| Ref | Part Number | Description |
|---|
| 1 |
104-3436-03 |
PLATE-CONTROL Price: $37.56 |
| 1 |
188720 |
Seat Price: Call Us |
| 2 |
105-0054 |
DECAL-PANEL, CONTROL Price: $74.97 |
| 2 |
140551 |
Bracket Pivot Seat 8 720 Price: Call Us |
| 3 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 4 |
3274-65 |
SCREW-HSBH Price: $1.15 |
| 5 |
145006 |
Clip Push-In Price: Call Us |
| 5 |
98-9308 |
GAUGE-TEMPERATURE Price: $112.90 |
| 6 |
73800600 |
Nut Hex w/Ins. 3/8-16 unc Price: Call Us |
| 6 |
98-9339 |
GAUGE-FUEL Price: $115.28 |
| 7 |
124181X |
Spring Seat Cprsn 2 250 Blk Zi Price: Call Us |
| 8 |
17000616 |
Screw 3/8-16 x 1.5 Smgml Price: Call Us |
| 9 |
19131614 |
Washer 13/32 x 1 x 14 Ga. Price: Call Us |
| 10 |
195530 |
Pan Seat Price: Call Us |
| 11 |
166369 |
Knob Seat Price: Call Us |
| 12 |
112-6561 |
WARNING LIGHT ASM This part replaces 98-9306. Price: $121.84 |
| 12 |
174648 |
Bracket Mounting Switch Price: Call Us |
| 13 |
121248X |
Bushing Snap Blk Nyl 50 Id Price: Call Us |
| 14 |
72050412 |
Bolt Rdhd Sqnk 1/4-20 x 1-1/2 Price: Call Us |
| 15 |
134300 |
Spacer Split 28 x 96 Price: Call Us |
| 16 |
121250X |
Spring Cprsn Price: Call Us |
| 17 |
120-2244 |
HOURMETER This part replaces 66-2950. Price: $48.06 |
| 17 |
123976X |
Nut Lock 1/4 Lge Flg Gr. 5 Zinc Price: Call Us |
| 18 |
124238X |
Cap Spring Seat Price: Call Us |
| 21 |
138-1911 |
PTO SWITCH KIT This part replaces 85-4980. Price: $320.00 |
| 21 |
171852 |
Bolt Shoulder 5/16-18 unc Price: Call Us |
| 22 |
73800500 |
Nut Hex Lock W/Ins 5/16-18 Price: Call Us |
| 24 |
104-2541 |
SWITCH ASM Price: $36.70 |
| 24 |
19171912 |
Washer 17/32 x 1-3/16 x 12 Ga. Price: Call Us |
| 25 |
127018X |
Bolt Shoulder 5/16-18 x 62 Price: Call Us |
| 27 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 28 |
100-8072 |
SWITCH Price: $94.07 |
| 29 |
105-0029 |
BRACKET-CONTROLLER Price: $30.21 |
| 30 |
98-7611 |
CONTROLLER-GLOW Price: $316.53 |
| 32 |
98-9321 |
RING-KEY Price: $1.80 |
| 34 |
32105-13 |
SCREW-HWH Price: $1.59 |
