| Ref | Part Number | Description |
|---|
| 1 |
5-0743-03 |
SPRING-MOWER This part replaces 5-0743. Price: $188.53 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 2 |
62-7240 |
DISCONTINUED Price: Call Us |
| 3 |
62-7300 |
CHAIN Price: $9.30 |
| 4 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 5 |
282-4 |
SHACKLE Price: $32.98 |
| 6 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 7 |
92-1818-01 |
ARM-SPRING, TENSION This part replaces 92-1818. Price: $13.39 |
| 8 |
323-7 |
SCREW-HH Price: $0.65 |
| 8 |
532139123 |
PULLEY.IDLER.V. This part replaces 532121361. Price: $32.99 |
| 9 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 9 |
532177748 |
KEEPER ASM BELT ENGINE Price: $12.99 |
| 10 |
3256-45 |
WASHER-FLAT Price: $0.28 |
| 10 |
532175287 |
BUSHING Price: $17.99 |
| 11 |
532179335 |
CLUTCH MZ ZTR GT.48/54"1.125" Price: $299.99 |
| 11 |
83-7900 |
DISCONTINUED Price: Call Us |
| 12 |
532143996 |
PULLEY ENG VGT ELECT CLUTCH Price: $37.99 |
| 12 |
76-0370 |
BOLT ASSY Price: $26.50 |
| 13 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 14 |
283-40 |
PIN-CLEVIS Price: $2.85 |
| 15 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 15 |
532179115 |
TANK.FUEL.5.0 LEFT.FILL.YTGT Price: $89.99 |
| 17 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 18 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 18 |
62-7250 |
VINYL SLEEVE Price: $32.91 |
| 19 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 20 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 20 |
532178147 |
CONTROL.THROTTLE.COBRA.42"BLK. Price: $29.99 |
| 21 |
18-2970 |
CLIP-FUEL LINE Price: $8.67 |
| 21 |
532189747 |
SCREW.HI-LO#13-16X5/8 This part replaces 532171875. Price: $14.99 |
| 22 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 22 |
532187768 |
CONTROL.CHOKE.ERGO.BLACK This part replaces 532189541. Price: $27.99 |
| 23 |
322-4 |
SCREW-HH Price: $0.35 |
| 25 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 26 |
532003645 |
BUSHING OUTLET T This part replaces 532124952. Price: $3.99 |
| 26 |
92-1815 |
SHAFT-C.U. PIVOT Price: $59.70 |
| 27 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 27 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 28 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 28 |
532008542 |
FUEL LINE 42" This part replaces 532124703. Price: $5.99 |
| 29 |
16-1089 |
DISCONTINUED Price: Call Us |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 31 |
92-1812 |
SHAFT-PIVOT, LIFT Price: $51.90 |
| 32 |
283-75 |
PIN-CLEVIS Price: $1.56 |
| 33 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 34 |
93-6912 |
DISCONTINUED This part replaces 92-1822. Price: Call Us |
| 35 |
32104-6 |
SCREW-HH, TAP Price: $3.19 |
| 36 |
322-26 |
SCREW-HH Price: $2.36 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 39 |
596564004 |
SCREW TT 3/8-16X2.31 UNC This part replaces 817490636. Price: $1.99 |
| 40 |
817490664 |
Screw TT 3/8-16 x 4 unc Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 47 |
532175288 |
BUSHING Price: $4.99 |
| 62 |
532176252 |
HEAT SHIELD Price: $5.59 |
| 70 |
532175767 |
TUBE.EXHAUST.KAWASAKI.RH Price: $54.99 |
| 71 |
532175766 |
TUBE EXHAUST LH Price: $48.99 |
| 80 |
596433401 |
Nuts This part replaces 532163305. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 84 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
