| Ref | Part Number | Description |
|---|
| 0 |
632528 |
CARBURETOR Price: $80.77 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG Price: $149.99 |
| 1 |
631615 |
SHAFT & LEV Price: $6.48 |
| 2 |
532140551 |
SEAT PIVOT BRKT Price: $3.99 |
| 2 |
631767 |
SPRING Price: $1.25 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $2.99 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 4 |
819131610 |
WASHER PM Price: $3.99 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 6 |
631036 |
SHUTTER Price: $1.20 |
| 6 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $2.99 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 9 |
819131612 |
Washer 13/32 X 1 X 12 Ga (AYP part number) This part replaces 819131614. Price: $3.99 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT Price: $14.99 |
| 10 |
630973 |
SHAFT & LEV Price: $5.16 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 11 |
632045 |
SPRING Price: $1.25 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK Price: $4.99 |
| 12 |
631184 |
WASHER Price: $1.25 |
| 13 |
532121248 |
BUSHING Price: $3.99 |
| 13 |
631183 |
WASHER Price: $1.25 |
| 14 |
631582 |
SHUTTER Price: $1.20 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $3.99 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 16 |
631807 |
FUEL FITTING Price: $6.03 |
| 17 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 17 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 532123976. Price: $2.99 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 20 |
631838 |
ADJ SCREW Price: $2.71 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $1.99 |
| 21 |
630766 |
SPRING Price: $1.25 |
| 22 |
630739 |
WASHER Price: $1.25 |
| 22 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.99 |
| 23 |
630740 |
O RING Price: $1.49 |
| 25 |
532127018 |
BOLT,SHOULD Price: $3.99 |
| 25 |
631867 |
FLOAT BOWL Price: $2.34 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
632816 |
FLOAT This part replaces 632802. Price: $5.90 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 40 |
631583 |
POWER SCREW Price: $10.18 |
| 41 |
630740 |
O RING Price: $1.49 |
| 42 |
630739 |
WASHER Price: $1.25 |
| 43 |
630738 |
SPRING Price: $1.25 |
| 44 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
