| Ref | Part Number | Description |
|---|
| 1 |
325-4 |
SCREW-HH Price: $0.95 |
| 2 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S This part replaces 580532301. Price: $39.99 |
| 3 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 4 |
110-0009 |
JOINT ARM ASM This part replaces 75-3010-03. Price: $199.32 |
| 5 |
32121-122 |
PIN-ROLL Price: $2.93 |
| 6 |
282-4 |
SHACKLE Price: $32.98 |
| 7 |
104-0028 |
GUIDE-HOSE Price: $46.21 |
| 8 |
32121-27 |
PIN-ROLL Price: $1.56 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 (3 2) This part replaces 584911602. Price: $11.99 |
| 10 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 11 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 12 |
586729001 |
PULLEY.ENGINE Price: $27.99 |
| 12 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 13 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 14 |
92-9097 |
SCREW-HS Price: $1.56 |
| 15 |
581289901 |
FUEL.TANK.ASM.NON-EPA Price: $44.99 |
| 15 |
93-0142 |
BUSHING-STRAIGHT Price: $3.21 |
| 16 |
94-4919-03 |
BRACKET-CLAMP, HOSE Price: $19.76 |
| 17 |
322-13 |
SCREW-HH Price: $2.73 |
| 18 |
75-4520 |
SPRING-TORSION, RH Price: $25.31 |
| 19 |
75-4530 |
SPRING-TORSION, LH Price: $25.31 |
| 20 |
532176636 |
CONTROL.TH/CK.C.BLACK This part replaces 532183897. Price: $27.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 23 |
100-3828 |
DISCONTINUED Price: Call Us |
| 24 |
100-3827 |
LH REAR LIFT ARM ASM Price: $720.05 |
| 25 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 26 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 27 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 28 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
5-1096 |
CHAIN-LIFT Price: $18.82 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
100-3834-03 |
ROD-PIVOT Price: $69.13 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 69 |
532185909 |
GASKET.EXHAUST.KOHLER Price: $7.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 94 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE Price: $27.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 122 |
532421922 |
EXTENSION DRAIN OIL Price: $24.99 |
