| Ref | Part Number | Description |
|---|
| 1 |
580687702 |
LEVER.CONTROL.RH.PNT.BLACK This part replaces 532415542. Price: $19.99 |
| 1 |
93-3351 |
GEAR-IND. PUMP Price: $373.60 |
| 2 |
580687802 |
LEVER.CONTROL.LH.BLACK This part replaces 532415541. Price: $24.99 |
| 2 |
93-3352 |
GEAR ASSY-IDLER Price: $292.36 |
| 3 |
93-3364 |
DISCONTINUED Price: Call Us |
| 4 |
93-3363 |
DISCONTINUED Price: Call Us |
| 5 |
42-7190 |
DISCONTINUED Price: Call Us |
| 5 |
532169675 |
SPRING RETAINER Price: $4.99 |
| 6 |
42-9440 |
BOLT/WASHER Price: $4.52 |
| 6 |
817060408 |
SCREW Price: $4.99 |
| 7 |
532412677 |
BAIL.CONTROL.INTERLOCK Price: $12.99 |
| 7 |
93-3360 |
COVER Price: $20.74 |
| 8 |
532429098 |
ARM.IMPELLER.ROD.SNOW This part replaces 532199576. Price: $3.99 |
| 8 |
93-3361 |
GASKET-COVER Price: $4.72 |
| 9 |
532415546 |
ARM.TRACTION.ROD.YZ Price: $3.99 |
| 9 |
93-3365 |
PIN-DOWEL Price: $3.29 |
| 10 |
585198802 |
PANEL.CONTROL.SNOW.BLACK This part replaces 532415539. Price: $34.99 |
| 10 |
93-3688 |
SHIPPING CAP(TACHOMETER) This part replaces 93-3366. Price: $5.36 |
| 11 |
596582201 |
Bolts This part replaces 874780524. Price: $2.99 |
| 11 |
93-3356 |
DISCONTINUED Price: Call Us |
| 12 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874780512. Price: $3.99 |
| 12 |
93-3355 |
WASHER SPRING Price: $2.71 |
| 13 |
42-9810 |
WASHER Price: $5.44 |
| 13 |
532414517 |
TUBE.HANDLE.PLOW.LH.PNT This part replaces 532415236. Price: $28.99 |
| 14 |
532414516 |
TUBE.HANDLE.PLOW.RH.PNT This part replaces 532415237. Price: $29.99 |
| 14 |
93-3357 |
DISCONTINUED Price: Call Us |
| 15 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 15 |
93-3359 |
DISCONTINUED Price: Call Us |
| 16 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
93-3370 |
BRG-CON-ROD Price: $38.90 |
| 17 |
532178899 |
KNOB.HANDLE.3/8.TRI-POINT.BLAC Price: $4.99 |
| 17 |
93-3373 |
BOLT CONNECTING Price: $25.55 |
| 18 |
104-0552 |
PIN,PISTON This part replaces 93-3374. Price: $40.18 |
| 18 |
532180480 |
ROD.ASM.IMPELLER Price: $24.99 |
| 19 |
532180481 |
ROD.ASM.TRACTION. Price: $22.99 |
| 19 |
93-3375 |
RING SET-PISTON Price: $181.55 |
| 20 |
93-3596 |
DISCONTINUED Price: Call Us |
| 22 |
872120618 |
BOLT 3/8-16 X 2-1/4 Price: $5.99 |
| 22 |
93-3376 |
PISTON STD Price: $250.91 |
| 23 |
104-0553 |
CONNECTING ROD ASM This part replaces 93-3371. Price: $734.57 |
| 23 |
532184087 |
TUBE.LOWER.HANDLE.24.BLACK Price: $59.99 |
| 24 |
43-1810 |
GEAR RING Price: $269.80 |
| 24 |
532180447 |
SLEEVE, SPRING Price: $5.99 |
| 25 |
532180926 |
SPRING, TRACTION DRIVE Price: $5.99 |
| 25 |
93-3358 |
FLYWHEEL SUB-ASSY Price: $1,601.02 |
| 26 |
532178669 |
SPRING, AUGER CONTROL Price: $7.99 |
| 26 |
54-8670 |
BOLT Price: $6.00 |
| 27 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 27 |
93-3354 |
DISCONTINUED Price: Call Us |
| 28 |
42-7730 |
DISCONTINUED Price: Call Us |
| 28 |
532412680 |
SPACER CONTROL LEVER Price: $2.99 |
| 30 |
532405879 |
CONSOLE, PANEL Price: $29.99 |
| 30 |
93-3372 |
DISCONTINUED Price: Call Us |
| 31 |
532175262 |
SCREW, HEX HD TAPPING #10-24 1 Price: $3.99 |
| 31 |
93-3369 |
DISCONTINUED Price: Call Us |
| 32 |
594975601 |
Screws This part replaces 532184471. Price: $1.99 |
| 32 |
93-3367 |
DISCONTINUED Price: Call Us |
| 33 |
42-9250 |
BOLT Price: $1.63 |
| 34 |
93-3362 |
DISCONTINUED Price: Call Us |
| 35 |
93-3350 |
GEAR-CAMSHAFT Price: $385.01 |
| 36 |
532443215 |
SPRING.TORSION.LEVER This part replaces 532178831. Price: $3.99 |
| 36 |
93-3353 |
DISCONTINUED Price: Call Us |
| 39 |
532178668 |
BEZEL.HEADLIGHT.BLACK Price: $5.99 |
| 41 |
532178775 |
RIVET.POP.1/8X Price: $6.99 |
| 42 |
817060410 |
SCREW 14-20 X 5/8 Price: $3.99 |
| 47 |
532196943 |
BRKT.PANEL.RH.INT Price: $8.99 |
| 48 |
532196944 |
BRKT.PANEL.LH.INT Price: $8.99 |
| 49 |
532414515 |
GRIP.HANDLE.HEATED Price: $54.99 |
| 532401620 |
BULB.HEADLIGHT.HALOGEN. |
Price: $59.99 532401620 |
