| Ref | Part Number | Description |
|---|
| 1 |
710-04916 |
Bolt M6×14 Price: $3.86 |
| 1 |
75-3480 |
FRAME-UPPER Price: $323.32 |
| 2 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 2 |
951-11194 |
Muffler Shield Price: $59.77 |
| 3 |
66-8520 |
BUMPER-DOWNSTOP Price: $37.56 |
| 3 |
710-04915 |
Bolt M6×12 Price: $3.82 |
| 4 |
751P10757A |
THROTTLE LEVER KNOB This part replaces 951-10757. Price: $6.01 |
| 4 |
82-9060 |
DISCONTINUED Price: Call Us |
| 5 |
76-1960 |
KNOB KIT This part replaces 77-2870. Price: $357.33 |
| 5 |
951-11594 |
Control Panel Price: $47.87 |
| 6 |
76-1910 |
DISCONTINUED Price: Call Us |
| 6 |
951-10637 |
Key Switch Base Price: $13.28 |
| 7 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 7 |
951-10630 |
Ignition Key This part replaces 731-05632. Price: $6.07 |
| 8 |
76-1940 |
SPRING-EXTENSION Price: $66.03 |
| 9 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 9 |
951-11302 |
Choke Knob Price: $5.94 |
| 10 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 10 |
710-04914 |
Bolt M6×10 Price: $3.71 |
| 11 |
66-8610 |
DISCONTINUED Price: Call Us |
| 11 |
951-11181 |
Muffler Baffle Price: $27.15 |
| 12 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 12 |
951-11227 |
Heat Shield Price: $25.66 |
| 13 |
710-04968 |
Bolt M6×16 Price: $5.77 |
| 13 |
75-3580 |
PLATE-SEAT Price: $213.06 |
| 14 |
75-3510 |
BOLT-SHOULDER Price: $14.55 |
| 14 |
951-11195 |
Muffler Assembly Price: $114.49 |
| 15 |
712-04219 |
Nut M8 Price: $5.34 |
| 15 |
80-4860 |
PIN-CLEVIS Price: $6.13 |
| 16 |
75-3530 |
SPRING-COMPRESSION Price: $31.98 |
| 17 |
3285-19 |
PIN-GROOVE This part replaces 75-3540. Price: $1.79 |
| 18 |
75-3550 |
BUMPER-SEAT Price: $18.48 |
| 19 |
76-2940 |
BUMPER Price: $9.73 |
| 20 |
75-3570 |
TIP-VINYL Price: $2.48 |
| 21 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 22 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 24 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 25 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 26 |
3256-46 |
WASHER-FLAT Price: $5.77 |
| 27 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 28 |
93-3164 |
CAP Price: $11.64 |
| 29 |
93-3163 |
SPRING Price: $26.01 |
| 30 |
93-3165 |
BRACKET Price: $37.47 |
| 31 |
322-6 |
SCREW-HH Price: $0.45 |
| 32 |
3253-33 |
WASHER-LOCK Price: $1.19 |
