| Ref | Part Number | Description |
|---|
| 1 |
918-04317 |
Wheel Assembly Hub This part replaces 618-04317. Price: $102.24 |
| 2 |
618-04329 |
HYDRO GT TRANSMISSION ASSEMBLY Not Available Price: |
| 3 |
629-0949B |
Hydro Ground Harness Assembly Not Available This part replaces 629-0949A. Price: |
| 4 |
710-0176 |
HH Cap Screw 5/16-18 x 2.75 Price: $3.89 |
| 5 |
710-0216 |
HH Cap Screw 3/8-16 x.75 Price: $3.93 |
| 6 |
710-0227 |
AB Screw #8-18 x.500 Price: $3.90 |
| 7 |
710-0520 |
HH Cap Screw 3/8-16 x 1.50 Price: $3.93 |
| 8 |
710-0599 |
TT Screw 1/4-20 x.500 Price: $3.86 |
| 9 |
710-0726 |
AB Screw 5/16-12 x.750 Price: $3.82 |
| 10 |
710-1007 |
TT Sems Screw 3/8-16 x 1.500 Price: $5.71 |
| 11 |
710-3011 |
HH Cap Screw 3/8-16 x 2.25 Price: $6.49 |
| 12 |
710-3119 |
HH Cap Screw 3/8-16 x.750 Price: $5.91 |
| 13 |
911-0832 |
Ferrule, 3/8-24 x .375 This part replaces 711-0832. Price: $13.68 |
| 14 |
912-0240 |
Nut, Jam, 7/16-20, Gr2 This part replaces 712-0240. Price: $3.90 |
| 15 |
712-04063 |
Flange Lock Nut 5/16-18 Price: $3.56 |
| 16 |
712-04065 |
Flange Lock Nut 3/8-16 Price: $3.68 |
| 17 |
712-3017 |
HEX NUT 3/8-16 GR5 Price: $3.90 |
| 18 |
714-0104 |
Cotter Pin.072 x 1.13 Price: $3.90 |
| 19 |
714-0111 |
Cotter Pin 3/32 x 1.0 Price: $4.20 |
| 20 |
714-0507 |
Cotter Pin 3/32 x.750 Price: $3.93 |
| 21 |
725-1644 |
SAFETY SPRING SWITCH Price: $8.34 |
| 22 |
926-0320 |
Insulator Nut Plate This part replaces 726-0320. Price: $6.01 |
| 23 |
732-04323B |
Extension Spring.770 x 3.720 Price: $11.23 |
| 24 |
732-0716D |
Extension Spring, .59 OD x 4.00 LG This part replaces 732-0716C. Price: $11.49 |
| 25 |
732-3118 |
Extension Spring 3/8 x 1.44 Price: $8.78 |
| 26 |
736-0169 |
Lock Washer 3/8 Price: $3.33 |
| 27 |
736-0227 |
Flat Washer.390 x 1.500 x.134 Price: $5.78 |
| 28 |
736-0258 |
Flat Washer.385 x 1.0 x.135 Price: $3.93 |
| 29 |
736-3010 |
Flat Washer.407 x.812 x.135 Price: $4.02 |
| 30 |
738-0372B |
Shoulder Spacer 1.00 x.38 x.38 Price: $8.78 |
| 31 |
747-04140 |
BRAKE ROD Not Available Price: |
| 32 |
747-1119 |
CONTROL ROD HYDRO Not Available Price: |
| 33 |
747-1121A |
DISENGAGEMENT ROD Not Available Price: |
| 34 |
954-0349 |
DECK SPINDLE BELT This part replaces 754-0349. Price: $37.46 |
| 35 |
756-04209 |
V-Type Idler Pulley 3.06 Price: $20.97 |
| 36 |
756-04224 |
Flat Idler Pulley 2.75 Price: $24.80 |
| 37 |
783-04442 |
Center Double Idler Pulley Price: $31.46 |
| 38 |
783-0667B |
TRANSMISSION TORQUE BRACKET Not Available Price: |
| 39 |
783-0745-0637 |
CONTROL BRACKET Not Available This part replaces 783-0745. Price: |
| 40 |
783-0782-0637 |
ACTUATOR BRACKET Not Available This part replaces 783-0782. Price: |
| 41 |
753-05606 |
SERVICE REPLACEMENT KITLAC Not Available This part replaces 647-0031B. Price: |
| 42 |
647-0049A-0637 |
HYDRO CONTROL ASSEMBLY (POWDER BLACK) Not Available This part replaces 647-0049A. Price: |
| 43 |
683-0267C |
CONTROL PEDAL ASSEMBLY Not Available Price: |
| 44 |
710-0650 |
TT Screw 5/16-18 x.875 Price: $3.71 |
| 45 |
710-1260A |
LD Screw 5/16-18 x.750 Price: $3.34 |
| 46 |
710-1611B |
TT Screw 5/16-18 x.750 Price: $5.94 |
| 47 |
711-04159B |
Pin 3/8-16 x 2.68 Price: $6.75 |
| 48 |
712-3004A |
HEX FLANGE NUT Price: $3.49 |
| 49 |
732-0335 |
SPRING Not Available Price: |
| 50 |
732-0955 |
Extension Spring.50 x 1.41 Price: $8.34 |
| 51 |
732-0963 |
Extension Spring.50 x 6.37 Price: $8.91 |
| 52 |
735-0662 |
Drive Pedal Pad Price: $10.46 |
| 53 |
735-3049A |
Pad, Brake This part replaces 735-3049. Price: $11.30 |
| 54 |
936-0119 |
LOCK WASHER 5/16 This part replaces 736-0119. Price: $4.29 |
| 55 |
736-0187 |
Flat Washer.64 x 1.24 x.06 Price: $4.02 |
| 56 |
736-0262 |
Flat Washer.385 x.870 x.092 Price: $3.66 |
| 57 |
936-3008 |
Flat Washer, .344 x .750 x .120 This part replaces 736-3008. Price: $6.24 |
| 58 |
938-0155 |
Screw, Shoulder.437 Dia x.162 This part replaces 738-0155. Price: $6.01 |
| 59 |
738-0380 |
Shoulder Screw.50 x.27 x 3/8-16 Price: $7.34 |
| 60 |
941-0225 |
FLANGE BEARING This part replaces 741-0225. Price: $6.55 |
| 61 |
741-3065B |
Hex Flange Bearing.628 ID Split Price: $7.45 |
| 62 |
747-04093A |
LOCK CONTROL BRAKE ROD Not Available This part replaces 747-04093. Price: |
| 63 |
747-04096 |
CRUISE CONTROL ROD Not Available Price: |
| 64 |
753-05606 |
SERVICE REPLACEMENT KITLAC Not Available This part replaces 747-04521. Price: |
| 65 |
748-04039C |
CRUISE LATCH Not Available This part replaces 748-04039B. Price: |
| 66 |
783-04612-0637 |
Steering Support Bracket This part replaces 783-04612. Price: $78.74 |
| 67 |
783-0663E |
LOCKOUT BRACKET Not Available Price: |
| 68 |
712-3050 |
Lug Nut 7/16-14 Price: $9.17 |
| 69 |
634-0202A |
WHEEL ASM COMP.23X Not Available Price: |
| 69 |
634-04238 |
RIM ASSEMBLY (12 x 7) This part replaces 634-3178. Price: $141.19 |
| 69 |
934-0255 |
TUBELESS VALVE This part replaces 734-0255. Price: $3.83 |
