| Ref | Part Number | Description |
|---|
| 1 |
108-1412 |
TURBO CHARGER ASM This part replaces 99-8332. Price: $3,754.74 |
| 1 |
532071673 |
PLUNGER CAP Price: $4.99 |
| 2 |
105-3768 |
GASKET This part replaces 99-8333. Price: $31.56 |
| 2 |
532123436 |
ROD,PARK BRAKE Price: $4.99 |
| 3 |
532123437 |
BRKT,PARK BRAKE Price: $4.46 |
| 3 |
99-8334 |
BOLT Price: $0.69 |
| 4 |
532008156 |
FOOT PEDAL COVER Price: $2.64 |
| 4 |
99-8335 |
FLANGE-MUFFLER Price: $305.34 |
| 5 |
532122504 |
BRKT,CLU PEDAL LH Price: $3.08 |
| 5 |
99-8336 |
BOLT Price: $3.41 |
| 6 |
100-2562 |
BOLT This part replaces 98-7610. Price: $2.79 |
| 6 |
596917601 |
Pins This part replaces 876020312. Price: $1.99 |
| 7 |
819131016 |
WASHER Price: $2.99 |
| 7 |
98-7534 |
NUT Price: $0.48 |
| 8 |
3253-4 |
WASHER-LOCK This part replaces 99-8339. Price: $0.25 |
| 8 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 9 |
105-3767 |
GASKET This part replaces 99-8340. Price: $29.57 |
| 9 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 10 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 10 |
99-8342 |
STUD This part replaces 99-8341. Price: $0.84 |
| 11 |
532123543 |
ROD,FRT BRAKE Price: $8.38 |
| 11 |
99-8342 |
STUD Price: $0.84 |
| 12 |
532139933 |
CLUTCH/BRAKE PEDAL ASSY Price: $21.38 |
| 13 |
532123394 |
ROD,CLUTCH Price: $7.99 |
| 14 |
532121978 |
BRKT,LIFT SHAFT Price: $2.38 |
| 15 |
532133332 |
ARM, BRAKE ASMBLY Price: $6.71 |
| 16 |
819251816 |
WASHER T Price: $4.99 |
| 17 |
812000034 |
Ring, Klip Price: $2.99 |
| 18 |
532151332 |
SPRING, BRAKE ROD This part replaces 532106888. Price: $4.99 |
| 19 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 20 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 21 |
532131461 |
CLUTCH KIT This part replaces 532131460. Price: $13.99 |
| 22 |
532144585 |
TRUNNION, LEFT Price: $8.99 |
| 24 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 25 |
532004921 |
COTTER PIN This part replaces 532124961. Price: $4.99 |
| 26 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 27 |
532127369 |
LINK.MOWER.REAR Price: $9.99 |
| 28 |
532140776 |
REAR MOWER LIFT ASSY Price: $40.26 |
| 29 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 30 |
596040501 |
Hardware This part replaces 873510500. Price: $2.99 |
| 31 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $2.99 |
