| Ref | Part Number | Description |
|---|
| 1 |
323-6 |
SCREW-HH Price: $0.66 |
| 1 |
952030249 |
Spark Plug (RCJ-6Y) Price: $3.99 |
| 1B |
31994 |
SHAFT & LEV Price: Call Us |
| 2 |
530015953 |
Screw Price: $1.99 |
| 2 |
650506 |
SCREW This part replaces 630606. Price: $0.87 |
| 2 |
94-2703 |
PLUG Price: $1.86 |
| 2A |
650506 |
SCREW This part replaces 630606. Price: $0.87 |
| 3 |
112-6967 |
O-RING Price: $2.70 |
| 3 |
31995 |
SHUTTER Price: Call Us |
| 3 |
530055191 |
Insulator-Heat Price: $1.99 |
| 4 |
120-5118 |
SHAFT-ADJUSTER Price: $44.64 |
| 4 |
530055240 |
Screw Price: $1.99 |
| 4A |
631499 |
SHAFT & LEV Price: Call Us |
| 5 |
106-5344 |
BUSHING-FLANGE, KEYED Price: $2.37 |
| 5 |
530055241 |
Deflector-Muffler Price: $3.99 |
| 6 |
650399 |
SCREW This part replaces 630605. Price: $1.20 |
| 6 |
99-2097 |
DETENT Price: $12.71 |
| 7 |
114-9396 |
CAPSCREW-HH Price: $2.22 |
| 7 |
27112 |
IDLE SCREW Price: $1.26 |
| 7 |
530016369 |
Bolt-Muffler-external Price: $1.99 |
| 8 |
120-5116 |
WASHER-WAVE Price: $9.17 |
| 8 |
27114 |
SPRING Price: $2.62 |
| 8 |
530016341 |
Screw-Muffler-Internal Price: $0.08 |
| 9 |
108-0015 |
WASHER-FLAT Price: $0.39 |
| 9 |
31503 |
SPRING Price: $1.23 |
| 10 |
137-6130 |
SCREW-ADJUSTER, BEDBAR This part replaces 115-7039. Price: $25.42 |
| 10 |
30927 |
SHUTTER Price: Call Us |
| 10 |
530071458 |
Gasket-Baffle (kit) Price: $5.99 |
| 11 |
119-4155 |
WASHER-HARDENED Price: $4.16 |
| 11 |
27109 |
GASKET Price: $1.18 |
| 11 |
530071458 |
Gasket-Cylinder (kit) Price: $5.99 |
| 12 |
120-5120 |
SPRING-COMPRESSION Price: $2.89 |
| 12 |
27108 |
GASKET Price: Call Us |
| 12 |
530071457 |
Kit-Cylinder Price: $11.99 |
| 13 |
119-4039 |
NUT-HEX, NI Price: $0.28 |
| 13 |
32256A |
REPAIR KIT This part replaces 32255A. Price: $45.70 |
| 13 |
530019182 |
Grommet-Ign. Module Price: $1.99 |
| 14 |
27105 |
FLOAT Price: $20.00 |
| 14 |
530016357 |
Screw-Ignition Module Price: $1.99 |
| 15 |
112-8908-01 |
BEDBAR Price: $402.52 |
| 15 |
27106 |
FLOAT SHAFT Price: $2.04 |
| 15 |
530035505 |
Ignition Module Price: $29.99 |
| 16 |
119-4151 |
SCREW-BEDKNIFE Price: $0.41 |
| 16 |
27136A |
DRAIN ASSY Price: $5.96 |
| 17 |
147-1249 |
BEDKNIFE-RM 27IN STD This part replaces 114-9388. Price: $84.10 |
| 17 |
29170 |
FLOAT BOWL Price: Call Us |
| 17 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 18 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 19 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 20 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 20 |
530019264 |
Seal-Crankcase Price: $2.99 |
| 21 |
28945 |
POWER SCREW Price: $18.86 |
| 21 |
530055728 |
Bearing-Outer Price: $6.99 |
| 21 |
61-1950 |
WASHER-PLASTIC Price: $0.55 |
| 22 |
530015941 |
Retainer Ring-C'chaft Price: $1.99 |
| 22 |
56-9520 |
BUSHING-FLANGED Price: $2.15 |
| 22 |
630786 |
SPRING Price: $1.25 |
| 23 |
530016190 |
Spacer-Flywheel Price: $2.99 |
| 23 |
631695 |
NOZZLE Price: Call Us |
| 23 |
69-8980 |
WASHER Price: $0.58 |
| 24 |
106-9623 |
BOLT-BEDBAR Price: $18.27 |
| 24 |
27544 |
O RING Price: $1.26 |
| 24 |
530015149 |
Washer Price: $1.99 |
| 25 |
27554 |
GASKET Price: $1.05 |
| 25 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 25 |
530047534 |
FLYWHEEL ASSY This part replaces 530039209. Price: $22.99 |
| 26 |
323-12 |
SCREW-HH Price: $1.14 |
| 27 |
119-0614-01 |
WEIGHT-END Price: $98.48 |
| 27 |
32096 |
RET SPRING Price: $2.62 |
| 28 |
107-2954 |
NUT-ADJUSTER, BEARING Price: $17.63 |
| 28 |
530032125 |
Bearing-Inner Price: $11.99 |
| 29 |
530012452 |
Assy-Crankshaft Price: $24.99 |
| 29 |
93-2489 |
BEARING Price: $24.37 |
| 30 |
107-4028 |
SEAL-GREASE Price: $21.51 |
| 30 |
530071458 |
O-ring-C/case (kit) Price: $5.99 |
| 31 |
530012443 |
Cover-Crankcase Price: $5.99 |
| 32 |
137-8460 |
REEL+,FWY(27)8 BLD This part replaces 115-8275. Price: $843.92 |
| 32 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 33 |
530071459 |
Foam-219mm (kit) Price: $4.99 |
| 34 |
530029182 |
Eyelet-Flange Price: $1.99 |
| 35 |
530071467 |
Kit-Rope Price: $4.99 |
| 36 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 36 |
530049488 |
Handle-Starter Price: $1.99 |
| 37 |
530016326 |
Screw-Rope Price: $1.99 |
| 38 |
530016279 |
Washer-Flat Price: $1.99 |
| 39 |
530626605 |
Nut Price: $1.99 |
| 40 |
530402043 |
Spring-Return Cover Price: $2.99 |
| 41 |
530049313 |
Inlet Door Price: $4.99 |
| 42 |
530016240 |
Washer-Belleville Price: $1.99 |
| 43 |
530069817 |
Assy-Impeller Price: $12.99 |
| 44 |
530055106 |
Seal-Ring Price: $1.99 |
| 45 |
530016349 |
Screw Price: $1.99 |
| 46 |
530055101 |
Housing-Pulley Price: $6.99 |
| 47 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 48 |
545150201 |
PULLEY STARTER This part replaces 530071466. Price: $8.99 |
| 49 |
530055102 |
Fan Housing Price: $14.99 |
| 50 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 51 |
530071459 |
Foam-365mm (kit) Price: $4.99 |
| 52 |
530071458 |
Kit-Gasket Price: $5.99 |
