| Ref | Part Number | Description |
|---|
| 1 |
117-8093 |
RADIATOR ASM This part replaces 104-3780. Price: $2,185.13 |
| 1 |
98000129 |
NUT Price: Call Us |
| 2 |
114-3995 |
OIL COOLER ASM This part replaces 82-3740. Price: $1,388.56 |
| 2 |
161415X428 |
SHLD.SIDE.OUTER.L Price: Call Us |
| 3 |
8393J |
STAKE PIN TI Price: Call Us |
| 3 |
94-2638 |
NUT-FLAT Price: $0.54 |
| 4 |
12000036 |
KLIP RING TI Price: Call Us |
| 4 |
93-6028 |
PLATE-LOGO Price: $13.70 |
| 5 |
72140506 |
BOLT Price: Call Us |
| 5 |
92-7505-03 |
SCREEN ASM Price: $1,733.53 |
| 6 |
8394J |
SPRING TI Price: Call Us |
| 6 |
92-7631 |
SEAL-SCREEN Price: $33.08 |
| 7 |
77-3620 |
KNOB-RETAINER Price: $15.13 |
| 7 |
8392J |
LATCH BRACKET TI Price: Call Us |
| 8 |
109230X |
SPRING CRT Price: Call Us |
| 8 |
93-4208 |
SEAL-SCREEN, STRIP Price: $68.49 |
| 9 |
102326X428 |
SHIELD TINE Price: Call Us |
| 9 |
32151-72 |
RING-RETAINING Price: $1.59 |
| 10 |
104085X428 |
SHIELD SIDE Price: Call Us |
| 10 |
92-7535 |
HOSE ASM Price: $197.33 |
| 11 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 11 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 12 |
10040500 |
LOCKWASHER Price: Call Us |
| 12 |
37-8771 |
BOLT-SHOULDER,HFH Price: $3.59 |
| 13 |
32128-20 |
NUT-HF Price: $0.99 |
| 13 |
72110510 |
BOLT Price: Call Us |
| 14 |
124343X |
BRKT SHIELD TINE Price: Call Us |
| 14 |
92-7516-03 |
BRACKET-SUPPORT, COOLER BASE Price: $46.80 |
| 15 |
161414X428 |
SHLD.SIDE.OUTER.R Price: Call Us |
| 16 |
3269-4 |
RIVET-POP Price: $1.19 |
| 16 |
73510400 |
NUT Price: Call Us |
| 17 |
105-9296 |
LATCH-DRAW Price: $71.82 |
| 18 |
100-3758-03 |
BUMPER ASM Price: $1,074.80 |
| 18 |
72040410 |
BOLT Price: Call Us |
| 19 |
102701X |
GRIP CRT Price: Call Us |
| 19 |
2410-42 |
CAP-END Price: $11.62 |
| 20 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 20 |
73220600 |
NUT.HEX.3/8-16UNC Price: Call Us |
| 21 |
102156X |
SUB= 102156X500 Price: Call Us |
| 21 |
325-6 |
SCREW-HH Price: $1.42 |
| 22 |
74930632 |
BOLT Price: Call Us |
| 22 |
92-7416-03 |
STRAP-RADIATOR Price: $32.23 |
| 23 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 23 |
4440J |
HINGE CRT Price: Call Us |
| 24 |
72140404 |
BOLT Price: Call Us |
| 25 |
237-65 |
O-RING Price: $2.50 |
| 25 |
6712 |
J VINYL CAP TI Price: Call Us 6712 J |
| 26 |
109227X |
PAD IDLER TI Price: Call Us |
| 26 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 27 |
2410-64 |
PLUG-BUTTON Price: $0.74 |
| 28 |
104-3781 |
HOSE-RADIATOR, LOWER Price: $98.96 |
| 29 |
104-3782 |
HOSE-RADIATOR, UPPER Price: $116.97 |
| 30 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 33 |
98-4576-03 |
BRACKET-RESERVOIR, WATER This part replaces 98-4576. Price: $43.21 |
| 34 |
108-0638 |
BOTTLE-OVERFLOW This part replaces 104-9318. Price: $33.20 |
| 35 |
321-4 |
SCREW-HH Price: $0.99 |
| 36 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 37 |
281-13 |
PLUG-PIPE Price: $2.86 |
| 38 |
98-7895 |
TUBE Price: $6.88 |
| 39 |
110-4110 |
HOSE-LP This part replaces 54-8040. Price: $8.31 |
| 40 |
2412-108 |
CLAMP-WORM Price: $1.29 |
