| Ref | Part Number | Description |
|---|
| 1 |
8-1280-01 |
REAR CROSS CHANNEL ASM Price: $998.35 |
| 1 |
817060408 |
SCREW Price: $4.99 |
| 2 |
37-2760-01 |
PIN-LIFT, BAIL Price: $89.10 |
| 2 |
532132752 |
CONTROL.TH/CH.RH.BLK.FLG.26 Price: $19.99 |
| 3 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 4 |
322-3 |
SCREW-HH Price: $0.79 |
| 4 |
596134201 |
Screws This part replaces 871070512. Price: $2.99 |
| 5 |
115-4947 |
HYD CYLINDER ASM (10.69 STROKE) Price: Call Us |
| 5 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 6 |
47-3990 |
DECAL Price: $19.68 |
| 6 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED Price: $8.99 |
| 7 |
47-3840 |
ELBOW-ORIFICE (.094) Price: $37.03 |
| 7 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 8 |
20-4390 |
SPACER Price: $12.54 |
| 8 |
532121094 |
BOLT T Price: $2.99 |
| 9 |
3-2196-01 |
SHEAVE Price: $141.72 |
| 9 |
734115441 |
WASHER - 26X6.5X1.6 This part replaces 819101216. Price: $0.99 |
| 10 |
325-18 |
SCREW-HH Price: $3.19 |
| 10 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 11 |
47-3500-01 |
CHANNEL BRACE ASM Price: $989.40 |
| 12 |
3-0136-01 |
CHAIN KEEPER ASM Price: $51.92 |
| 12 |
532137437 |
MUFFLER.SINGLE.B&S.12HP Price: $199.99 |
| 13 |
32153-5 |
NUT-HEX Price: $1.59 |
| 14 |
32128-23 |
NUT-HF Price: $1.51 |
| 14 |
532161464 |
SCREW.HEX.WS.HD.8-18 X 7/8 This part replaces 817030808. Price: $3.99 |
| 15 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 15 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 16 |
38-6200 |
SOCKET-SLOW MOVING VEHICLE Price: $21.04 |
| 17 |
47-3480-01 |
BRACKET-SMV Price: Call Us |
| 17 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 817490624. Price: $6.99 |
| 18 |
32128-20 |
NUT-HF Price: $0.99 |
| 19 |
47-3800-01 |
STRAP-LOCKING Price: $156.60 |
| 20 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 21 |
3290-274 |
RIVET-POP Price: $0.25 |
| 22 |
65-2710 |
PLATE-INFORMATION Price: $19.40 |
| 23 |
325-14 |
SCREW-HH Price: $2.64 |
| 24 |
3290-216 |
WASHER Price: $3.83 |
| 25 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 26 |
49-8170 |
SPACER Price: $27.34 |
| 27 |
3234-22 |
SCREW-HHF Price: $2.69 |
| 28 |
325-6 |
SCREW-HH Price: $1.42 |
| 29 |
3-0144 |
SHAFT Price: $53.89 |
| 39 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 532128861. Price: $2.99 |
