| Ref | Part Number | Description |
|---|
| 1 |
137-7038-03 |
CONTROL BOX ASM Price: $107.28 |
| 2 |
119-3470 |
ACTUATOR ARM ASM Price: $17.50 |
| 3 |
120-2273 |
WASHER-NYLON Price: $1.54 |
| 4 |
133-9299-05 |
ARM-CONTROL Price: $32.13 |
| 5 |
133-7055 |
HANDLE-CONTROL, LH Price: $41.09 |
| 6 |
133-7057 |
HANDLE-CONTROL, RH Price: $41.09 |
| 7 |
133-9301 |
SPEED CONTROL ASM Price: $51.21 |
| 8 |
115-5099 |
BOLT-PIVOT Price: $2.32 |
| 9 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 10 |
117-1240 |
WASHER Price: $1.27 |
| 11 |
119-8925 |
WASHER-BELLEVILLE Price: $0.80 |
| 12 |
117-1198 |
BOLT-PIVOT Price: $2.01 |
| 13 |
3234-47 |
SCREW-HHF Price: $1.79 |
| 14 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 15 |
119-8952 |
WASHER Price: $0.77 |
| 16 |
120-7950 |
SCREW-SHOULDER Price: $1.79 |
| 17 |
131-4132 |
DAMPER Price: $43.77 |
| 18 |
110-6810 |
STUD-DAMPER Price: $3.50 |
| 19 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 20 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 21 |
323-6 |
SCREW-HH Price: $0.66 |
| 22 |
117-5385 |
RETAINER Price: $0.81 |
| 23 |
32144-70 |
SCREW-HWHTF Price: $1.99 |
| 24 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 25 |
138-7217 |
ROD-HYDRO This part replaces 117-5388. Price: $8.29 |
| 26 |
138-7218 |
MOUNT-ROD, HYDRO This part replaces 119-8842. Price: $7.95 |
| 27 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 28 |
1-603807 |
SPRING-RETURN, NEUTRAL Price: $3.29 |
| 29 |
121-1753 |
PIN-ROD, HYDRO Price: $3.52 |
| 30 |
93-6079 |
SPACER-NYLON Price: $0.25 |
| 31 |
321-3 |
SCREW-HH Price: $0.28 |
| 32 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 33 |
132-9368 |
KNOB-RH Price: $1.63 |
| 34 |
132-9369 |
KNOB-LH Price: $1.63 |
| 35 |
94-4496 |
SCREW-PPH Price: $0.89 |
