| Ref | Part Number | Description |
|---|
| 1 |
3296-68 |
NUT-LOCK, NI Price: $14.67 |
| 1 |
539111376 |
DECK W/DECALS 48" HUS Price: $3,299.99 |
| 2 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 2 |
539103295 |
IDLER BUSHING Price: $12.99 |
| 3 |
539101341 |
HCS 3/8C X 3 Price: $4.99 |
| 3 |
71-2570 |
SHAFT-PIVOT Price: $431.51 |
| 4 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 4 |
69-7940-01 |
SUPPORT-LIFT ARM, RH This part replaces 69-7940. Price: $234.45 |
| 6 |
237-42 |
O-RING Price: $2.78 |
| 6 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 7 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 7 |
92-4971 |
CYLINDER-HYD Price: $718.13 |
| 8 |
237-22 |
O-RING Price: $2.43 |
| 8 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 9 |
539976941 |
HCS 3/8C X 1 1/4 GR5 Price: $3.99 |
| 9 |
69-8440 |
HOSE ASM Price: $53.07 |
| 10 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 11 |
539103256 |
SPRING Price: $9.99 |
| 11 |
72-4310 |
SWITCH-BALL Price: $84.47 |
| 12 |
69-5440 |
HOSE ASM Price: $73.25 |
| 12 |
966956101 |
KIT HSG ASM 52/61 This part replaces 539112934. Price: $129.99 |
| 13 |
340-70 |
NUT-LOCK Price: $2.10 |
| 13 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 14 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 14 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 15 |
539100340 |
BLADE OEM 16 1/4" Price: $22.99 |
| 15 |
98-7346 |
SPACER This part replaces 69-9190. Price: $30.67 |
| 16 |
20-4360-03 |
SPACER This part replaces 20-4360. Price: $8.01 |
| 16 |
539103299 |
HCS 5/8F X 1 1/4 Price: $5.99 |
| 17 |
539990333 |
LOCKWASHER 5/8 Price: $2.99 |
| 17 |
69-9180 |
PIN-CYLINDER Price: $25.38 |
| 18 |
3272-23 |
PIN-COTTER Price: $0.28 |
| 18 |
539112141 |
PULLEY 42-48 Price: $37.99 |
| 19 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 19 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 20 |
32153-6 |
NUT-LOCK Price: $3.46 |
| 20 |
539112120 |
HCS 7/16-20 GD 8 SPEC Price: $24.99 |
| 21 |
328-10 |
SCREW-HH Price: $14.93 |
| 21 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 22 |
325-6 |
SCREW-HH Price: $1.42 |
| 22 |
539990839 |
NUT 7/16C CENTERLOCK Price: $2.99 |
| 23 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 23 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 24 |
596770301 |
Washers This part replaces 539103303. Price: $4.99 |
| 24 |
71-2590 |
SHAFT-PIVOT Price: $228.41 |
| 25 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 26 |
3217-9 |
NUT-HH Price: $0.37 |
| 27 |
539111812 |
DECAL, TUNNEL RAM 6" Price: $11.99 |
| 27 |
69-7920-01 |
SUPPORT-LIFT ARM, LH This part replaces 69-7920. Price: $214.14 |
| 28 |
256-304 |
WASHER-THRUST Price: $3.94 |
| 28 |
539114405 |
SWIVEL Price: $14.99 |
| 29 |
539114404 |
SPACER Price: $6.99 |
| 29 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 30 |
111-1290 |
ENGINE - KUBOTA V1505-E2B-HAYTER-1 This part replaces 92-4806. Price: $3,715.61 |
| 30 |
539119227 |
BOLT, EYE Price: $14.99 |
| 31 |
32120-47 |
RING-RETAINING, EXTERNAL Price: $0.99 |
| 31 |
539114698 |
EYEBOLT, 1/2-13 X 5.88 Price: $22.99 |
| 32 |
595316401 |
Washers This part replaces 539109554. Price: $2.99 |
| 32 |
69-8470-03 |
SPRING-TORSION This part replaces 69-8470. Price: $92.60 |
| 33 |
596438501 |
Bolts This part replaces 539108073. Price: $2.99 |
| 33 |
76-1670-03 |
SPRING-EXTENSION This part replaces 76-1670. Price: $24.92 |
| 34 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 34 |
69-1540-03 |
PIVOT-SPRING, TORSION This part replaces 69-1540. Price: $122.27 |
| 35 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 35 |
595316401 |
Washers This part replaces 539990550. Price: $2.99 |
| 36 |
32136-2 |
NUT-SHH Price: $3.55 |
| 36 |
539109246 |
PIN COTTER 1/8 X 1 ZD Price: $4.99 |
| 37 |
539108450 |
TOP DUST CAP Price: $4.99 |
| 37 |
86-8100-01 |
BALL JOINT ASM This part replaces 86-8100. Price: $137.53 |
| 38 |
21-3000-01 |
NUT-JAM, PUSH ARM This part replaces 21-3000. Price: $37.02 |
| 38 |
596917301 |
Washers This part replaces 539111897. Price: $4.99 |
| 39 |
532133957 |
WHEEL GAGE DONUT This part replaces 539107610. Price: $11.99 |
| 39 |
69-9580 |
LH FRONT LIFT ARM ASM Price: $1,165.75 |
| 40 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 40 |
539108366 |
HCS 1/2-13 X 4 GR 5 ZD This part replaces 539118862. Price: $5.99 |
| 41 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 41 |
539990258 |
NUT HEX 1/2 Price: $3.99 |
| 42 |
539130778 |
CHUTE, RUBBER DISCHARGE 42/48" Price: $64.99 |
| 43 |
539130923 |
PIVOT BRACKET - RUBBER CHUTE Price: $37.99 |
| 44 |
539130925 |
BRACKET, REINF-CHUTE Price: $139.99 |
| 45 |
539131813 |
PIN, CHUTE PIVOT Price: $6.99 |
| 46 |
596030801 |
Bolts This part replaces 539102933. Price: $3.99 |
| 47 |
596671401 |
Bolts This part replaces 539100472. Price: $3.99 |
| 48 |
539130391 |
ARM-IDLER W/BRG Price: $37.99 |
| 49 |
596581801 |
Bolts This part replaces 539130235. Price: $2.99 |
| 50 |
539107042 |
HCS 3/8-16 X 1-1/2 Price: $2.99 |
| 51 |
596433501 |
NUT NUT.3/8-16.HEX.JAM.Z 3/8-1 This part replaces 539109332. Price: $2.99 |
| 52 |
539130242 |
BUSHING, IDLER Price: $2.99 |
| 53 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
| 54 |
539114823 |
CAP, VINYL Price: $2.99 |
| 55 |
539130205 |
PIVOT, BEARING Price: $3.99 |
| 56 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 57 |
539108449 |
BOTTOM DUST CAP Price: $3.99 |
| 58 |
539108754 |
SHAFT SEAL Price: $6.99 |
| 59 |
539977326 |
PLUG-VENTED Price: $8.99 |
| 60 |
539109660 |
DRAW LATCH Price: $13.99 |
