| Ref | Part Number | Description |
|---|
| 1 |
110-4750 |
DRIVE AXLE ASM Price: $8,909.28 |
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 2 |
340-126 |
NUT-BULKHEAD Price: $4.61 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT This part replaces 532172393. Price: $119.99 |
| 3 |
240-2 |
GROMMET-RUBBER Price: $20.20 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
120-9069-03 |
PLATE-MOUNT, BULKHEAD Price: $33.45 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 5 |
43-0090 |
SCREW-HH Price: $8.05 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 8 |
92-5836 |
WASHER Price: $5.34 |
| 9 |
100-3796 |
SPACER-JOINT, BALL Price: $13.33 |
| 10 |
32136-14 |
NUT-HST Price: $3.38 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 11 |
353-989 |
PLUG-HEX, HOLLOW Price: $21.59 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
93-5268 |
NUT-LUG Price: $2.20 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
74-5700 |
BEARING-NEEDLE, ROLLER Price: $27.84 |
| 15 |
32120-15 |
RING-SNAP, EXT Price: $1.20 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 16 |
100-3053 |
GEAR-45 TOOTH Price: $220.85 |
| 17 |
106-1140 |
GASKET Price: $17.66 |
| 17 |
532407600 |
KIT.RPLMNT.SHAFT.STRG. This part replaces 532177876. Price: $59.99 |
| 18 |
104-2353 |
PIN-DOWEL Price: $2.17 |
| 19 |
95-7541 |
PLATE-COVER Price: $89.04 |
| 20 |
32120-76 |
RING-SNAP, EXT Price: $0.34 |
| 21 |
104-0755 |
PINION-27 TOOTH Price: $168.40 |
| 22 |
237-166 |
O-RING Price: $10.46 |
| 23 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 24 |
325-7 |
SCREW-HH Price: $1.53 |
| 25 |
120-8814 |
HYD MOTOR ASM Price: $2,731.96 |
| 26 |
33114-025 |
SCREW-HH Price: $0.70 |
| 27 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 28 |
121-1535 |
STEERING CYLINDER ASM Price: $1,109.52 |
| 29 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 30 |
3296-68 |
NUT-LOCK, NI Price: $14.67 |
| 31 |
92-1765 |
WASHER-THRUST Price: $2.57 |
| 32 |
325-6 |
SCREW-HH Price: $1.42 |
| 32 |
532171888 |
TIE ROD Price: $59.99 |
| 33 |
130-2744-03 |
MOUNT-REAR Price: $649.41 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 34 |
99-5107 |
NUT-LOCK Price: $1.77 |
| 35 |
145-8330 |
PIN-AXLE, REAR This part replaces 98-7077. Price: $192.04 |
| 35 |
873540500 |
NUT, CROWNLOCK Price: $3.99 |
| 36 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 37 |
99-8431 |
WASHER-THRUST Price: $4.63 |
| 38 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 39 |
819132411 |
Washer 13/32 x 1-1/20 x 11 Gauge Price: $2.99 |
| 40 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 41 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 42 |
532145054 |
STEERING BOOT, GRAY This part replaces 532169634. Price: $11.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
532153721 |
SHAFT EXT STEERING This part replaces 532153720. Price: $54.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 51 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 54 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 63 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE This part replaces 872140618. Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
