| Ref | Part Number | Description |
|---|
| 1 |
539111331 |
FAN COVER W/DECALS This part replaces 539106752. Price: $179.99 |
| 1 |
7-3900 |
PAD-BRAKE Price: $27.35 |
| 2 |
539106693 |
UPPER HOUSING Price: $141.99 |
| 2 |
93-8743 |
FOOTPAD-TURN This part replaces 27-7580. Price: $27.95 |
| 3 |
3218-5 |
NUT-JAM Price: $0.27 |
| 3 |
539109900 |
LOWER HOUSING This part replaces 539106706. Price: $149.99 |
| 4 |
21-2850-01 |
MOUNT-PEDAL, RH This part replaces 21-2850. Price: $69.64 |
| 4 |
539106786 |
BEARING KIT-2 PCS Price: $44.99 |
| 5 |
32144-102 |
SCREW-HWH This part replaces 11-0590. Price: $3.19 |
| 6 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 6 |
539110111 |
FAN WELDMENT This part replaces 539106707. Price: $179.99 |
| 7 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 7 |
539102691 |
BRG FLANGE Price: $3.99 |
| 8 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 8 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 9 |
539106711 |
SHEAVE FLOOR WELDMENT Price: $23.17 |
| 9 |
95-1821 |
SPRING-COMPRESSION This part replaces 3-3251. Price: $6.71 |
| 10 |
27-7660 |
DISCONTINUED Price: Call Us |
| 10 |
539106713 |
SHEAVE 4" Price: $54.99 |
| 11 |
233-17 |
KNOB Price: $10.58 |
| 11 |
596564401 |
Bolts This part replaces 539990563. Price: $3.99 |
| 12 |
539106715 |
IDLER ARM Price: $34.99 |
| 12 |
66-6190 |
DECAL - PARKING BRAKE Price: $6.35 |
| 13 |
3-7243 |
SPRING-EXTENSION Price: $11.23 |
| 13 |
539101836 |
BUSHING, SLEEVE Price: $2.99 |
| 14 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 14 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 15 |
108-1380 |
LH BRAKE CABLE ASM This part replaces 21-3380. Price: $162.33 |
| 15 |
596564404 |
Bolts This part replaces 539990629. Price: $2.99 |
| 16 |
23-2270 |
BUSHING-RUBBER Price: $17.07 |
| 16 |
539990655 |
HCS 3/8C X 1 1/2 Price: $3.99 |
| 17 |
23-2240-03 |
PUMP CONTROL TUBE ASM This part replaces 23-2240. Price: $209.72 |
| 17 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 18 |
28-5190 |
DISCONTINUED Price: Call Us |
| 18 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
| 19 |
28-5130 |
TRACTION PEDAL PAD Price: $33.21 |
| 19 |
595281301 |
Caps This part replaces 539102535. Price: $4.99 |
| 20 |
28-5240 |
DISCONTINUED Price: Call Us |
| 20 |
596671401 |
Bolts This part replaces 539100472. Price: $3.99 |
| 21 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 21 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 22 |
28-5210 |
TRACT PEDAL SHAFT Price: $48.49 |
| 22 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 23 |
28-5160-01 |
DISCONTINUED This part replaces 28-5160. Price: Call Us |
| 23 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 539990799. Price: $2.99 |
| 24 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 24 |
595901501 |
Bolts This part replaces 539990208. Price: $3.99 |
| 25 |
28-5220 |
FRICTION WHEEL ASM Price: $108.15 |
| 25 |
539990362 |
SCREW 1/4 X 5/8 Price: $3.99 |
| 26 |
539106721 |
PULLEY Price: $25.99 |
| 26 |
99-5686 |
RH SOCKET ASM This part replaces 21-0140. Price: $99.81 |
| 27 |
3220-5 |
NUT-JAM Price: $0.65 |
| 27 |
596238401 |
BOLT CUP HEAD SQUARE NECK BOLT This part replaces 539990074. Price: $2.99 |
| 28 |
3217-7 |
NUT-HEX Price: $0.28 |
| 28 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 29 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 29 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 30 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 30 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 31 |
3231-21 |
SCREW-CARR Price: $0.76 |
| 31 |
539106801 |
SPRING ROD WLDMNT Price: $99.99 |
| 32 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 32 |
539106720 |
SPRING Price: $22.99 |
| 33 |
3274-47 |
SCREW-HSFH Price: $0.53 |
| 33 |
539101050 |
GRIP Price: $2.99 |
| 34 |
27-7590-01 |
BRAKE MT WA This part replaces 27-7590. Price: $239.14 |
| 34 |
539990037 |
COTTER PIN 3/32 X 3/4 Price: $2.99 |
| 35 |
27-9270-01 |
PIVOT SHAFT MOUNT ASM This part replaces 27-9270. Price: $81.41 |
| 35 |
539100141 |
HCS 7/16F X 1 1/2 Price: $7.99 |
| 36 |
27-7640-01 |
SHAFT-BRAKE LATCH ASM This part replaces 27-7640. Price: $62.42 |
| 36 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 37 |
32149-2 |
NUT-KEPS Price: $2.39 |
| 37 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 38 |
539106810 |
CLAMP Price: $5.12 |
| 38 |
93-8743 |
FOOTPAD-TURN This part replaces 27-7570. Price: $27.95 |
| 39 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 39 |
539106809 |
BEARING PLATE - BLACK Price: $12.99 |
| 40 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 40 |
539106811 |
BELT GUIDE Price: $6.99 |
| 41 |
27-7490 |
LH BRAKE PEDAL ASM Price: $347.33 |
| 41 |
539106812 |
BACKING (BLACK) Price: $6.99 |
| 42 |
27-7510 |
RH BRAKE PEDAL ASM Price: $321.91 |
| 42 |
539102067 |
KEY 1/4 SQ X 3/4 Price: $2.99 |
| 43 |
256-10 |
BUSHING-FLANGE Price: $3.68 |
| 43 |
539106751 |
SUPPORT WELDMENT Price: $82.99 |
| 44 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 44 |
539106748 |
HOSE 7 X 82 CLEAR Price: $399.00 |
| 45 |
539097076 |
HOSE CLAMP 4-1/8 TO 7" Price: $6.99 |
| 46 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
