| Ref | Part Number | Description |
|---|
| 1 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 2 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 532445962. Price: $44.99 |
| 3 |
3-8514 |
WASHER-THRUST Price: $1.58 |
| 4 |
69-8390 |
SPINDLE PULLEY ASSEMBLY Price: $162.41 |
| 5 |
253-154 |
SEAL-OIL Price: $5.48 |
| 6 |
71-2530 |
BEARING/SPACER KIT Price: $160.66 |
| 7 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 8 |
69-1530 |
HOUSING-SPINDLE Price: $227.62 |
| 9 |
32128-21 |
NUT-HF Price: $0.39 |
| 9 |
596501502 |
Keepers This part replaces 584908001. Price: $9.99 |
| 10 |
138-6388 |
SHAFT-SPINDLE This part replaces 69-6760. Price: $189.44 |
| 11 |
138-6416 |
SPACER-SPINDLE, SHAFT This part replaces 92-9800. Price: $18.44 |
| 11 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $229.99 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 12 |
69-6920-03 |
BLADE-20 IN. This part replaces 69-6920. Price: $31.92 |
| 13 |
67-7561 |
CUP-SCALP, ANTI Price: $40.99 |
| 14 |
3253-8 |
WASHER-LOCK Price: $0.47 |
| 15 |
51-4060 |
SCREW-BLADE Price: $7.39 |
| 15 |
599306004 |
FUEL TANK, 3GAL, 2.25"NECK, 20 This part replaces 532438080. Price: $199.99 |
| 18 |
532439208 |
CAP.ASM.FL.RITCH.3"E10.SYM.498 Price: $37.99 |
| 20 |
587242504 |
THROTTLE CABLE This part replaces 587242501. Price: $32.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
