| Ref | Part Number | Description |
|---|
| 1 |
3-9034 |
DISCONTINUED Price: Call Us |
| 1 |
530054429 |
Handle Price: $7.99 |
| 2 |
322-9 |
SCREW-HH Price: $3.09 |
| 2 |
530054432 |
Isolator-Handle Price: $3.99 |
| 3 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 3 |
530016316 |
Nut Price: $1.99 |
| 4 |
3-7243 |
SPRING-EXTENSION Price: $11.23 |
| 4 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 5 |
5-2907 |
DISCONTINUED Price: Call Us |
| 5 |
530016258 |
Plate-Crankcase Price: $0.64 |
| 6 |
5-2916 |
DISCONTINUED Price: Call Us |
| 6 |
530055336 |
Shroud Price: $17.99 |
| 7 |
3272-13 |
PIN-COTTER This part replaces 3272-14. Price: $0.25 |
| 7 |
530055378 |
Shield-Heat Price: $4.99 |
| 8 |
3256-39 |
WASHER-FLAT Price: $1.29 |
| 8 |
530015805 |
Screw Price: $1.99 |
| 9 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 9 |
530015880 |
Screw Price: $1.99 |
| 10 |
5-2908 |
DISCONTINUED Price: Call Us |
| 10 |
530071472 |
Gasket-Carb. (Kit) Price: $6.99 |
| 11 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 11 |
530052333 |
Air Box Price: $2.99 |
| 12 |
282-2 |
YOKE Price: $30.04 |
| 12 |
530015123 |
Washer Price: $1.99 |
| 13 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 13 |
530015892 |
Screw Price: $1.99 |
| 14 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 14 |
530052332 |
Cover-Air Box Price: $1.99 |
| 15 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 15 |
530047932 |
Foam-Air Filter Price: $1.99 |
| 16 |
530016353 |
Screw Price: $1.99 |
| 16 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 17 |
322-3 |
SCREW-HH Price: $0.79 |
| 17 |
530071629 |
Kit - Carburetor Assy C1U-W12A This part replaces 530071471. Price: $54.99 |
| 18 |
3217-26 |
NUT-HEX Price: $0.25 |
| 18 |
530016014 |
Screw Price: $1.99 |
| 19 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 19 |
545030402 |
CARBURETOR ADAPTOR This part replaces 530056403. Price: $8.99 |
| 20 |
3274-33 |
DISCONTINUED Price: Call Us |
| 20 |
530071472 |
Gasket-Cyl/Carb. Adaptor (Kit) Price: $6.99 |
| 21 |
5-3323 |
DISCONTINUED Price: Call Us |
| 21 |
530071472 |
Gasket-C'case/Shroud (Kit) Price: $6.99 |
| 23 |
323-39 |
SCREW-HH This part replaces 323-21. Price: $1.60 |
| 23 |
530071625 |
C'case & C'shaft Ass'y. This part replaces 530052344. Price: $39.99 |
| 24 |
323-23 |
SCREW-HH Price: $2.07 |
| 25 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 25 |
530015941 |
Retainer Ring (C'shaft) Price: $1.99 |
| 26 |
5-3900 |
Main Frame (Incl. Ref. 46) Price: Call Us |
| 26 |
545221701 |
FLYWHEEL ASSY This part replaces 530069886. Price: $8.99 |
| 27 |
256-159 |
BUSHING Price: $24.63 |
| 27 |
545081702 |
KIT FAN HSG This part replaces 530055335. Price: $11.99 |
| 28 |
3-8775 |
DISCONTINUED Price: Call Us |
| 28 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 29 |
3-8778 |
DISCONTINUED Price: Call Us |
| 30 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 30 |
530032125 |
Inner Bearing Price: $11.99 |
| 31 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 31 |
530015945 |
Retainer Ring (C'case) Price: $1.99 |
| 32 |
322-3 |
SCREW-HH Price: $0.79 |
| 32 |
530019179 |
Seal-Crankcase Price: $2.99 |
| 33 |
322-6 |
SCREW-HH Price: $0.45 |
| 33 |
530032124 |
Bearing-Outer Price: $4.99 |
| 34 |
5-4403 |
DISCONTINUED Price: Call Us |
| 34 |
530071472 |
Gasket-Cylinder (Kit) Price: $6.99 |
| 35 |
3-9035 |
DISCONTINUED Price: Call Us |
| 35 |
530036145 |
Spacer-Ign. Module Price: $1.99 |
| 36 |
5-4401 |
DISCONTINUED Price: Call Us |
| 36 |
530039163 |
Ignition Module Price: $34.99 |
| 37 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 37 |
530019182 |
Grommet-Ign. Module Price: $1.99 |
| 38 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 38 |
530015954 |
Screw Price: $1.99 |
| 39 |
217-34 |
BOLT WHEEL RETAINER Price: $13.47 |
| 39 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 40 |
3212-2 |
SCREW-HH Price: $3.60 |
| 41 |
3254-20 |
WASHER-LOCK, INT This part replaces 3254-3. Price: $1.29 |
| 41 |
530015162 |
Wrist Pin Retainer Price: $1.99 |
| 42 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 42 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 43 |
3273-32 |
DISCONTINUED Price: Call Us |
| 43 |
530015953 |
Screw Price: $1.99 |
| 44 |
3-9274 |
SPACER Price: $6.33 |
| 44 |
530012416 |
Cylinder This part replaces 530071359. Price: $17.99 |
| 45 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 45 |
952030249 |
Spark Plug (RCJ-6Y) Price: $3.99 |
| 46 |
256-90 |
BUSHING-FLANGE Price: $2.92 |
| 46 |
530042088 |
Spring-Muffler Price: $1.99 |
| 47 |
5-1183 |
DISCONTINUED Price: Call Us |
| 48 |
3-8826 |
DISCONTINUED Price: Call Us |
| 48 |
530071361 |
Kit-Spark Aresstor Price: $4.99 |
| 49 |
3-8844 |
DISCONTINUED Price: Call Us |
| 50 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 51 |
3212-2 |
SCREW-HH Price: $3.60 |
| 52 |
3-8845 |
DISCONTINUED Price: Call Us |
| 53 |
3218-5 |
NUT-JAM Price: $0.27 |
| 54 |
5-4002 |
DISCONTINUED Price: Call Us |
| 55 |
5-2568 |
DISCONTINUED Price: Call Us |
| 56 |
325-13 |
SCREW-HH Price: $3.57 |
| 57 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 58 |
5-4693 |
CHAIN Price: $30.29 |
| 59 |
323-11 |
SCREW-HH Price: $1.08 |
| 60 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 61 |
5-2567 |
DISCONTINUED Price: Call Us |
| 62 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 63 |
3-8936 |
DISCONTINUED Price: Call Us |
| 64 |
3-9033 |
DISCONTINUED Price: Call Us |
| 65 |
3220-2 |
NUT-JAM Price: $0.50 |
| 66 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 67 |
23-4680 |
BRAKE BAND ASM This part replaces 5-2905. Price: $229.48 |
| 68 |
3273-30 |
DISCONTINUED Price: Call Us |
| 69 |
5-3314 |
Cable Guard Price: Call Us |
| 70 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 71 |
3254-8 |
WASHER-LOCK Price: $0.37 |
| 72 |
5-3910 |
DISCONTINUED Price: Call Us |
| 73 |
5-3913 |
DISCONTINUED Price: Call Us |
| 74 |
5-2913 |
DISCONTINUED Price: Call Us |
