| Ref | Part Number | Description |
|---|
| 1 |
121-3639 |
FRAME Price: $1,529.33 |
| 1 |
532159460 |
WIRE ASM INNER W/ PLUNGER LT Price: $22.99 |
| 2 |
529845601 |
SERVICE KIT SHAFT ASM RH HANDL This part replaces 532159471. Price: $49.99 |
| 2 |
95-8568-03 |
FRAME-LOWER Price: $957.21 |
| 3 |
32144-15 |
SCREW-HHFTF Price: $7.99 |
| 3 |
532105767 |
PIN GROOVE. Price: $4.99 |
| 4 |
3234-38 |
SCREW-HHF Price: $3.33 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 5 |
32128-49 |
NUT-HHF Price: $1.04 |
| 5 |
819211621 |
WASHER Price: $4.99 |
| 6 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 6 |
99-3375-03 |
STEP Price: $81.69 |
| 7 |
2412-72 |
CLIP-CLOSED, INSULATED Price: $1.90 |
| 7 |
532125631 |
GRIP HANDLE Price: $6.99 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 8 |
95-8615 |
TUBE-BREATHER Price: $48.92 |
| 9 |
32128-33 |
NUT-HF Price: $0.25 |
| 10 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 11 |
3229-11 |
SCREW-CARR Price: $0.99 |
| 11 |
532165828 |
LIFT LINK, LH This part replaces 532165829. Price: $17.99 |
| 12 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 12 |
532165830 |
LINK ASSY. This part replaces 532165831. Price: $9.99 |
| 13 |
119-2029 |
TOOLBOX COVER ASM Price: $81.78 |
| 13 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 14 |
99-3430-0P |
BOTTOM - TOOLBOX *B This part replaces 99-3430-03. Price: $93.53 |
| 15 |
532173288 |
LINK.SUSPENSION.FRONT Price: $11.99 |
| 15 |
99-3431-0P |
END - TOOLBOX, RH *B This part replaces 99-3431-03. Price: $54.38 |
| 16 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 16 |
99-3432-0P |
END - TOOLBOX, LH *B This part replaces 99-3432-03. Price: $54.38 |
| 17 |
532175689 |
TRUNNION Price: $3.99 |
| 18 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 19 |
127-8493 |
ROPS ASM Price: $740.37 |
| 19 |
531165801 |
SERVICE KIT ARM ARM.REAR.SUSPE This part replaces 532139868. Price: $11.99 |
| 20 |
117-3176 |
SCREW-HHF Price: $3.73 |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 22 |
115-3417-0P |
BRACKET-BULKHEAD,SCISSOR This part replaces 115-3417-03. Price: $35.82 |
| 23 |
104-7050 |
TUBE-MANUAL Price: $8.76 |
| 23 |
532110807 |
NUT T Price: $3.99 |
| 24 |
2412-133 |
CLAMP-R Price: $3.19 |
| 24 |
819131016 |
WASHER Price: $2.99 |
| 25 |
32144-70 |
SCREW-HWHTF Price: $1.99 |
| 25 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 26 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 26 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 27 |
532126971 |
ROD ADJ LIFT Price: $5.99 |
| 28 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
121-3607 |
DECAL-SERVICE Price: $68.24 |
| 29 |
532138057 |
KNOB INF 3/8-16 Price: $6.99 |
| 30 |
532150233 |
TRUNNION Price: $9.99 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT Price: $5.99 |
| 32 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 32 |
99-3503 |
INDICATOR-ANGLE Price: $92.89 |
| 33 |
104-7048 |
CAP-HOUSING Price: $5.21 |
| 34 |
119-2034 |
HINGE-TOOLBOX Price: $55.07 |
| 35 |
119-6906 |
SCREW-HSBH Price: $0.27 |
| 36 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 36 |
532155097 |
POINTER, HEIGHT INDICATOR(2 2) Price: $4.99 |
| 37 |
532123935 |
PLUG,HOLE Price: $4.99 |
| 38 |
593337601 |
Screws This part replaces 817060516. Price: $3.99 |
| 39 |
161-8355 |
CUP HOLDER ASM This part replaces 117-2378. Price: $12.36 |
| 40 |
819112410 |
WASHER Price: $3.99 |
| 41 |
532123934 |
HEIGHT INDICATOR Price: $2.99 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 50 |
532110452 |
NUT PUSH M Price: $2.99 |
