| Ref | Part Number | Description |
|---|
| 1 |
3296-15 |
NUT-LOCK, NI Price: $1.75 |
| 1 |
581578101 |
DECAL.READ.OWN.MAN.SYMBOL.LT Price: $2.99 |
| 2 |
3-6514 |
THRUST WASHER Price: $1.74 |
| 2 |
581627301 |
DECAL.BADGE.170MM.TEXTLOGO. Price: $11.99 |
| 3 |
252-6 |
BEARING-NEEDLE Price: $10.72 |
| 3 |
581579701 |
DECAL.ENGINE.WARNING Price: $2.99 |
| 4 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 4 |
532440095 |
Price: Call Us |
| 5 |
323-5 |
SCREW-HH Price: $0.41 |
| 5 |
581579601 |
DECAL.CHASSIS.HOT.MUFFLER Price: $2.99 |
| 6 |
39-8900-03 |
RH SPINDLE ASM This part replaces 39-8900. Price: $269.69 |
| 6 |
581724101 |
DECAL.CERTIFICATION.6MIL.100D Price: $2.99 |
| 7 |
44-9090 |
REAR AXLE WA Price: $661.42 |
| 7 |
584904602 |
DECAL.DECK.DEFLECTOR.WARNING This part replaces 584904601. Price: $1.99 |
| 8 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 8 |
583568401 |
DECAL.RPL.BSM21.PB.SRD.30R.PMS This part replaces 532443241. Price: $2.99 |
| 9 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 9 |
532145005 |
DECAL BTRY SYMBOLS Price: $3.99 |
| 10 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 10 |
581578001 |
DECAL.PARKING.BRAKE.SADDLE.LT Price: $2.99 |
| 11 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 11 |
581579401 |
DECAL.WARN.DFLCTR/CTFRG.SRD Price: $3.99 |
| 12 |
27-4060-01 |
DISCONTINUED This part replaces 27-4060. Price: Call Us |
| 12 |
581580004 |
DECAL.V.BELT.30" Price: $3.99 |
| 13 |
581579301 |
DECAL.WARN.DFLCTR/CTFNGR.SRD. This part replaces 581724001. Price: $2.99 |
| 14 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 16 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 17 |
256-121 |
WASHER-THRUST Price: $4.55 |
| 17 |
583518401 |
DECAL.ENG.BS.PB3.125SER.279689 This part replaces 532437410. Price: $2.99 |
| 18 |
39-8850-03 |
LH SPINDLE ASM This part replaces 39-8850. Price: $269.69 |
| 19 |
253-129 |
SEAL Price: $21.73 |
| 20 |
231-104 |
DISCONTINUED Price: Call Us |
| 21 |
217-108 |
DISCONTINUED Price: Call Us |
| 22 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 23 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 25 |
32136-5 |
NUT-HEX, SLOTTED Price: $2.71 |
| 26 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 27 |
254-94 |
BEARING-CONE, TAPERED Price: $8.48 |
| 28 |
5108 |
VALVE This part replaces 232-35. Price: $6.29 |
| 29 |
44-9120 |
DISCONTINUED Price: Call Us |
| 30 |
3220-3 |
NUT-HJ Price: $0.28 |
| 33 |
27-4090 |
DISCONTINUED Price: Call Us |
| 34 |
3220-12 |
NUT-HEX JAM LH Price: $1.83 |
| 35 |
21-0151 |
LH BALL JOINT ASM Price: $126.28 |
| 36 |
3220-5 |
NUT-JAM Price: $0.65 |
| 37 |
21-0141 |
RH BALL JOINT ASM Price: $109.12 |
| 38 |
44-9110 |
REAR STRG TUBE *PP Price: $82.74 |
| 39 |
27-5230 |
PIVOT ARM WA Price: $148.16 |
