| Ref | Part Number | Description |
|---|
| 1 |
594056301 |
Studs This part replaces 539110607. Price: $2.99 |
| 1 |
703-2144 |
BULKHEAD, UPPER Not Available Price: |
| 1 |
99-1865 |
O-RING Price: $38.32 |
| 2 |
539110826 |
RT DRIVE LEVER WLDMT Price: $49.99 |
| 2 |
703-2142 |
BULKHEAD BRACKET Not Available Price: |
| 2 |
99-2182 |
O-RING Price: $5.07 |
| 3 |
539110827 |
LT DRIVE LEVER WLDMT Price: $49.99 |
| 3 |
710-3039 |
SCREW 5/16-18 x .50 GR5 Not Available Price: |
| 3 |
98-7375 |
GASKET-NOZZLE Price: $11.91 |
| 4 |
539131932 |
DAMPENER W/EXT SEAL This part replaces 539110606. Price: $74.99 |
| 4 |
68-6430 |
GASKET Price: $2.82 |
| 4 |
736-0242 |
Washer, Bell, .345 x .88 x .060 Thk Price: $3.75 |
| 5 |
107-4814 |
O-RING This part replaces 99-1878. Price: $5.67 |
| 5 |
539102592 |
GRIP Price: $7.99 |
| 6 |
539111074 |
DAMPENER BRACKET Price: $7.99 |
| 6 |
710-3013 |
Screw, Hex Cap, 1/4-20 x .50 Lg GR5. Price: $4.02 |
| 6 |
99-1853 |
SEAL-SIDE Price: $4.04 |
| 7 |
51-7210 |
GASKET Price: $8.57 |
| 7 |
539102519 |
BUSHING Price: $2.99 |
| 7 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 8 |
539101080 |
SWITCH, INTERLOCK Price: $14.99 |
| 8 |
712-3006 |
HEX NUT Price: $4.05 |
| 8 |
99-2131 |
O-RING Price: $9.43 |
| 9 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 9 |
703-2143 |
BULKHEAD-LOWER Not Available Price: |
| 9 |
99-2148 |
GASKET-WATER Price: $13.55 |
| 10 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 10 |
99-2147 |
GASKET-COVER, PUMP Price: $22.27 |
| 11 |
596583101 |
Screws This part replaces 539990582. Price: $3.99 |
| 11 |
723-3042 |
SNAP BUSHING 7/8 Not Available Price: |
| 11 |
99-1813 |
GASKET Price: $29.00 |
| 12 |
107-4829 |
GASKET-THERMOSTAT This part replaces 99-2154. Price: $3.11 |
| 12 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 12 |
703-1827 |
TRAY ASSEMBLY- Not Available Price: |
| 13 |
596564401 |
Bolts This part replaces 539990563. Price: $3.99 |
| 13 |
710-3012 |
BOLT-J TYPE 1/4-20 Not Available Price: |
| 14 |
539102593 |
WASHER, 3/8 DISC SPRING SPEC Price: $2.99 |
| 14 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 15 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 15 |
723-3062 |
SEALING RING Not Available Price: |
| 16 |
539110833 |
CONTROL SHAFT Price: $37.99 |
| 16 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 17 |
539108394 |
HCS 5/16-18X1-3/4 TPBLT Price: $2.99 |
| 17 |
712-3051 |
HEX NUT TOP LOCK Not Available Price: |
| 18 |
596582601 |
Nuts This part replaces 539990196. Price: $2.99 |
| 19 |
539103003 |
ADJUSTMENT KNOB Price: $4.99 |
| 20 |
539111039 |
COMPRESSION SPRING Price: $9.99 |
| 21 |
596671501 |
Washers This part replaces 539101949. Price: $2.99 |
| 22 |
539110943 |
NUT 5/16F NYLOC Price: $2.99 |
| 23 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 24 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 25 |
539110603 |
SPHERICAL ROD END, RH Price: $27.99 |
| 26 |
539110604 |
SPHERICAL ROD END, LH Price: $17.99 |
| 27 |
539105279 |
PUMP CONTROL LINK Price: $17.99 |
| 28 |
596584101 |
Nuts This part replaces 539991073. Price: $2.99 |
| 29 |
596040901 |
Hardware This part replaces 539990223. Price: $2.99 |
| 30 |
539110636 |
RT CONTROL WLDMT Price: $99.99 |
| 31 |
539110637 |
LT CONTROL WLDMT Price: $83.99 |
| 32 |
539110638 |
CONTROL ARM Price: $29.99 |
| 33 |
539102678 |
TAPPED PLATE Price: $12.99 |
| 34 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 35 |
596583901 |
Bolts This part replaces 539990730. Price: $2.99 |
| 36 |
596039001 |
Screws This part replaces 539976952. Price: $2.99 |
