| Ref | Part Number | Description |
|---|
| 1 |
62-3800 |
YOKE-END This part replaces 21-5960. Price: $239.26 |
| 2 |
04063-01 |
Key, 1/4 x 1/4 x 1.25" Pulley Mtg. Price: Call Us |
| 2 |
54-9180 |
U-JOINT KIT This part replaces 21-5970. Price: $58.18 |
| 3 |
04112-06 |
Nut, 3/4-16 Spriral Lock Price: Call Us |
| 3 |
2115-80 |
ZERK This part replaces 21-5980. Price: $0.76 |
| 5 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 5 |
21-5990 |
DUST CAP ASM Price: $36.55 |
| 6 |
04043-04 |
Flatwasher, 3/8 (.391 x .938 x .105 HD) Grade 8 Price: Call Us |
| 6 |
100-6564 |
DRIVESHAFT ASM This part replaces 21-6020. Price: $924.10 |
| 7 |
424367 |
Quick Pin, 5/16" Dia. Price: Call Us |
| 8 |
483422 |
Pulley, 5" Idler Price: Call Us |
| 10 |
424479 |
Brace, Pulley Price: Call Us |
| 11 |
43711 |
Spacer, Idler Pulley Price: Call Us |
| 13 |
04021-22 |
Lock Nut, 5/16-18 Elastic Stop Grade 8 Price: Call Us |
| 14 |
04030-03 |
Lockwasher, 5/16 (.317 x .586 x .078) Helical Spring Price: Call Us |
| 15 |
483453-03 |
Bearing, Plastic Price: Call Us |
| 17 |
04001-31 |
Capscrew, Hex Head 3/8-16 x 2-1/2" Price: Call Us |
| 18 |
43708 |
Pivot, Idler Price: Call Us |
| 19 |
04001-136 |
Bolt, Hex Head 3/8-16 x 1-1/2" Grade 8 Black Price: Call Us |
| 20 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 21 |
483375 |
Spring, Cutter Deck Idler Price: Call Us |
| 22 |
04110-03 |
U-Nut, 3/8-16 (short) Price: Call Us |
| 23 |
04107-04 |
Bolt, Hex Head 3/8-16 x 2" Special Lock Price: Call Us |
| 25 |
04001-11 |
Bolt, Hex Head 5/16-18 x 1-1/2" (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 27 |
04043-06 |
Flatwasher, 5/8-.688 x 1-3/4 x .134 HD Price: Call Us |
| 28 |
04030-07 |
Lockwasher, 5/8" Spring Price: Call Us |
| 29 |
04001-121 |
Bolt, Hex Head 5/8-11 x 1-1/2" Price: Call Us |
| 30 |
461950 |
Spindle Assembly Price: Call Us |
| 31 |
483304 |
Debris Shield Price: Call Us |
| 32 |
483303 |
Bearing Price: Call Us |
| 33 |
43693 |
Spacer, Bearing Price: Call Us |
| 35 |
43694 |
Protector, Bearing Price: Call Us |
| 36 |
43695 |
Shaft, Spindle Price: Call Us |
| 37 |
04001-77 |
Bolt, Hex Head, 3/8-16 x 3-1/2" Price: Call Us |
| 38 |
04003-26 |
Bolt, Hex Head 3/8-16 x 3-1/2" Price: Call Us |
| 39 |
481632 |
Bolt, Carriage 3/8-16 x 4" Price: Call Us |
| 40 |
04017-27 |
Capscrew, 3/8-16 x 1.0" Serrated Flange Hex Hd Price: Call Us |
| 41 |
04021-05 |
Bolt, Hex Head 3/8-16 x 1" Ser. Flg. Price: Call Us |
| 42 |
427865 |
Bracket, Anti-Scalp, (Black) Price: Call Us |
| 43 |
04001-09 |
Bolt, Heax Head 5/16-18 x 1" (48V / 52V) Price: Call Us |
| 44 |
451926 |
Shaft Weldment, Guide Roller Price: Call Us |
| 45 |
482295 |
Wheel, Anti-Scalp Price: Call Us |
| 46 |
04003-42 |
Bolt, Carriage 7/16-14 x 2-1/4" Price: Call Us |
| 47 |
483361 |
Bolt, Carriage 7/16-14 x 2-1/4" Price: Call Us |
| 48 |
04021-11 |
HEX LOCKNUT, ELASTIC STOP, 7/16-14 Price: Call Us |
| 49 |
481625-01 |
Knob, w/stud 3/8-16 x 1-1/4" Price: Call Us |
| 51 |
482245 |
Spring, Discharge Chute Price: Call Us |
| 52 |
04001-154 |
Bolt, 5/16-18 x 4-3/4" Hex Head Price: Call Us |
| 53 |
04021-10 |
HEX NUT, ELASTIC STOP LOCK, 5/16-18 Price: Call Us |
| 54 |
424615 |
Bracket, Belt Guide Price: Call Us |
| 55 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 56 |
04001-12 |
Bolt, Hex Head 5/16-18 x 1-1/2" - Front Price: Call Us |
| 57 |
04041-38 |
Flatwasher, 3/8-.406 x 2.25" x .1875 Price: Call Us |
| 425260 |
Belt |
Cover (61H) Price: Call Us 425260 |
| 425264 |
Support, |
Idler Pivot (61H) Price: Call Us 425264 |
| 462213 |
Discharge |
Chute (61H) Price: Call Us 462213 |
| 463309 |
Cutter |
Deck w/Decals, SPZ61 Price: Call Us 463309 |
| 482879 |
Cutter |
Blade, 21" (61H) Price: Call Us 482879 |
| 484031 |
Belt, |
Cutter Deck Price: Call Us 484031 |
