| Ref | Part Number | Description |
|---|
| 1 |
532170551 |
CONTROL TH/CH FLAG This part replaces 532140310. Price: $22.99 |
| 1 |
98-2354-03 |
LATCH-SEAT Price: $41.34 |
| 2 |
539990072 |
HCS 1/4C X 5/8 This part replaces 817720410. Price: $1.99 |
| 2 |
98-2353 |
BRACKET-LATCH, SEAT Price: $17.71 |
| 3 |
32128-25 |
NUT-HF Price: $3.19 |
| 4 |
98-9342 |
DECAL-SOLENOID, INFORMATION Price: $69.36 |
| 5 |
98-9302 |
PLATE-STOP, IDLER Price: $12.42 |
| 6 |
532272293 |
Gasket Eng 1 313 Id Tin Plated This part replaces 532125593. Price: $7.99 |
| 6 |
66-4190-03 |
SPRING-IDLER, CLUTCH Price: $7.20 |
| 7 |
105-4674 |
DECAL-NOISE Price: $4.80 |
| 9 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 10 |
25-8640 |
SCREW-HH Price: $1.09 |
| 11 |
3296-3 |
NUT-LOCK Price: $0.54 |
| 11 |
810040500 |
Washer Lock Hvy Hlcl Spr 5/16 Price: $2.99 |
| 12 |
532192334 |
Screw Socket Hd 5/16-18 x .75 This part replaces 871070512. Price: $2.99 |
| 12 |
98-9311 |
SWIVEL-THROTTLE Price: $28.41 |
| 13 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 13 |
532137348 |
Muffler LT B&S 12/12.5/13HP Price: $45.99 |
| 14 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 14 |
813280324 |
Nipple Pipe 3/8 Npt X 3" Price: Call Us |
| 15 |
322-3 |
SCREW-HH Price: $0.79 |
| 15 |
813200300 |
Elbow Std 90 Degree 3/8-18 Npt Price: $4.99 |
| 16 |
539990118 |
WASHER.3/8 This part replaces 811050600. Price: $1.49 |
| 16 |
75-3400 |
SHAFT-PIVOT, SEAT Price: $21.81 |
| 17 |
110-4149 |
KIT-SEAT PLATE This part replaces 98-2350-03. Price: $166.30 |
| 17 |
874760620 |
Bolt Fin Hex 3/8-16 UNC x 1-1/4 This part replaces 817490620. Price: $3.99 |
| 18 |
532136718 |
Shield Heat Lt Price: $3.79 |
| 18 |
93-8060 |
DECAL-REELS Price: $53.80 |
| 19 |
233-42 |
KNOB Price: $12.88 |
| 19 |
532105839 |
Receptacle 1/4 turn Price: $3.99 |
| 20 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 20 |
532105838 |
Retainer 1/4 turn Price: $3.99 |
| 21 |
819091016 |
Washer 9/32 x 5/8 x 16 Ga. Price: $2.99 |
| 21 |
98-9303 |
CABLE-THROTTLE Price: $21.41 |
| 22 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 22 |
532123650 |
Stud 1/4 turn Price: $3.99 |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 23 |
532128953 |
Shield Heat Browning LT/YT Price: $3.08 |
| 24 |
817021008 |
Screw Tap Hex #10-24unc X 1/2 Price: $1.99 |
| 24 |
98-2352-03 |
FRAME-SEAT Price: $456.00 |
| 25 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 26 |
93-0021 |
SWIVEL-CABLE, THROTTLE Price: $33.15 |
| 27 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 28 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 29 |
321-4 |
SCREW-HH Price: $0.99 |
| 29 |
532137180 |
Kit Spark Arrestor (Flat Scrn) Price: $128.99 |
| 30 |
532127057 |
Pinch Weld Hood Black Price: $2.38 |
| 30 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 31 |
532180645 |
GAS TANK 2GAL This part replaces 532140280. Price: $51.99 |
| 31 |
75-3680-03 |
ROD-SEAT Price: $38.90 |
| 32 |
581075501 |
CAP.FUEL.TANK.SS/SNO.EPA.DOME This part replaces 532140527. Price: $14.99 |
| 33 |
532123487 |
Clamp Hose Black Price: $3.99 |
| 34 |
532124028 |
Bushing Snap Nyl Blk Fuel Line Price: $3.99 |
| 35 |
874760412 |
Bolt Hex Hd 1/4-20 unc x 3/4 This part replaces 817490412. Price: $3.99 |
| 36 |
819091416 |
Washer 9/32 X 7/8 X 16 Ga Price: $3.99 |
