| Ref | Part Number | Description |
|---|
| 1 |
71673 |
PLUNGER CAP T Price: Call Us |
| 4 |
8156H |
FOOT PEDAL COVER Price: Call Us |
| 5 |
132205 |
BRK ASM CLUT LH Price: Call Us |
| 6 |
76020312 |
SUB= 3145 Price: Call Us |
| 7 |
19131016 |
WASHER Price: Call Us |
| 8 |
17490508 |
SCREW LT Price: Call Us |
| 9 |
76020412 |
COTTER PIN Price: Call Us |
| 010 |
131-6557 |
ALTERNATOR ASM This part replaces 98-9474. Price: $443.05 |
| 10 |
19131316 |
WASHER Price: Call Us |
| 12 |
136263 |
ASM CLUTCH/BRK PD Price: Call Us |
| 15 |
123641X |
BRAKE PIVOT ARM Price: Call Us |
| 16 |
19251816 |
WASHER T Price: Call Us |
| 17 |
12000034 |
KLIP RING Price: Call Us |
| 18 |
106888X |
SPRING ROD LT Price: Call Us |
| 19 |
73350600 |
NUT Price: Call Us |
| 020 |
98-9453 |
PULLEY-DYNAMO Price: $138.04 |
| 20 |
73680600 |
SUB= 73690600 Price: Call Us |
| 21 |
131460 |
SUB= 532131460 Price: Call Us |
| 22 |
127378 |
SUB= 144585 Price: Call Us |
| 23 |
73680600 |
SUB= 73690600 Price: Call Us |
| 24 |
19132012 |
WASHER Price: Call Us |
| 25 |
4921H |
SPRING.RETAINER Price: Call Us |
| 26 |
73930600 |
LOCKNUT Price: Call Us |
| 27 |
132218 |
THREADED LINK Price: Call Us |
| 28 |
132221 |
ASM REAR MOW LIFT Price: Call Us |
| 29 |
72110506 |
SUB= 72270506 Price: Call Us |
| 030 |
98-7708 |
NUT Price: $7.76 |
| 30 |
73510500 |
NUT Price: Call Us |
| 31 |
133095 |
COUNTER SPRING Price: Call Us |
| 040 |
98-7709 |
COLLAR Price: $8.79 |
| 050 |
107-0136 |
ROTOR ASM This part replaces 98-7710. Price: $268.62 |
| 060 |
98-7711 |
COVER-BEARING Price: $7.32 |
| 070 |
98-7712 |
BEARING-BALL Price: $31.09 |
| 080 |
98-7713 |
WASHER-THRUST Price: $4.49 |
| 090 |
98-7714 |
FRAME-END, DRIVE Price: $311.88 |
| 100 |
98-7715 |
PLATE-RETAINER Price: $9.38 |
| 110 |
98-7716 |
SCREW-HEAD, ROUND Price: $0.91 |
| 120 |
98-7717 |
BOLT-THROUGH Price: $9.75 |
| 130 |
98-7718 |
BEARING-BALL Price: $34.82 |
| 140 |
98-7719 |
FRAME-END Price: $88.65 |
| 150 |
98-7720 |
COVER-END Price: $39.58 |
| 160 |
98-7721 |
RECTIFIER ASM Price: $486.45 |
| 170 |
98-7722 |
BUSHING-INSULATION Price: $28.44 |
| 180 |
98-7723 |
HOLDER-BRUSH Price: $52.72 |
| 190 |
98-7724 |
BRUSH Price: $12.41 |
| 200 |
98-7725 |
SPRING-BRUSH Price: $4.32 |
| 210 |
98-7726 |
SCREW-HEAD, ROUND Price: $0.42 |
| 220 |
98-7727 |
SCREW-HEAD, ROUND Price: $0.94 |
| 230 |
98-7728 |
SCREW-HEAD, ROUND Price: $0.70 |
| 240 |
98-7729 |
BOLT Price: $2.35 |
| 250 |
98-7730 |
NUT Price: $1.31 |
| 260 |
98-7731 |
BOLT Price: $3.94 |
| 270 |
98-7732 |
NUT Price: $1.45 |
