| Ref | Part Number | Description |
|---|
| 1 |
482340 |
Grip, Control Lever Price: Call Us |
| 3 |
04001-09 |
Bolt, Hex Hd. 5/16-18 x 1" Price: Call Us |
| 4 |
04030-03 |
Lockwasher, 5/16" Price: Call Us |
| 5 |
483269 |
Knob Price: Call Us |
| 6 |
04040-15 |
Flatwasher, 5/16 (.375 x .875 x .083") Price: Call Us |
| 7 |
04060-01 |
Roll Pin, Spring 5/32 x 3/4" Price: Call Us |
| 8 |
483238 |
Pivot, Control Lever Price: Call Us |
| 9 |
04021-09 |
Nut, Elastic Stop 3/8-16 Price: Call Us |
| 10 |
482330 |
Rod End, 3/8-24 RH Female Price: Call Us |
| 11 |
04020-14 |
Nut, 3/8-24 RH Thread Price: Call Us |
| 12 |
482623 |
Rod, Pump Control Linkage Price: Call Us |
| 13 |
04020-17 |
Nut, 3/8-24 UNF-2B LH Thread Price: Call Us |
| 14 |
482331 |
Rod End, 3/8-24 LH Thread Price: Call Us |
| 15 |
43477 |
Pin Retainer Price: Call Us |
| 16 |
04001-20 |
Bolt, Hex Head 3/8-16 x 1-1/2" B&S 32BV Price: Call Us |
| 17 |
04001-12 |
Bolt, Hex Hd. 5/16-18 x 1-3/4" Price: Call Us |
| 18 |
43602 |
Spacer, Pump Damper Price: Call Us |
| 19 |
423599 |
Plate, Control Lever Price: Call Us |
| 20 |
04001-17 |
Bolt, Hex Hd. 5/16-18 x 2" Price: Call Us |
| 21 |
484151 |
Gas Damper Price: Call Us |
| 22 |
04001-19 |
Bolt, Hex Hd. 3/8-16 x 1" Price: Call Us |
| 23 |
482099 |
Block, Clamping Price: Call Us |
| 24 |
04003-12 |
Bolt, Carriage, 5/16-18 x 3/4" Price: Call Us |
| 25 |
461770 |
Control Plate - LH w/Decal Price: Call Us |
| 26 |
04019-03 |
Nut, Serr., Flng., 5/16-18 Price: Call Us |
| 27 |
04021-08 |
Nut, Elastic Stop 1/4-20 Price: Call Us |
| 28 |
04001-18 |
Bolt, Hex Hd. 3/8-16 x 3/4" Price: Call Us |
| 29 |
43616 |
Shaft, Steering Control Price: Call Us |
| 30 |
04021-10 |
Nut, Elastic Stop 5/16-18 Price: Call Us |
| 31 |
48114-04 |
Grease Fitting, 1/4-28 Self Tap Price: Call Us |
| 32 |
43559 |
Spacer, Control Price: Call Us |
| 34 |
04021-10 |
Nut, Elastic Stop 5/16-18 Price: Call Us |
| 35 |
48100-06 |
Bushing Price: Call Us |
| 36 |
04041-08 |
Flatwasher, 3/4 (.766 x 1.25 x .059") Price: Call Us |
| 37 |
04050-02 |
Retaining Ring, 3/4" Ext. Price: Call Us |
| 38 |
423057 |
Bracket, Switch Actuator Price: Call Us |
| 39 |
04017-16 |
Bolt, Hex Serr. Flng. 5/16-18 x 3/4" Price: Call Us |
| 40 |
04003-02 |
Bolt, Carr. 1/4-20 x 3/4" Price: Call Us |
| 41 |
45918 |
Bracket, Control Return Price: Call Us |
| 42 |
481389 |
Spring Price: Call Us |
| 43 |
43477 |
Pin Retainer Price: Call Us |
| 44 |
04003-38 |
Bolt, Carriage 5/16-18 x 1-1/2" Price: Call Us |
| 461771 |
Control |
Plate - RH w/Decal Price: Call Us 461771 |
