| Ref | Part Number | Description |
|---|
| 1 |
931-0220 |
Steering Wheel Cap This part replaces 731-0220. Price: $7.93 |
| 2 |
710-0643 |
Hex Bolt 5/16-18 x 1" Lg. Price: $5.99 |
| 3 |
736-0242 |
Belleville Wash. .345" I.D. Price: $3.75 |
| 9 |
783P08577A |
STABILIZER PLATE This part replaces 17198A. Price: $6.48 |
| 10 |
938-0141 |
SHOULDER SCREW .437 DIA x .350 Not Available This part replaces 738-0141. Price: |
| 11 |
710-1039 |
Hex Bolt 3/8-24 x 1" Lg. This part replaces 710-0152. Price: $4.02 |
| 13 |
950-0535 |
Spacer.380" I.D. x .625" O.D. x .227 This part replaces 750-0535. Price: $3.90 |
| 14 |
736-0217 |
L-Wash. 3/8" I.D. (H.D.) Price: $3.86 |
| 15 |
710-0726 |
Hex Wash. Hd. Self-Tap Scr. Price: $3.82 |
| 16 |
911-1107 |
Steering Drag Link Not Available This part replaces 711-1107. Price: |
| 18 |
738-0527 |
Shoulder Bolt Price: $7.90 |
| 19 |
912-0431 |
Flange Lock Nut 3/8-16 This part replaces 7120431. Price: $4.29 |
| 21 |
712-0411 |
Hex L-Nut 5/16-24 Thd. Price: $3.71 |
| 22 |
983-0055-0637 |
Steering Arm Front Axle This part replaces 16481A. Price: $41.85 |
| 23 |
710-0772 |
Hex Bolt 5/16-24 x 2.00" Lg. Price: $3.93 |
| 24 |
941-0659 |
Hex Flg. Brg. .632 I.D. This part replaces 741-0659. Price: $4.80 |
| 25 |
683-0128B-0637 |
Pivot Axle - Powder Black This part replaces 683-0128. Price: $85.22 |
| 26 |
983-0127 |
Front Axle Ass'y. - L.H. This part replaces 683-0127. Price: $89.45 |
| 27 |
712-0241 |
Hex Nut 3/8-24 Thd. Price: $3.86 |
| 28 |
736-0169 |
L-Wash. 3/8" I.D. Price: $3.33 |
| 29 |
923-3018 |
Ball Joint, 3/8-24 This part replaces 723-3018. Price: $15.50 |
| 30 |
747-0753 |
Tie Rod (Adjustable) Price: $29.86 |
| 31 |
712-0711 |
Hex Jam Nut 3/8-24 Thd. Price: $3.90 |
| 32 |
983-0126 |
AXLE ASSEMBLY (RH) SHORT Not Available This part replaces 683-0126. Price: |
| 33 |
634-0056B-0911 |
Wheel Ass'y. Comp. This part replaces 634-0056. Price: $218.84 |
| 34 |
753-0838-0662 |
WHEEL RIM GREY Not Available This part replaces 634-0024. Price: |
| 35 |
741-0487C |
Flange Bearing .632 ID This part replaces 741-0487A. Price: $6.87 |
| 36 |
736-0285 |
Fl-Wash. .635 I.D. x 1.59" O.D. Price: $3.89 |
| 37 |
931-0484A |
Hub Cap This part replaces 731-0484A. Price: $5.98 |
| 38 |
714-0470 |
Cotter Pin 1/8" Dia. x 1.25" Price: $3.90 |
| 39 |
736-04088 |
Flat Washer, .635 x 1.24x x.181 This part replaces 736-0531. Price: $3.90 |
| 40 |
726-0214 |
Push Cap 5/8" Dia. Rod Price: $9.11 |
| 42 |
712-0262 |
Hex Jam Nut 3/8-24 Thd. Price: $3.90 |
| 43 |
710-1309 |
Hex Patch Bolt 5/16-18 x .62" Price: $3.86 |
| 44 |
N/A |
UNKNOWN |
| 46 |
948-0389 |
Cap, 1.25 x .16 This part replaces 748-0389. Price: $4.40 |
| 47 |
712-0214 |
Hex Cent. L-Nut 3/8-24 Thd. Price: $5.94 |
| 48 |
736-0169 |
L-Wash. 3/8" I.D. Price: $3.33 |
| 49 |
912-0158 |
Hex Cent. L.-Nut 5/16-18 Thd. This part replaces 712-0158. Price: $2.83 |
| 50 |
936-0119 |
Lock Wash. 5/16" I.D. This part replaces 736-0119. Price: $4.29 |
| 51 |
717-0622C |
Steering Gear Segment Not Available This part replaces 717-0622A. Price: |
| 52 |
941-0656A |
BRG:HEX FLNG 5/8 This part replaces 741-0656. Price: $4.69 |
| 53 |
736-0187 |
Fl-Wash. (Hardened) Price: $4.02 |
| 54 |
738-0919B |
Steering Shaft This part replaces 738-0919. Price: $51.87 |
| 58 |
936-0271 |
SPRING WASHER .317 X .625 X .020 This part replaces 736-0271. Price: $3.93 |
| 59 |
736-0187 |
Fl-Wash. (Hardened) Price: $4.02 |
| 60 |
923-0448A |
Ball Joints This part replaces 723-0448. Price: $22.55 |
| 61 |
N/A |
UNKNOWN |
| 64 |
936-0356 |
BELL WASHER Not Available This part replaces 736-0356. Price: |
| 66 |
710-0459A |
Hex Cap Screw 3/8-24 x 1.5 This part replaces 710-0459. Price: $6.50 |
| 69 |
731-1649 |
STANDARD AXLE CAP Not Available Price: |
