: Call Us |
| 28 |
48181 |
PULLEY, IDLER Price: Call Us |
| 29 |
43297 |
SPINDLE BUSHING, BOTTOM Price: Call Us |
| 31 |
48926 |
TAPERED HUB, 1-1/8 BORE Price: Call Us |
| 32 |
04001-01 |
BOLT, HEX HEAD 1/4-20 X 3/4" Price: Call Us |
| 33 |
04001-41 |
BOLT, HEX HEAD 5/8-11 X 9-1/2" Price: Call Us |
| 35 |
04001-23 |
BOLT, HEX HEAD 3/8-16 X 4-1/2" Price: Call Us |
| 36 |
483210 |
Pulley, 5" Idler This part replaces 48550. Price: Call Us |
| 39 |
04041-12 |
FLATWASHER, 3/8"(.375 X 1.5 X .06) Price: Call Us |
| 40 |
48807 |
SPRING, IDLER TENSION Price: Call Us |
| 41 |
48100-02 |
BUSHING Price: Call Us |
| 43 |
45329 |
IDLER PIVOT BASE Price: Call Us |
| 44 |
04001-97 |
BOLT, HEX HEAD 5/8-11 X 3" Price: Call Us |
| 46 |
04020-16 |
NUT, HEX 5/8-18 UNF Price: Call Us |
| 47 |
48763 |
ROD END Price: Call Us |
| 48 |
461516 |
Push Arm This part replaces 46460. Price: Call Us |
| 49 |
48100-06 |
BUSHING Price: Call Us |
| 50 |
451240 |
Push Arm Shaft This part replaces 45332. Price: Call Us |
| 51 |
461663 |
Spindle Assembly This part replaces 46631. Price: Call Us |
| 52 |
43589 |
Shaft, Spindle This part replaces 43298. Price: Call Us |
| 53 |
481024 |
SEAL, TOP Price: Call Us |
| 54 |
481022 |
BEARING ASSEMBLY(1 REQUIRED PER SPINDLE) Price: Call Us |
| 55 |
48667 |
RELIEF FITTING, TAPERED SPINDLE Price: Call Us |
| 56 |
43644 |
Spindle Housing This part replaces 43294. Price: Call Us |
| 57 |
481025 |
SEAL, BOTTOM Price: Call Us |
| 58 |
43312 |
SPACER, OUTSIDE Price: Call Us |
| 59 |
43296 |
SPACER, INSIDE Price: Call Us |
| 60 |
04063-08 |
KEY, 1/4 X 1/4 X 2" Price: Call Us |
| 61 |
04001-10 |
BOLT, HEX HEAD 5/16-18 X 1-1/4" Price: Call Us |
| 62 |
43590 |
Spacer, Spindle Bottom This part replaces 43309. Price: Call Us |
| 64 |
482245 |
Spring, Discharge Chute This part replaces 481050. Price: Call Us |
| 65 |
461074 |
CLUTCH ASSEMBLY This part replaces 48786. Price: Call Us |
| 66 |
04001-108 |
BOLT, HEX HEAD 5/16-18 X 4.25" Price: Call Us |
| 68 |
482744 |
Pulley, 5.75 OD Taper Bore This part replaces 48924. Price: Call Us |
| 69 |
04001-109 |
BOLT, HEX HEAD 1/4-20 X 1.375 FULL THREAD Price: Call Us |
