| Ref | Part Number | Description |
|---|
| 1 |
532106085 |
V-BELT T Price: $37.99 |
| 1 |
95-7522 |
AXLE Price: $377.20 |
| 2 |
532144725 |
DECK HOUSING 38" This part replaces 532121259. Price: $159.99 |
| 2 |
99-7564 |
SEAL-OIL Price: $25.36 |
| 3 |
532128772 |
RUNNER.RH.38 This part replaces 532124962. Price: $6.99 |
| 3 |
95-7544 |
CLIP Price: $4.04 |
| 4 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 4 |
95-7523 |
SPACER Price: $26.89 |
| 5 |
99-7555 |
SHIM 0.3 Price: $3.29 |
| 6 |
95-7525 |
GEAR-BEVEL, 27 TOOTH Price: $333.09 |
| 7 |
531155201 |
SERVICE KIT BRACKET BRACKET This part replaces 532105896. Price: $2.99 |
| 7 |
99-7534 |
BEARING-BALL Price: $65.44 |
| 8 |
532110452 |
NUT PUSH M Price: $2.99 |
| 8 |
95-7521 |
COVER-AXLE Price: $107.87 |
| 9 |
106-1071 |
O-RING This part replaces 99-7538. Price: $18.43 |
| 9 |
532123713 |
SPRING TORSION This part replaces 532106734. Price: $6.99 |
| 10 |
532106735 |
ROD-HINGE T Price: $8.99 |
| 10 |
93-7775 |
BEARING-BALL This part replaces 99-7561. Price: $127.75 |
| 11 |
532106736 |
SHIELD.DEFLECTOR.MOWER.38.BL Price: $36.99 |
| 11 |
99-7539 |
CLIP Price: $11.07 |
| 12 |
104-2374 |
BOLT This part replaces 99-7596. Price: $6.33 |
| 12 |
532109646 |
BRACKET LH T Price: $5.50 |
| 13 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 14 |
532105662 |
LINK,PARALLEL Price: $15.31 |
| 15 |
532105744 |
ROD,FRT PARALL LT Price: $9.99 |
| 16 |
532004921 |
COTTER PIN This part replaces 532124961. Price: $4.99 |
| 18 |
532109835 |
HINGE PIN T Price: $13.61 |
| 20 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 21 |
532109598 |
BRACKET RH LT NLA Price: $3.96 |
| 22 |
532109597 |
BRACKET LH T Price: $3.96 |
| 24 |
532109647 |
BRACKET RH T NLA Price: $9.63 |
| 25 |
532109503 |
SUPPORT ARM T Price: $2.42 |
| 26 |
532109504 |
STOP T Price: $6.02 |
| 27 |
532109776 |
PIVOT PIN T Price: $8.99 |
| 28 |
532126756 |
GUIDE BELT Price: $25.96 |
| 29 |
874930632 |
BOLT.375-16 This part replaces 874760632. Price: $5.99 |
| 30 |
532127163 |
ARM,IDLER Price: $19.55 |
| 31 |
532106902 |
SPACER RETAINER Price: $2.99 |
| 32 |
532123674 |
PULLEY.IDLER.FLAT This part replaces 532123688. Price: $24.99 |
| 33 |
532106513 |
WASHER, WEAR LT (1 2) Price: $5.99 |
| 34 |
532102669 |
BELT KEEPER LT Price: $3.68 |
| 35 |
532121687 |
JACKSHAFT.38"LT This part replaces 532121676. Price: $99.99 |
| 36 |
532100668 |
SUPPORT PLATE LT Price: $2.38 |
| 39 |
532143978 |
BLADE 38" This part replaces 532121263. Price: $24.99 |
| 40 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 41 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 42 |
874610624 |
BOLT.3/8-24X1-1/2 Price: $4.99 |
| 43 |
532108250 |
SPRING LT Price: $17.99 |
| 44 |
532108235 |
ROD LT NLA Price: $10.06 |
| 45 |
532109729 |
ROLLER T Price: $6.99 |
| 46 |
876020616 |
Pin, Cotter 3/16 x 1 Price: $2.42 |
| 47 |
532109892 |
ROCKSHAFT This part replaces 532124066. Price: $11.99 |
| 48 |
532124915 |
SPACER T Price: $5.46 |
| 49 |
532108247 |
ROD BRAKE LT Price: $6.99 |
| 51 |
596040101 |
Washers This part replaces 819151610. Price: $2.99 |
| 52 |
532108243 |
BRACKET LT NLA Price: $16.38 |
| 53 |
532108241 |
BRACKET LT Price: $4.73 |
| 54 |
532105857 |
BRKT, SUSP RH LT Price: $2.42 |
| 55 |
532108673 |
BRKT,SUSP REAR LH Price: $3.99 |
| 56 |
532106578 |
BRAKE LT Price: $37.99 |
| 57 |
532106463 |
ROD, BRAKE LH LT Price: $4.91 |
| 58 |
532108249 |
ROD BRAKE LT Price: $24.99 |
| 59 |
532106456 |
BRK,BRAKE,PVT LT Price: $10.08 |
| 60 |
532100672 |
SPACER BRAKE LTV Price: $2.99 |
| 61 |
532100673 |
BRACKET SUPT LTV NLA Price: $5.17 |
| 62 |
596040101 |
Washers This part replaces 819161616. Price: $2.99 |
| 63 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga. Price: $5.99 |
| 65 |
532007631 |
RUNNER LH This part replaces 532125074. Price: $14.99 |
| 66 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 68 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 69 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 70 |
532122314 |
SPACER Price: $3.23 |
| 75 |
596917601 |
Pins This part replaces 876020308. Price: $1.99 |
| 80 |
532110445 |
SUPPORT T Price: $8.99 |
| 81 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 532105814 |
DECAL |
LT NLA Price: $5.53 532105814 |
| 532121349 |
DECAL |
WARNING Price: $2.99 532121349 |
| 532123928 |
MOWER |
ASSY NLA Price: $742.22 532123928 |
