| Ref | Part Number | Description |
|---|
| 1 |
47-3650 |
CHAIN-LIFT, NO. 2 AND 3 Price: $119.48 |
| 1 |
532170803 |
CONTROL, THROTTLE Price: $24.99 |
| 2 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 2 |
8-0280 |
DISCONTINUED Price: Call Us |
| 3 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 4 |
51-0850-01 |
SUPPORT-PULLEY This part replaces 51-0850. Price: $306.47 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 5 |
325-17 |
SCREW-HH Price: $2.90 |
| 5 |
532181444 |
EXHAUST TUBE LH KAWI Price: $54.99 |
| 6 |
47-3930-01 |
LOCKUP BRACKET ASM This part replaces 47-3930. Price: $270.92 |
| 6 |
532181442 |
EXHAUST TUBE RH KAWI Price: $59.99 |
| 7 |
32128-23 |
NUT-HF Price: $1.51 |
| 8 |
47-3640-01 |
CYLINDER REST ASM This part replaces 47-3640. Price: $44.42 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
3290-216 |
WASHER Price: $3.83 |
| 10 |
325-6 |
SCREW-HH Price: $1.42 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 11 |
47-3870-01 |
RH CHANNEL ASM This part replaces 47-3870. Price: $235.39 |
| 12 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 13 |
26-8590 |
PIN-CYLINDER Price: $23.00 |
| 14 |
237-79 |
O-RING Price: $5.46 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
353-537 |
FITTING-ELBOW, 90 DEG Price: $12.91 |
| 16 |
115-4949-01 |
HYDRAULIC CYLINDER ASM (14.00 STROKE) This part replaces 47-3720. Price: $1,376.05 |
| 17 |
20-4390 |
SPACER Price: $12.54 |
| 18 |
32104-17 |
SCREW-HWH Price: $0.99 |
| 19 |
42-3550-01 |
COVER-MOUNT, CYLINDER This part replaces 42-3550. Price: $108.41 |
| 20 |
3-0144 |
SHAFT Price: $53.89 |
| 21 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 22 |
47-3860-01 |
LH CHANNEL ASM This part replaces 47-3860. Price: $215.68 |
| 23 |
13-6200 |
PIN-HITCH, POINTED Price: $40.83 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 24 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 25 |
47-3010-01 |
TRAILER ASM This part replaces 47-3010. Price: $3,956.22 |
| 25 |
532191812 |
NEEDS DESCRIPTION Price: Call Us |
| 26 |
322-3 |
SCREW-HH Price: $0.79 |
| 27 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 28 |
60-9110-01 |
LIFT BAIL PIN ASM This part replaces 60-9110. Price: $84.41 |
| 29 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 31 |
47-3230-01 |
NO. 1 LIFT ARM ASM This part replaces 47-3230. Price: $907.15 |
| 31 |
581289901 |
FUEL.TANK.ASM.NON-EPA This part replaces 532185534. Price: $44.99 |
| 32 |
32513-5 |
Nut-Lock Price: Call Us |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532197725. Price: $22.99 |
| 33 |
3-2196-01 |
SHEAVE This part replaces 3-2196. Price: $141.72 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 34 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 35 |
47-3660 |
CHAIN-LIFT, NO. 1 Price: $197.71 |
| 36 |
5-2942 |
SHACKLE Price: $16.99 |
| 37 |
325-7 |
SCREW-HH Price: $1.53 |
| 37 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 38 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 44 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 46 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 105 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 116 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
