| Ref | Part Number | Description |
|---|
| 1 |
325-7 |
SCREW-HH Price: $1.53 |
| 2 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 2 |
532186211 |
KEY.SQUARE.187X2.500 Price: $3.99 |
| 3 |
61-0900-01 |
CARRIER BRKT This part replaces 61-0900. Price: $66.74 |
| 4 |
61-0160 |
DISCONTINUED X-REF Price: Call Us |
| 5 |
61-3380 |
BELT-V Price: $29.87 |
| 6 |
323-6 |
SCREW-HH Price: $0.66 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7 |
531170101 |
SERVICE.KIT HUB ASM HUB.ASM.WH This part replaces 532199844. Price: $49.99 |
| 8 |
92-3159 |
SUPPORT WA - LH FRONT This part replaces 61-1050. Price: $191.00 |
| 9 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 9 |
596218701 |
Bolts This part replaces 532140080. Price: $2.99 |
| 10 |
323-12 |
SCREW-HH Price: $1.14 |
| 11 |
32121-36 |
PIN-SPRING Price: $2.56 |
| 12 |
62-5510 |
BUSHING-RUBBER Price: $7.42 |
| 13 |
52-2890 |
BUSHING-NYLON Price: $2.49 |
| 14 |
3296-62 |
NUT-LOCK,NI Price: $5.72 |
| 15 |
57-5270 |
SPRING-COMPRESSION Price: $9.79 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
29-8870 |
WASHER Price: $1.66 |
| 17 |
52-2980 |
S.P.A. PIVOT Price: $107.93 |
| 17 |
532413678 |
SPRING.BRAKE.K46.GREEN Price: $6.99 |
| 18 |
52-3000 |
SPRING ARM Price: $35.27 |
| 19 |
52-2990 |
SPRING RET CAPSCREW Price: $8.73 |
| 20 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 21 |
257-5 |
WASHER-THRUST Price: $1.83 |
| 22 |
253-84 |
SEAL-OIL Price: $10.00 |
| 22 |
532197329 |
ROD.SHIFT.FENDER.STGT. Price: $74.99 |
| 23 |
532140845 |
KNOB.DELUXE.(PISTOL.GRIP).BLAC Price: $11.99 |
| 24 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 25 |
61-1070 |
DISCONTINUED Price: Call Us |
| 26 |
257-6 |
BEARING-THRUST Price: $4.78 |
| 27 |
107-7409 |
PIN-PIVOT, BEDBAR This part replaces 57-5260. Price: $33.41 |
| 28 |
93-8849 |
REAR GRASS SHIELD ASM This part replaces 61-1130. Price: $137.18 |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 29 |
61-0940 |
DISCONTINUED Price: Call Us |
| 30 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 32 |
61-0500 |
BRG RETAINER SPACER Price: $40.44 |
| 33 |
67-9760 |
WASHER Price: $11.32 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 35 |
3211-4 |
SCREW-HH Price: $1.02 |
| 35 |
583864502 |
Rods This part replaces 583864501. Price: $6.99 |
| 36 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 37 |
61-0610-01 |
C.U. GUARD This part replaces 61-0610. Price: $48.86 |
| 38 |
3230-1 |
BOLT-CARR This part replaces 3230-20. Price: $1.49 |
| 39 |
251-319 |
DISCONTINUED Price: Call Us |
| 40 |
251-331 |
BEARING Price: $38.82 |
| 41 |
251-229 |
BRG FLANGE Price: $38.99 |
| 42 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 43 |
3217-6 |
NUT-HEX Price: $1.19 |
| 44 |
61-0970 |
BEDBAR PIVOT HSG WA Price: $59.59 |
| 45 |
56-9510 |
BUSHING ASM Price: $12.89 |
| 46 |
56-9520 |
BUSHING-FLANGED Price: $2.15 |
| 47 |
119-4151 |
SCREW-BEDKNIFE This part replaces 57-4910. Price: $0.41 |
| 48 |
105-6785 |
BEDKNIFE-LOWCUT (FAIRWAY) This part replaces 62-5180. Price: $91.81 |
| 49 |
61-1210-01 |
BEDBAR This part replaces 61-1210. Price: $367.89 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 50 |
61-1010 |
BEDBAR PIVOT HSG WA Price: $41.79 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 51 |
57-5190 |
SCREW-SET, HSH Price: $5.50 |
| 52 |
3218-18 |
NUT-JAM Price: $0.57 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 53 |
61-1950 |
WASHER-PLASTIC Price: $0.55 |
| 54 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 55 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 56 |
322-3 |
SCREW-HH Price: $0.79 |
| 56 |
592855201 |
Belts This part replaces 532130969. Price: $27.99 |
| 57 |
12-7079 |
DISCONTINUED Price: Call Us |
| 58 |
61-0660-01 |
REEL FRAME WA This part replaces 61-0660. Price: $388.13 |
| 59 |
323-7 |
SCREW-HH Price: $0.65 |
| 60 |
67-5840 |
NUT-JAM Price: $5.02 |
| 61 |
27-1850 |
WASHER-PIVOT Price: $2.58 |
| 62 |
61-1320 |
DISCONTINUED Price: Call Us |
| 63 |
3296-45 |
NUT-HEX Price: $3.79 |
| 64 |
302-18 |
FITTING-GREASE Price: $3.46 |
| 64 |
532196200 |
SHAFT.ASM.PEDAL.BRAKE. Price: $49.99 |
| 65 |
62-7120 |
WASHER Price: $1.48 |
| 66 |
62-5070 |
DECAL-WARNING Price: $5.59 |
| 70 |
532439660 |
SUBASM.CONSOLE.HUSQ.GT.HYDRO Price: $79.99 |
| 73 |
583613301 |
BOLT.HEX.FLNG.5/16-18X3.75 This part replaces 874490560. Price: $4.99 |
| 74 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 99 |
532415743 |
ROD.SPRING.BYPASS.K46.TEX.GT Price: $6.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 162 |
580457401 |
SPACER.TRANSAXLE.1" Price: $12.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532413430 |
KEEPER.CENTER SPAN.1.688 Price: $5.99 |
| 174 |
532197289 |
NUT.PUSH.500.2006 Price: $2.99 |
| 175 |
532406208 |
SHAFT ASM SHIFT Price: $22.99 |
| 176 |
532196214 |
ARM.CLEVIS.ROD.SHIFT Price: $6.99 |
| 178 |
532197456 |
SPRING.SHIFT.GT2006 Price: $4.99 |
| 183 |
532400424 |
SPACER.SPLIT.800X.350 Price: $4.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 532441455. Price: $9.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG This part replaces 532194323. Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
585658602 |
Stop This part replaces 585658601. Price: $4.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 211 |
532196212 |
BUSHING.SHAFT.BRAKE.HAND Price: $5.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 220 |
532198908 |
REFLECTOR.RH.TEX GT Price: $14.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
| 227 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 230 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 231 |
532407287 |
IDLER.V-GROOVE.1.688.OFFSET Price: $19.99 |
| 233 |
596135201 |
Washers This part replaces 532405296. Price: $2.99 |
| 276 |
596238601 |
Bolts This part replaces 874780716. Price: $2.99 |
| 279 |
532406207 |
LINK.SHIFT.T/A.K46.FEND.TX Price: $9.99 |
| 325 |
585995702 |
BRACKET.TRQ.STP.46.22".TIRE.LH Price: $3.99 |
| 326 |
585993102 |
BRACKET.TRQ.STP.46.22".TIRE.RH Price: $3.99 |
| 334 |
585882202 |
SWAY.ROD.BRACKET.K46.X431 Price: $11.99 |
| 336 |
587259602 |
Bolts This part replaces 587259601. Price: $3.99 |
