| Ref | Part Number | Description |
|---|
| 1 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 1 |
MA-19572321000 |
PLATE-SPD Not Available Price: |
| 2 |
195223 |
Shaft Asm., Lift Price: Call Us |
| 2 |
325-6 |
SCREW-HH Price: $1.42 |
| 2 |
MA-19572322AG0 |
LINK-SPEED Not Available Price: |
| 3 |
105-0418-01 |
ARM-STEERING Price: $568.38 |
| 3 |
195231 |
Lever Asm., Lift Rh Price: Call Us |
| 3 |
MA-19572323AG0 |
ARM-SPEED CONTROL Not Available Price: |
| 4 |
105-4316-03 |
STEERING MOUNT ASM Price: $105.64 |
| 4 |
MA-05500006032 |
SPRING PIN Not Available Price: |
| 5 |
104-2053 |
DECAL-WARNING Price: $20.70 |
| 5 |
93-8063 |
DECAL-CAUTION, CE Price: $18.92 |
| 5 |
MA-03500130815 |
WASHER Not Available Price: |
| 6 |
105-4326 |
SCREW-HH, LH Price: $11.60 |
| 6 |
MA-05200125015 |
COTTER PIN Not Available This part replaces MA-05200125016. Price: |
| 7 |
107-2562 |
NUT-HEX Price: $19.95 |
| 7 |
196492 |
Grip, Lever Price: Call Us |
| 7 |
MA-19632311000 |
SHAFT PEDAL Not Available Price: |
| 8 |
75-0560 |
STEERING WHEEL ASM Price: $204.13 |
| 8 |
MA-19632312000 |
SHAFT Not Available Price: |
| 9 |
MA-19632313000 |
ARM LOCK Not Available Price: |
| 10 |
196314 |
Spring Torsion Price: Call Us |
| 10 |
3241-1 |
SCREW-SET, SQH Price: $22.99 |
| 10 |
MA-19632317000 |
SPRING Not Available Price: |
| 11 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 11 |
MA-19632334000 |
ARM BRAKE Not Available Price: |
| 12 |
3274-39 |
SCREW-HSBH Price: $4.34 |
| 12 |
MA-07972020200 |
BUSHING Not Available Price: |
| 13 |
105-0457 |
PLATE-FRICTION Price: $28.64 |
| 13 |
MA-19632336000 |
SHOE Not Available Price: |
| 14 |
47-2890 |
BUSHING Price: $3.19 |
| 14 |
MA-05620108025 |
PIN Not Available Price: |
| 15 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 15 |
MA-05200125015 |
COTTER PIN Not Available This part replaces MA-05200125016. Price: |
| 16 |
119-3587 |
LEVER-STEERING This part replaces 105-4313. Price: $26.68 |
| 16 |
MA-19572325AG0 |
PLATE Not Available Price: |
| 17 |
92-6798 |
CAP-ROD, TILT Price: $4.59 |
| 17 |
MA-F1540108020 |
BOLT,W/SPRING WASH Not Available Price: |
| 18 |
323-29 |
SCREW-HH Price: $0.42 |
| 18 |
MA-14212284000 |
GRIP Not Available Price: |
| 19 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 19 |
MA-19572331AG0 |
LEVER-SPEE Not Available Price: |
| 20 |
3290-477 |
WASHER-CURVED Price: $0.79 |
| 20 |
MA-19572332000 |
ROD-SPEED Not Available Price: |
| 21 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 21 |
MA-19572335000 |
PLATE-CNTR Not Available Price: |
| 22 |
105-0425 |
STEERING COLUMN ASM Price: $376.71 |
| 22 |
MA-A3000106002 |
NUT Not Available Price: |
| 23 |
83-0810 |
COVER-STEERING Price: $110.46 |
| 23 |
MA-05200125015 |
COTTER PIN Not Available This part replaces MA-05200125016. Price: |
| 24 |
3290-277 |
NUT-SPEED Price: $0.61 |
| 24 |
MA-03500140818 |
WASHER Not Available Price: |
| 25 |
130-7943 |
VALVE-STEERING,CONTROL This part replaces 105-0424. Price: $1,160.56 |
| 25 |
MA-05200125015 |
COTTER PIN Not Available This part replaces MA-05200125016. Price: |
| 26 |
340-1 |
FITTING-STRAIGHT Price: $10.19 |
| 27 |
33103-016 |
SCREW-HHF Price: $5.18 |
| 28 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 87 |
194209 |
Pin Cotter 7/16 Bow Tie Lock Price: Call Us |
| 88 |
195303 |
Spring Lift Assist Price: Call Us |
| 89 |
19191912 |
Washer Clear Zinc Price: Call Us |
| 90 |
194208 |
Pin Cotter 5/16 Bow Tie Lock Price: Call Us |
| 91 |
195181 |
Link Asm. Lift Rear Price: Call Us |
| 97 |
17060612 |
Screw 3/8-16 x .75 Smgml Tap/R.Z Price: Call Us |
