| Ref | Part Number | Description |
|---|
| 1 |
532186093 |
WHEEL.STEERING.LEGND2.GRY This part replaces 532193943. Price: $89.99 |
| 1 |
63-7900-03 |
RACK This part replaces 63-7900. Price: $144.55 |
| 2 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 4 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532194743. Price: $14.99 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532194744. Price: $19.99 |
| 5 |
92-7498 |
TUBE ASSY-STEERING,FRT,RH Price: $117.13 |
| 6 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
92-7499 |
DISCONTINUED Price: Call Us |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 8 |
92-7497 |
TUBE ASSY-STEERING,FRT,LH Price: $120.49 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
92-7544 |
STEERING VALVE ASSY-4PORT Price: $1,202.49 |
| 10 |
3234-7 |
SCREW-HHF Price: $1.99 |
| 11 |
75-2810 |
BRACKET-COLUMN, STEERING Price: $11.01 |
| 12 |
21-9260 |
COVER-DUST Price: $8.19 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
75-0560 |
STEERING WHEEL ASM Price: $204.13 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
68-5140 |
CAP-WHEEL, STEERING Price: $15.13 |
| 15 |
68-5370 |
DECAL Price: $6.21 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
32144-21 |
SCREW Price: $0.20 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532194746. Price: $34.99 |
| 17 |
3220-6 |
NUT-JAM Price: $1.25 |
| 18 |
105-3306 |
SPEEDOMETER KIT, RM6000 SERIES This part replaces 93-4213. Price: $424.47 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 19 |
93-1263 |
DECAL-TOWER Price: $46.56 |
| 19 |
93-7554 |
DISCONTINUED Price: Call Us |
| 20 |
93-7998-03 |
PLATE-INSTRUMENT This part replaces 93-7998. Price: $40.21 |
| 21 |
218-536 |
WASHER-LOCK Price: $1.09 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532194845. Price: $14.99 |
| 22 |
94-3090 |
HARNESS - WIRE, MAIN Price: $1,957.31 |
| 23 |
218-533 |
LENS Price: $17.62 |
| 24 |
44-2210 |
LIGHT-INDICATOR, RED Price: $57.97 |
| 25 |
93-7480 |
LED-MINIATURE Price: $78.50 |
| 26 |
532193652 |
INSERT.CAP.STRG.WH.GRAY Price: $11.99 |
| 26 |
87-6620 |
SCREW Price: $1.29 |
| 27 |
233-17 |
KNOB Price: $10.58 |
| 28 |
218-535 |
NUT-HEX Price: $0.34 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 30 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 31 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 32 |
95-1821 |
SPRING-COMPRESSION This part replaces 3-3251. Price: $6.71 |
| 33 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 34 |
237-22 |
O-RING Price: $2.43 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 35 |
94-1447 |
STEERING RETURN TUBE ASM Price: $79.79 |
| 36 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 37 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 38 |
340-70 |
NUT-LOCK Price: $2.10 |
| 39 |
92-7495 |
STEERING TUBE ASM Price: $148.27 |
| 40 |
340-117 |
CAP Price: $10.30 |
| 41 |
92-7622 |
DISCONTINUED Price: Call Us |
| 42 |
92-7494 |
REAR STEARING TUBE ASM Price: $150.03 |
| 43 |
92-7606-03 |
BRACKET-BULKHEAD This part replaces 92-7606. Price: $13.64 |
| 44 |
92-7496 |
TUBE ASSY-STEERING,FRT,RH Price: $82.04 |
| 45 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 47 |
75-1490 |
ROD-BRAKE, PARKING Price: $50.23 |
| 48 |
237-42 |
O-RING Price: $2.78 |
| 50 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 51 |
3253-2 |
WASHER-LOCK Price: $0.25 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 52 |
3219-14 |
NUT-HEX Price: $0.25 |
| 53 |
3256-14 |
WASHER-FLAT Price: $0.39 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
56-7973 |
CLAMP-TUBE Price: $15.56 |
| 57 |
532197246 |
BRKT.UPSTOP.GT/LT.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
