| Ref | Part Number | Description |
|---|
| 1 |
04001-109 |
BOLT, HEX HEAD, 1/4-20 X 1-3/8 Price: Call Us |
| 2 |
481434 |
PULLEY, 5.55 OD Price: Call Us |
| 3 |
481497 |
Belt, Main Drive This part replaces 481235. Price: Call Us |
| 4 |
48926 |
HUB, TAPERED Price: Call Us |
| 5 |
04063-06 |
KEY, 1/4 X 1/4 X 1-1/2 Price: Call Us |
| 6 |
04001-62 |
BOLT, HEX HEAD, 3/8-16 X 3-1/4 Price: Call Us |
| 7 |
04040-07 |
FLATWASHER, 1/2(.531 X .062 X .095) Price: Call Us |
| 8 |
04001-90 |
BOLT, HEX HEAD, 1/2-13 X 3-1/4 Price: Call Us |
| 9 |
48062 |
PULLEY, IDLER - 5.75 DIA. Price: Call Us |
| 10 |
43391 |
SPACER Price: Call Us |
| 11 |
04050-02 |
RETAINING RING, .75 "E" Price: Call Us |
| 12 |
04041-08 |
FLATWASHER, 3/8(.766 X 1.25 X .06) Price: Call Us |
| 13 |
04041-08S |
FLATWASHER, 3/8(7.66 X 1.25 X .035) Price: Call Us |
| 14 |
48100-05 |
BUSHING, OILITE, .753 ID Price: Call Us |
| 15 |
46081 |
ARM, IDLER Price: Call Us |
| 16 |
43277 |
SPACER, J-PULL ROD Price: Call Us |
| 17 |
04001-22 |
BOLT, HEX HEAD, 3/8-16 X 2-3/4 Price: Call Us |
| 18 |
44114 |
ROD, J-PULL Price: Call Us |
| 19 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 20 |
04004-31 |
STUD, 3/8-16 X 4.00 Price: Call Us |
| 21 |
04021-09 |
HEX LOCKNUT, ELASTIC STOP, 3/8-16 Price: Call Us |
| 22 |
04021-07 |
HEX LOCKNUT, ELASTIC STOP, 1/2-13 Price: Call Us |
| 23 |
45741 |
PIVOT, ENGINE IDLER Price: Call Us |
| 24 |
48114-04 |
GREASE FITTING Price: Call Us |
| 25 |
04019-04 |
SERR. FL. HEX NUT, 3/8-16 Price: Call Us |
| 26 |
483211 |
Idler Pulley, Wheel Drive This part replaces 48198. Price: Call Us |
| 27 |
48141 |
HUB, TAPERED, 1.00 BORE Price: Call Us |
| 28 |
04063-01 |
KEY, 1/4 X 1/4 X 1-1/4 Price: Call Us |
| 29 |
481227 |
GEARBOX, T-DRIVE Price: Call Us |
| 30 |
481229 |
PULLEY, 4.25 OD DOUBLE GROOVE Price: Call Us |
| 31 |
44075 |
ROD, J-PULL Price: Call Us |
| 32 |
43277 |
SPACER, J-PULL Price: Call Us |
| 33 |
483208 |
Pulley, Idler 3" Dia. - 52" This part replaces 481048. Price: Call Us |
| 34 |
04041-12 |
FLATWASHER, 3/8(.375 X 1.50 X .06) Price: Call Us |
| 35 |
04003-21 |
CARRIAGE BOLT, 3/8-16 X 2-1/2 Price: Call Us |
| 36 |
481499 |
Belt, R.H. Transmission Drive This part replaces 481237. Price: Call Us |
| 37 |
481498 |
Belt, L.H. Transmission Drive This part replaces 481236. Price: Call Us |
| 38 |
48791 |
HUB, TAPERED, 15MM Price: Call Us |
| 39 |
04001-12 |
BOLT, HEX HEAD, 5/16-18 X 1-3/4 Price: Call Us |
| 40 |
04001-53 |
BOLT, HEX HEAD, 5/16-18 X 2-1/2 Price: Call Us |
| 41 |
04030-03 |
LOCKWASHER, 5/16 Price: Call Us |
| 42 |
04017-04 |
SERR. FL. HEX HEAD CPSCR, 1/4-20 X 1/2 Price: Call Us |
| 43 |
481225 |
PUMP, L.H. Price: Call Us |
| 44 |
481223 |
AXLE, L.H. Price: Call Us |
| 45 |
04001-51 |
BOLT, HEX HEAD, 3/8-16 X 3-3/4 Price: Call Us |
| 46 |
481503 |
Drive Wheel Assembly This part replaces 48827. Price: Call Us |
| 47 |
04028-01 |
NUT, WHEEL Price: Call Us |
| 48 |
421209 |
BACK-UP WASHER, FAN Price: Call Us |
| 49 |
04001-126 |
BOLT, HEX HEAD, 5/16-18 X 5-1/2 Price: Call Us |
| 50 |
481231 |
PULLEY, 4.25 OD Price: Call Us |
| 51 |
482133 |
Fan, Cooling This part replaces 48789. Price: Call Us |
| 52 |
04001-96 |
BOLT, HEX HEAD, 5/16-18 X 4-1/2 Price: Call Us |
| 53 |
04040-04 |
FLATWASHER, 5/16(.344 X .688 X .065) Price: Call Us |
| 54 |
04063-14 |
KEY, 5 MM X 5 MM X 25 MM Price: Call Us |
| 55 |
481226 |
PUMP, R.H. Price: Call Us |
| 56 |
481224 |
AXLE, R.H. Price: Call Us |
| 57 |
04020-03 |
HEX NUT, 5/16-18 Price: Call Us |
| 58 |
43063 |
SPACER Price: Call Us |
| 59 |
04001-94 |
BOLT, HEX HEAD, 5/16-18 X 7-1/2 Price: Call Us |
| 60 |
04001-19 |
BOLT, HEX HEAD, 3/8-16 X 1.0 Price: Call Us |
| 61 |
481232 |
FAN, COOLING RH Price: Call Us |
| 62 |
04041-07 |
FLATWASHER, 3/8(.391 X .938 X .105) Price: Call Us |
| 63 |
421863 |
WASHER, HEAT DEFLECTOR Price: Call Us |
