48"/122CM CUTTING DECK
Parts (64)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 107-0807 | VALVE-FLUSHING, RH Price: $129.44 |
| 2 | 107-0857 | PLUG Price: $31.81 |
| 3 | 107-0817 | O RING-PLUG Price: $3.09 |
| 4 | 120-5150 | CENTER CASE ASM Price: $2,743.66 |
| 6 | 107-0805 | PLATE-VALVE Price: $114.64 |
| 7 | 107-0824 | CYLINDER BLOCK ASM Price: $1,216.33 |
| 8 | 107-0830 | PLATE-THRUST Price: $77.36 |
| 9 | 92-0765 | PIN-PARALLEL Price: $3.03 |
| 10 | 107-0859 | BOLT Price: $1.56 |
| 11 | 120-6681 | U-NUT Price: $9.77 |
| 12 | 131-5505 | ARM-CONTROL Price: $205.55 |
| 13 | 107-0832 | SIDE COVER ASM Price: $444.99 |
| 14 | 107-0829 | WASHER Price: $35.71 |
| 15 | 120-5151 | PUMP HOUSING ASM Price: $4,033.93 |
| 16 | 107-0826 | BEARING Price: $32.70 |
| 17 | 107-0821 | BEARING Price: $40.03 |
| 18 | 107-0838 | BEARING Price: $62.42 |
| 19 | 120-6682 | BOLT Price: $7.06 |
| 20 | 107-0810 | GASKET-CASE, CENTER Price: $22.76 |
| 21 | 107-0814 | SEAL Price: $49.69 |
| 22 | 93-0475 | O-RING This part replaces 104-3298. Price: $8.99 |
| 23 | 107-0861 | PLUG-NPTF Price: $11.67 |
| 24 | 237-79 | O-RING Price: $5.46 |
| 25 | 107-0867 | PLUG Price: $14.59 |
| 26 | 107-0812 | PIPE Price: $75.78 |
| 27 | 107-0852 | CENTER CASE SEAL KIT Price: $12.50 |
| 28 | 107-0813 | SPACER Price: $8.69 |
| 29 | 107-0853 | PUMP HOUSING SEAL KIT Price: $190.09 |
| 30 | 120-6679 | PLATE-SWASH Price: $882.98 |
| 31 | 107-0808 | VALVE-BYPASS Price: $86.68 |
| 32 | 107-0804 | VALVE-REAR Price: $414.56 |
| 33 | 107-0803 | VALVE-FRONT Price: $414.56 |
| 34 | 107-0863 | BOLT Price: $1.22 |
| 35 | 107-0806 | VALVE-FLUSHING, LH Price: $129.44 |
| 48 | 502642102 | NEEDS DESCRIPTION Price: Call Us |
| 49 | 725245171 | SCREW Price: $2.08 |
| 50 | 732211801 | LOCKNUT M8 Price: $3.99 |
| 52 | 502641903 | NEEDS DESCRIPTION Price: Call Us |
| 53 | 506869601 | BEARING Price: $8.99 |
| 54 | 506813801 | PLATE Price: $5.99 |
| 55 | 725246151 | BOLT Price: $4.99 |
| 56 | 732211801 | LOCKNUT M8 Price: $3.99 |
| 57 | 504812702 | NEEDS DESCRIPTION Price: Call Us |
| 58 | 502642301 | PARALLEL ROD Price: $12.99 |
| 59 | 506839803 | NEEDS DESCRIPTION Price: Call Us |
| 60 | 721618301 | Split Pin Price: $1.99 |
| 61 | 502642003 | NEEDS DESCRIPTION Price: Call Us |
| 62 | 738210404 | BALL BEARING 6004-2RS1 Price: $9.99 |
| 63 | 535505901 | PIVOT WHEELS Price: $109.99 |
| 65 | 506963001 | DECK ROLLER, FRONT Price: $54.99 |
| 66 | 506810802 | PIPE Price: $7.99 |
| 67 | 506874102 | SPACER Price: $5.99 |
| 68 | 725251951 | BOLT Price: $9.99 |
| 69 | 732212001 | NUT This part replaces 732212051. Price: $3.99 |
| 70 | 506504805 | WASHER Price: $3.99 |
| 71 | 506570104 | BOLT Price: $4.99 |
| 72 | 734116441 | SPACER Price: $3.99 |
| 73 | 544017001 | HUB CAP PIVOT WHEEL Price: $2.99 |
| 74 | 506597401 | BOLT Price: $5.99 |
| 75 | 732211801 | LOCKNUT M8 Price: $3.99 |
| 76 | 502639502 | NEEDS DESCRIPTION Price: Call Us |
| 77 | 502642401 | NEEDS DESCRIPTION Price: Call Us |
| 78 | 725245171 | SCREW Price: $2.08 |
| 79 | 732211801 | LOCKNUT M8 Price: $3.99 |
