| Ref | Part Number | Description |
|---|
| 1 |
40-8970 |
DISCONTINUED This part replaces 5-1447. Price: Call Us |
| 1 |
530352036 |
Screw Price: $0.99 |
| 2 |
530351822 |
Handle Set Price: $3.33 |
| 2 |
8-2230 |
Name Plate Price: Call Us |
| 3 |
321-3 |
SCREW-HH Price: $0.28 |
| 3 |
530347653 |
Cord Retainer Price: $3.99 |
| 4 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 4 |
530347897 |
On/Off Switch Price: $2.99 |
| 5 |
530351826 |
Trigger Switch Price: $1.99 |
| 6 |
3219-4 |
NUT-HEX Price: $2.65 |
| 6 |
534014593 |
Harness Ass'y. Price: $14.99 |
| 7 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 7 |
534500111 |
Upper Tube Price: $3.99 |
| 8 |
530403094 |
Nut This part replaces 530015653. Price: $1.99 |
| 8 |
6-1600 |
SOLENOID Price: $55.95 |
| 9 |
10-4630 |
DISCONTINUED Price: Call Us |
| 9 |
530346034 |
Screw Price: $3.33 |
| 10 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 10 |
534014600 |
Lower Tube w/ Decal Price: $3.33 |
| 11 |
3218-13 |
NUT-JAM, BRASS Price: $0.88 |
| 11 |
534014597 |
Plug Ass'y. Price: $3.33 |
| 12 |
530625509 |
Screw Price: $1.99 |
| 13 |
3217-5 |
NUT-HEX Price: $0.25 |
| 13 |
530400013 |
Wing Nut Price: Call Us |
| 14 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 14 |
534036733 |
Assist Handle Price: $3.99 |
| 15 |
3290-199 |
NUT-SPEED Price: $4.09 |
| 15 |
534379655 |
Guard & Blade Ass'y. This part replaces 534379665. Price: $8.99 |
| 16 |
32149-7 |
NUT-KEPS Price: $0.27 |
| 16 |
530400787 |
Housing Set Price: $3.33 |
| 17 |
2412-21 |
DISCONTINUED Price: Call Us |
| 17 |
530015992 |
Washer Price: $1.99 |
| 18 |
3290-237 |
SLOT HD SCREW Price: $0.25 |
| 18 |
534193800 |
Screw Price: $3.33 |
| 19 |
218-247 |
IGNITION SWITCH Price: $94.84 |
| 19 |
530400753 |
Housing Label (Not a serviceable part) Price: Call Us |
| 20 |
3-8006 |
DISCONTINUED Price: Call Us |
| 20 |
530400754 |
Hsg. Front Label (Not a serviceable part) Price: $3.33 |
| 21 |
534222400 |
Screw Price: $1.99 |
| 21 |
7-1394 |
DISCONTINUED Price: Call Us |
| 22 |
3290-163 |
Locknut Price: Call Us |
| 22 |
534768300 |
Motor Ass'y. Price: $3.33 |
| 23 |
534487245 |
Air Baffle Price: $3.33 |
| 23 |
8-2120 |
DISCONTINUED Price: Call Us |
| 24 |
5-1336 |
KEY-SQUARE Price: $8.92 |
| 24 |
534907306 |
Cutting Head Ass'y. Price: $18.52 |
| 25 |
3-8388 |
WASHER Price: $24.32 |
| 25 |
534839100 |
Cam Price: $3.33 |
| 26 |
3273-29 |
SCREW-HSFH Price: $20.62 |
| 26 |
534907904 |
Spool & Line Price: $2.48 |
| 27 |
3-7935 |
DISCONTINUED Price: Call Us |
| 27 |
534899400 |
Cover Price: $3.33 |
| 28 |
3-7934 |
DISCONTINUED Price: Call Us |
| 28 |
534900301 |
Drive Adapter Price: $6.99 |
| 29 |
5-1315 |
DISCONTINUED Price: Call Us |
| 29 |
534400701 |
Push Nut Price: $1.99 |
| 30 |
221-335 |
Engine (Kohler Mod. K-141S Type No. 29403D) Price: Call Us |
| 30 |
534980301 |
Housing Head Price: $3.33 |
| 31 |
32122-14 |
SCREW-PPH Price: $1.02 |
| 31 |
534908500 |
Spring Price: $5.99 |
| 32 |
534899200 |
Arm Price: $3.33 |
| 32 |
8-0170 |
DISCONTINUED Price: Call Us |
| 33 |
2212-10 |
MUFFLER Price: $159.52 |
| 33 |
534908700 |
Washer Price: $1.99 |
| 34 |
3-7232 |
DISCONTINUED Price: Call Us |
| 34 |
534136401 |
Screw Price: $1.99 |
| 35 |
534900200 |
Line Shield Price: $3.33 |
| 35 |
98-3206 |
DECAL This part replaces 12-9140. Price: $1.99 |
| 36 |
5-1280 |
DISCONTINUED Price: Call Us |
| 36 |
534228703 |
Screw Price: $3.33 |
| 37 |
3217-6 |
NUT-HEX Price: $1.19 |
| 37 |
534207101 |
Endbell Ass'y. Drive Price: $3.33 |
| 38 |
534228800 |
Washer Price: $1.99 |
| 38 |
68-8860 |
CHAIN GUARD WA *R This part replaces 22-8240. Price: $53.73 |
| 39 |
25-9900 |
DISCONTINUED Price: Call Us |
| 39 |
534227004 |
Field Ass'y. Price: $22.99 |
| 40 |
534767700 |
Armature Ass'y. Price: $6.16 |
| 41 |
534228802 |
Washer Price: $0.99 |
| 41 |
8-2260 |
DISCONTINUED Price: Call Us |
| 42 |
237-41 |
GROMMET Price: $12.90 |
| 42 |
534238903 |
Washer Price: $1.99 |
| 43 |
321-2 |
SCREW-HH Price: $2.79 |
| 43 |
534227501 |
Endbell Ass'y. Brush Price: $3.33 |
| 44 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 44 |
534226000 |
Insulator Price: $3.33 |
| 45 |
237-37 |
BUMPER-RUBBER Price: $4.33 |
| 45 |
534227800 |
Carbon Brush Price: $3.16 |
| 46 |
321-4 |
SCREW-HH Price: $0.99 |
| 46 |
534228000 |
Brush Spring Price: $1.99 |
| 47 |
25-9930 |
DISCONTINUED Price: Call Us |
| 47 |
534227700 |
Brush Holder Price: $3.33 |
| 48 |
32140-70 |
DISCONTINUED Price: Call Us |
| 49 |
10-4640 |
DISCONTINUED Price: Call Us |
| 50 |
321-10 |
SCREW-HH Price: $1.29 |
| 51 |
10-8340 |
DISCONTINUED Price: Call Us |
| 52 |
11-3320 |
DISCONTINUED Price: Call Us |
| 53 |
32128-20 |
NUT-HF Price: $0.99 |
